[00:00:00] <_methods> if it's too tight offset and cut again
[00:00:09] <_methods> or hit with thread file
[00:00:37] -!- sumpfralle has quit [Ping timeout: 256 seconds]
[00:06:01] -!- Nick001-shop has quit [Quit: ChatZilla 0.9.91.1 [Firefox 34.0.5/20141126041045]]
[00:06:01] -!- FreezingCold has quit [Remote host closed the connection]
[00:06:01] -!- tekniq_ has quit [Ping timeout: 256 seconds]
[00:06:01] <dirty_d> trial and error
[00:06:01] <dirty_d> im just gonna do that
[00:06:01] -!- FreezingCold [FreezingCold!~FreezingC@135.0.41.14] has joined #linuxcnc
[00:06:01] <dirty_d> cut it too tight and just recut until it fits
[00:06:01] -!- sumpfralle [sumpfralle!~lars@erina.opennet-initiative.de] has joined #linuxcnc
[00:06:01] <_methods> yeah well normally you measure then make an offset lol
[00:06:01] <dirty_d> looks pretty pointy
http://cdn.mscdirect.com/global/images/ProductImages/4023292-23.jpg
[00:06:01] <dirty_d> why wouldnt the manufactureer just do that?
[00:06:01] <_methods> do what?
[00:08:08] <dirty_d> specify the diameter as it would be if the points were infinitely sharp
[00:08:08] <dirty_d> they designed it, so they do know that dimension
[00:08:09] <_methods> well personally i'll look at the manufacturers sheets but in the end i'm making the part so i measure the tools i'm working with
[00:08:09] <_methods> i trust nothing
[00:08:09] <_methods> great way to scrap parts just going by a piece of paper
[00:08:09] <tjtr33> re threadmilling: any use?
http://www.guhring.com/Tech/ThreadMillCNC/CNCGenerator/
[00:08:09] -!- anarchos2 has quit [Read error: Connection reset by peer]
[00:08:42] -!- anarchos2 [anarchos2!~mike@S010600259ce59399.vn.shawcable.net] has joined #linuxcnc
[00:09:13] <_methods> code looks good
[00:09:31] -!- dgmurdock [dgmurdock!~dgmurdock@c-73-168-14-247.hsd1.in.comcast.net] has joined #linuxcnc
[00:09:34] -!- DGMurdockIII has quit [Ping timeout: 244 seconds]
[00:09:44] -!- dgmurdock has quit [Read error: Connection reset by peer]
[00:10:01] -!- sumpfralle has quit [Ping timeout: 265 seconds]
[00:11:09] <dirty_d> _methods, how do you measure it? micrometer and some kinda 60deg thing that mates against the cutters?
[00:11:24] <Tom_itx> no, round bars
[00:11:32] <_methods> the threads?
[00:11:37] <Tom_itx> yes
[00:11:44] <dirty_d> i mean on the thread mill
[00:11:45] <Tom_itx> there should be data for that
[00:11:46] <_methods> yeah either thread mic or 3 wire
[00:11:47] <dirty_d> single profile type
[00:12:00] <_methods> well for that cutter i'd put it in a vblock
[00:12:29] <dirty_d> thats 90 deg though
[00:12:36] <_methods> measure cutter round diameter then drop down to centeline
[00:12:52] <_methods> then rotate the cutter to hit the high
[00:12:59] <_methods> to measure it's dist from centerline
[00:13:27] -!- TTN [TTN!~TTN@unaffiliated/ttn] has joined #linuxcnc
[00:13:56] <dirty_d> hmm
[00:15:17] <dirty_d> that looks pretty damn pointy
http://www.model-engineer.co.uk/sites/7/images/member_albums/70420/439869.jpg
[00:15:17] <Tom_itx> get the profile data on the cutter for the tip radius then calculate the difference
[00:15:17] <dirty_d> i think i could just get away with pretending it is infinitely sharp
[00:15:20] <_methods> yeah
[00:15:20] <dirty_d> cut the OD, then cut the ID a little small then finish to fit
[00:15:26] <dirty_d> and record what offsets i needed
[00:15:50] -!- tris [tris!tristan@2001:1868:a00a::4] has joined #linuxcnc
[00:17:55] <dirty_d> Tom_itx, i dont think there is any data
[00:17:55] <_methods> you're single point thread milling an external thread?
[00:17:55] <dirty_d> internal and external
[00:17:55] -!- sumpfralle [sumpfralle!~lars@erina.opennet-initiative.de] has joined #linuxcnc
[00:17:55] <_methods> weird thread or something?
[00:17:55] <dirty_d> yea
[00:17:56] <dirty_d> plus i figured i can do any kinda thread within a pretty braod range with just a few of these
[00:17:56] <dirty_d> sure its slower, but i dont care
[00:17:56] <_methods> yeah
[00:17:56] <_methods> its' handy for small runs
[00:17:56] <dirty_d> not building a factory or anything
[00:17:56] <_methods> and odd threads
[00:17:56] <dirty_d> just hobby stuff
[00:17:56] <_methods> yeah
[00:17:56] <_methods> it works just sneak up on it
[00:17:56] <_methods> and you'll be good to go
[00:17:56] <dirty_d> im learning theres a lot of that in this
[00:17:56] <dirty_d> a lot more manual that i thought
[00:17:56] <_methods> yeah there are a lot of variables
[00:18:04] <_methods> best to be patient
[00:18:15] <_methods> it's either that or you get to make the part again lol
[00:18:24] <dirty_d> like for holes and ODs ill just using a boring bar and creep up to what i need
[00:18:31] <_methods> yeah
[00:18:43] <dirty_d> im kinda worried about the boring head screwing off coing CCW though
[00:18:47] <dirty_d> i think it just screws on
[00:18:59] <dirty_d> boring head i mean
[00:19:01] <dirty_d> no lathe
[00:19:17] <_methods> you're using a boring head on a cnc?
[00:19:17] <dirty_d> yea
[00:19:17] <_methods> why not just interpolate?
[00:19:30] <dirty_d> oh i do, i only use that if the diameter is important
[00:19:35] <_methods> ahhh
[00:19:36] <dirty_d> like for a bearing to fit
[00:19:40] <_methods> k
[00:20:00] <dirty_d> and probably the ID and OD that need to be thread milled
[00:20:01] <_methods> yeah i only use boring head in cnc for super tight stuff
[00:20:16] <dirty_d> but im not sure if even that is neccessary
[00:20:25] <dirty_d> the tolerances on threads looks pretty loose
[00:20:33] <_methods> yeah
[00:20:43] <_methods> well it depends on the thread call out
[00:20:47] <_methods> some can be very tight
[00:20:58] <_methods> but for the most part threads aren't too bad
[00:21:18] <dirty_d> i was looking at this for 3A and 3B
http://theoreticalmachinist.com/Threads_UnifiedImperial.aspx
[00:22:01] <dirty_d> looks like +/-0.003" for pitch diameter
[00:22:01] <_methods> yeah that shows you how to measure using 3 wire technique
[00:23:16] <_methods> do you have a machinists handbook?
[00:23:20] <dirty_d> nope
[00:23:27] <dirty_d> im not sure which of those numbers is ideal either
[00:23:38] <dirty_d> like for major diameter 0.7500 / 0.7428
[00:23:53] <_methods> well it's pretty handy for that stuff
[00:23:57] <dirty_d> 0.75 would seem to be idea for a 3/4" thread
[00:24:00] <_methods> and explains a lot of things in more depth
[00:24:13] <roycroft> dirty_d: you really should get a copy of machinist's handbook
[00:24:20] <roycroft> and the book does not increase in size
[00:24:31] <_methods> your brain might though lol
[00:24:36] <roycroft> because it needs to fit in the drawer of a kennedy machinist's tool chest
[00:24:48] <dirty_d> lol
[00:24:50] <roycroft> so modern versions which have a lot of cnc info dropped some of the old-timey stuff
[00:25:07] <dirty_d> is that the name of an actual book?
[00:25:12] <roycroft> i say this because i'm going to recommend you go on ebay or amazon and get an old copy, from the '40s or the '50s
[00:25:13] <dirty_d> or a variety
[00:25:17] <roycroft> you can get it really cheap
[00:25:19] <_methods> machinery's handbook
[00:25:25] <roycroft> and yes, machinery's handbook
[00:25:25] <dirty_d> ahh, i see that
[00:25:35] <roycroft> and you can get a current copy later on
[00:25:37] <roycroft> if you want
[00:25:40] <roycroft> it's about $80
[00:25:53] <tjtr33> actual book, and machinists toolcases had a special drawer for it, true, and it was that basic a tool, that you really needed
[00:25:53] <roycroft> but you can an old copy for a fraction of that amount
[00:26:05] <_methods> i'm sure you can find a digital one for nothing
[00:26:07] <roycroft> yes, and they really did design a special drawer for it
[00:26:10] <tjtr33> cd available
[00:26:12] <dirty_d> yea id imagine
[00:26:15] <roycroft> and it really doesn't get bigger because of that
[00:26:26] <dirty_d> hah
[00:26:30] <_methods> but it's nice having it there physically
[00:26:37] <roycroft> the wooden gerstner machinist's chests have the drawer too
[00:26:52] <roycroft> it's good having a physical copy when you're working in the shop and need to look something up
[00:26:52] <tjtr33> thin bible paper, tiny fonts, a zillion pages
[00:27:27] <dirty_d> but for all intents and purposes, the pitch diameter is whats really important, because of varying radiuses?
[00:27:43] <_methods> the pitch diameter is what matters
[00:28:08] <dirty_d> but then how do they specify the pitch diameter for say a 3/4" UNF thread?
[00:28:32] <dirty_d> is it the centerline between an imaginary perfectly sharp thread with a 3/4" major diameter?
[00:28:40] <dirty_d> or 3/4" to the rounded edge?
[00:29:22] -!- tris has quit [Ping timeout: 256 seconds]
[00:29:34] <_methods> http://www.efunda.com/designstandards/screws/unified.cfm?start=148&finish=227
[00:29:56] <_methods> pitch diameter is the diameter between min and max
[00:31:20] <_methods> 0.7094 0.7056 for 3/4-16 3A
[00:31:29] <_methods> that's max and min pitch
[00:31:35] <dirty_d> oh, so its not like geometrically perfect
[00:31:40] -!- theorbtwo has quit [Remote host closed the connection]
[00:32:00] <dirty_d> i was visualizing the centerline of a triangle wave
[00:32:07] <_methods> it's a theroetical
[00:32:08] <dirty_d> as the pitch diameter
[00:32:10] <_methods> nominal
[00:32:16] -!- tris [tris!tristan@2001:1868:a00a::4] has joined #linuxcnc
[00:32:35] <_methods> and you need to use 3wire or thread mic to read it
[00:32:55] <_methods> that's why they make thread go/nogo gages
[00:33:10] <_methods> so people don't have to use 3wire or thread mic's all day
[00:33:18] <dirty_d> ok
[00:33:29] <Tom_itx> for production yes
[00:33:38] <Tom_itx> hardly worth it for one off etc
[00:33:42] <_methods> yes
[00:33:53] <_methods> for your case you need to learn to read 3 wire
[00:33:54] -!- tekniq [tekniq!~tekniq@179.sub-70-197-193.myvzw.com] has joined #linuxcnc
[00:34:06] <_methods> or just put the nut or screw on and see if you're happy
[00:35:04] <dirty_d> hmm
[00:36:27] -!- tekniq_ [tekniq_!~tekniq@198.179.137.223] has joined #linuxcnc
[00:37:40] -!- tekniq has quit [Read error: Connection reset by peer]
[00:38:08] -!- tekniq [tekniq!~tekniq@179.sub-70-197-193.myvzw.com] has joined #linuxcnc
[00:38:58] -!- akex2 has quit [Quit: Connection closed for inactivity]
[00:41:55] -!- tekniq_ has quit [Ping timeout: 265 seconds]
[00:48:26] -!- Valen has quit [Remote host closed the connection]
[00:49:49] -!- zeeshan-laptop [zeeshan-laptop!~zeeshan@mc-126-253.IPReg.mcmaster.ca] has joined #linuxcnc
[00:50:10] <zeeshan-laptop> ZZZZ
[01:04:12] -!- tekniq has quit [Remote host closed the connection]
[01:15:44] -!- PetefromTn_ [PetefromTn_!~IceChat9@75-136-60-251.dhcp.jcsn.tn.charter.com] has joined #linuxcnc
[01:18:06] <zeeshan-laptop> cant wait to get out of the lab
[01:18:08] <zeeshan-laptop> so tired
[01:18:12] <zeeshan-laptop> damn experiment running
[01:18:43] <zeeshan-laptop> its quiet in the channel
[01:19:36] <Tom_itx> make some noise
[01:20:01] <zeeshan-laptop> ive music blasting
[01:20:18] <zeeshan-laptop> nice thing about being by myself
[01:21:40] <Tom_itx> i'm copying drives. rather boreing
[01:21:54] <Tom_itx> trying to free up some drives to use
[01:22:01] <zeeshan-laptop> i formatted the other day
[01:22:08] <zeeshan-laptop> desktop feels brand new
[01:22:09] <zeeshan-laptop> :D
[01:22:17] <zeeshan-laptop> windows is such a hog after years of not formatting it
[01:22:22] <zeeshan-laptop> itll dump useless shit files everywhere
[01:22:31] <zeeshan-laptop> and the nonsense keeps growing
[01:23:26] <Tom_itx> no kidding
[01:23:41] <Tom_itx> one i did the other day is running alot better
[01:24:54] -!- rob_h has quit [Ping timeout: 256 seconds]
[01:26:17] -!- theorbtwo [theorbtwo!~theorb@cpc3-swin16-2-0-cust28.3-1.cable.virginm.net] has joined #linuxcnc
[01:35:56] <dirty_d> hrmm, cant figure out of im wrong or this online calculator is wrong
[01:37:28] -!- Loetmichel2 [Loetmichel2!~cylly@p54B11E83.dip0.t-ipconnect.de] has joined #linuxcnc
[01:37:48] <dirty_d> it says the basic pitch diameter for a 3/4-20 thread is 0.7175"
[01:37:57] <dirty_d> my sketch shows 0.7161"
[01:38:13] <dirty_d> im using the mathematical model
[01:38:43] <dirty_d> where Dmaj is set using P/8
[01:39:27] -!- Loetmichel has quit [Ping timeout: 245 seconds]
[01:47:09] <dirty_d> this also gives their answer
http://www.engineersedge.com/thread_strength/thread_bolt_pitch_circle_diameter.htm
[01:49:45] <zeeshan-laptop> home time!
[01:49:47] -!- zeeshan-laptop has quit [Quit: KVIrc 4.2.0 Equilibrium http://www.kvirc.net/]
[01:52:00] <jdh> http://raleigh.craigslist.org/for/4923104545.html
[01:58:05] <tjtr33> nice
[01:58:13] -!- anth0ny_ has quit [Quit: anth0ny_]
[02:00:00] <tjtr33> nice set of views
https://www.govdeals.com/index.cfm?fa=Main.Item&itemid=4456&acctid=127
[02:00:35] <dirty_d> hmm, now its right, im losing my mind
[02:02:10] -!- swingley has quit [Remote host closed the connection]
[02:02:21] <Roguish> dirty_d: per Mark's Mechanical Handbook (the bible) 0.7175 is the basic pitch diameter of the 3/4-20 UNEF thread.
[02:02:58] <dirty_d> thats what my sketch shows, maybe i was just seeing things before
[02:04:16] -!- swingley has quit [Read error: Connection reset by peer]
[02:06:00] <CaptHindsight> http://www.govdeals.com/index.cfm?fa=Main.Item&itemid=631&acctid=1997 Tree Journeyman 200R
[02:06:26] <tjtr33> ha CaptHindsight faster than i cheap tho
[02:06:42] <tjtr33> ( machines is cheap ;)
[02:07:10] <CaptHindsight> http://www.govdeals.com/index.cfm?fa=Main.Item&itemid=260&acctid=3524
[02:07:26] <CaptHindsight> used by the Postal service?!
[02:08:37] -!- swingley_ has quit [Ping timeout: 245 seconds]
[02:13:59] <tjtr33> who wanted a shipping ontainer, they got a few on govdeals
[02:15:21] <postaL> excuse me?
[02:15:37] <jdh> z:
https://www.govdeals.com/index.cfm?fa=Main.Item&itemid=403&acctid=6343
[02:17:25] -!- adam3999 [adam3999!~adam3999@pool-108-38-17-37.lsanca.fios.verizon.net] has joined #linuxcnc
[02:17:52] <CaptHindsight> furry wanted the container
[02:22:22] -!- furrywolf [furrywolf!~randyg@70.7.154.5] has joined #linuxcnc
[02:25:03] <tjtr33> furrywolf conatiner for shipping
http://www.govdeals.com/index.cfm?fa=Main.Item&itemid=42&acctid=2778
[02:25:38] -!- dirty_d has quit [Quit: Leaving]
[02:25:39] -!- kb8wmc [kb8wmc!~kb8wmc@64.25.194.29] has parted #linuxcnc
[02:25:50] <furrywolf> I'm sure everyone here will be completely and totally shocked to find out the 50W, 4500lm LED lamp I ordered from china isn't. My killawatt says it draws 32W, not 50W, and a quick visual brightness comparrison shows it to be about the same brightness as the 1600lm lamp I got from Costco for the same price, that only draws 19.5W.
[02:28:30] <CaptHindsight> those are Chinese Watts
[02:28:50] -!- PetefromTn_ has quit [Quit: I'm Outta here!!]
[02:29:05] <furrywolf> and chinese lumens too!
[02:29:32] <furrywolf> I'd paste a link, but my internet connections seems to be sucking too badly tonight to do complicated things like browse the web.
[02:29:33] <tjtr33> dang walmart has everything 40' containers
http://goo.gl/8ATvmq
[02:30:57] <furrywolf> http://www.ebay.com/itm/261475587095 <== fake. 32W, probably <2000lm.
[02:32:01] <CaptHindsight> tjtr33: Shipping Weight (in pounds): 14.95 ?
[02:32:09] -!- DenSchub has quit [Remote host closed the connection]
[02:32:20] <CaptHindsight> 1/4 scale
[02:32:37] <tjtr33> oh i thought 1/14 scale some expensive rc toy
[02:33:25] <furrywolf> yes, it's an expensive r/c toy.
[02:34:51] <tjtr33> but ebay has real ones for 1-2000 and real full sized. multiple seaport loations, if its of any use to you
[02:35:14] <CaptHindsight> http://www.trueactivist.com/a-shipping-container-costs-about-2000-what-these-15-people-did-with-that-is-beyond-epic/
[02:35:43] * furrywolf takes one look at the idiotic wording of the title and doesn't click
[02:35:53] <tjtr33> south east asian island beach homes?
[02:36:04] <tjtr33> IF you aint 6'4" like me :)
[02:37:01] <furrywolf> should I bother complaining about the fakeness of this bulb?
[02:37:04] <furrywolf> (to the seller)
[02:37:54] <CaptHindsight> ask them to send you the missing 18W
[02:38:53] <tjtr33> ah you're suppose to run it at 156% duty cycle
[02:39:22] <furrywolf> run it off 160V? :P
[02:40:59] <furrywolf> http://www.ebay.com/itm/High-Power-50W-COB-E27-LED-Bulb-Light-Lamp-Spotlight-White-Warm-White-AC85-265V-/261421509474 that looks like the next step upwards, but it's a lot of money
[02:41:16] <CaptHindsight> there needs to be a way to expose these corrupt sellers
[02:41:56] <furrywolf> there is not.
[02:42:34] <CaptHindsight> alibubu
[02:42:52] <furrywolf> fortunately, all these fake listings have an indicator that they're fake.
[02:43:09] <CaptHindsight> maybe mockery and irony
[02:43:30] <furrywolf> every one of them says "Item location: China".
[02:44:01] <furrywolf> the last one I pasted looks much less likely to be fake... but it's also $33.
[02:44:42] <CaptHindsight> what site did you find iton?
[02:44:48] <CaptHindsight> it on
[02:45:14] <furrywolf> ebay
[02:48:14] <Tom_itx> what's the easiest way to copy a drive to another with linux?
[02:48:19] <Tom_itx> bootable
[02:49:20] <furrywolf> are they identical? dd will copy it, but you'll need to manually resize partitions later.
[02:49:34] <Tom_itx> not identical
[02:49:55] <Tom_itx> but not full either
[02:56:39] -!- FinboySlick has quit [Quit: Leaving.]
[02:56:57] -!- ffurrywol [ffurrywol!~randyg@70.7.154.5] has joined #linuxcnc
[02:57:19] -!- AR_ has quit [Ping timeout: 245 seconds]
[02:57:43] <tjtr33> readup on dd. its powerful & dangerous, and has no progress info without trickery.
[02:57:45] <tjtr33> i'd think you can size the partitions on the destination drive, then dd each src to dest, then set the bootable flag on dest. i suggest you get a copy of the boot sector 1st and really be sure of each device's name ( /dev/sd? )
[02:58:31] <tjtr33> and for your 1st q, yes its easy. thus the danger
[02:58:46] -!- furrywolf has quit [Ping timeout: 255 seconds]
[03:02:06] -!- fablab has quit [Ping timeout: 252 seconds]
[03:03:41] * ffurrywol curls up and yawns
[03:06:08] -!- Roguish has quit [Quit: ChatZilla 0.9.91.1 [Firefox 36.0.1/20150305021524]]
[03:07:55] -!- sumpfralle1 [sumpfralle1!~lars@v22014112486721426.yourvserver.net] has joined #linuxcnc
[03:09:17] -!- swingley has quit [Ping timeout: 246 seconds]
[03:10:11] -!- sumpfralle has quit [Ping timeout: 250 seconds]
[03:12:21] -!- sumpfralle1 has quit [Ping timeout: 250 seconds]
[03:15:14] -!- fablab [fablab!~fablab@2001:a60:13c3:401:ec52:190b:c168:ec56] has joined #linuxcnc
[03:16:00] <Tom_itx> i'm aware of the pitfalls
[03:17:00] <Tom_itx> i may just use the live cd and copy the rest
[03:17:09] <Tom_itx> probably safer
[03:17:13] <Jymmm> Tom_itx: hang on
[03:17:56] <Tom_itx> it's taken all evening to free up a drive anyway
[03:18:02] <Tom_itx> i'll tackle it tomorrow
[03:18:52] <Jymmm> Tom_itx: partimage
[03:19:00] <Jymmm> or rsync
[03:19:22] -!- swingley has quit [Ping timeout: 240 seconds]
[03:19:59] <ffurrywol> I need to do some installing, but dicking around with computers has ended up pretty low on my to-do list these days.
[03:20:06] <Jymmm> and sfdisk to back/restore partition table
[03:21:08] <Jymmm> sysresccd.org ftw
[03:29:03] <ffurrywol> http://www.ebay.com/itm/Switch-3-way-LED-2700k-300L-800L-1100L-Warm-White-Dimmable-Lamp-bulb-/121507089674 liquid cooled? lol
[03:33:43] <alex4nder> man, I'd love a VMC
[03:33:44] ffurrywol is now known as furrywolf
[03:33:53] <alex4nder> I would just hate moving it ever
[03:35:01] * alex4nder looks at a 19,000 lb. matsuura for $9k
[03:36:29] * furrywolf would love a lot of things
[03:36:56] -!- FreezingCold has quit [Ping timeout: 256 seconds]
[03:37:02] <furrywolf> a vmc, enough money to get tooling for it, a house to put it in, a mature, intelligent, sane, good-with-a-strapon woman who knows cad/cam to use it with,...
[03:37:16] <alex4nder> don't get crazy
[03:38:50] <alex4nder> https://www.youtube.com/watch?v=3Ri5CQ5cIj8 <- that's pretty hilarious
[03:39:09] <zeeshan> what in the
[03:39:10] <zeeshan> f
[03:39:20] <zeeshan> thats a serious lathe
[03:39:34] <alex4nder> frankentaig
[03:41:12] <furrywolf> heh, that's a good idea. I could make my shoptask do that remarkably easily.
[03:41:47] <furrywolf> given as I have a 4" rotary table and an angle plate for it... lol
[03:42:59] <zeeshan> i just want a damn lathe
[03:43:02] <alex4nder> I'm wondering why they didn't use a standard spindle, and mount it back farther..
[03:43:04] <zeeshan> that works !
[03:43:48] <furrywolf> I'd guess the height of the rotary table, with space to clear tools, was higher than centerline...
[03:44:11] <alex4nder> furrywolf: I mean the one with the chuck attached
[03:44:21] <alex4nder> it's not a normal taig spindle...
[03:45:55] * furrywolf has no idea what a taig has
[03:46:19] -!- johtso has quit [Quit: Connection closed for inactivity]
[03:46:34] -!- nerdfiles has quit [Ping timeout: 244 seconds]
[03:47:26] <alex4nder> furrywolf:
http://tinyurl.com/oy67yc3
[03:49:27] <zeeshan> god
[03:49:29] <zeeshan> why cant this be near me
[03:49:30] <zeeshan> http://www.ebay.com/itm/MORI-SEIKI-TL-3-CNC-SLANT-BED-LATHE-TURNING-CENTER-/381182870535?pt=LH_DefaultDomain_0&hash=item58c0450407
[03:49:36] <zeeshan> i'd buy that in a fucking heart beat
[03:49:49] <alex4nder> yah jeez
[03:49:54] <alex4nder> that's basically free
[03:50:22] <furrywolf> it's an auction with three days left. the current price is not necessarily the selling price.
[03:50:30] <zeeshan> itll prolly sell for 3k
[03:50:34] <zeeshan> still good for that type of lathe
[03:50:43] <alex4nder> furrywolf: where could it go from there, that isn't 'free'
[03:50:58] <alex4nder> it's like scrap prices
[03:51:19] <furrywolf> it could well be scrap price. scrapyards often bid on equipment to crush...
[03:52:10] <zeeshan> well
[03:52:20] <zeeshan> its getting close to its scrap value
[03:52:23] <zeeshan> of $1475 :P
[03:52:32] <zeeshan> prolly actually past it
[03:52:36] <zeeshan> since someone would have to haul it
[03:53:43] <zeeshan> im hoping to work somewhere
[03:53:51] <zeeshan> one day they'll want to scrap a cnc lathe
[03:53:53] <zeeshan> and ill be like FU
[03:53:54] <zeeshan> its mine!
[03:56:49] <furrywolf> I don't know if there's a single business with a cnc lathe in the county I'm in. heh.
[03:57:16] <alex4nder> wut
[03:57:34] <furrywolf> all the local machine shops I've been to only have manual tools, with the exception of one that has a cnc plasma table.
[03:57:47] <furrywolf> (that no one knows how to use)
[03:57:54] -!- FreezingCold [FreezingCold!~FreezingC@135.0.41.14] has joined #linuxcnc
[03:59:08] <alex4nder> furrywolf: what country are you in?
[03:59:29] <furrywolf> humboldt, california. best known for growing pot, not producing useful items.
[03:59:38] <alex4nder> oh, county
[03:59:41] <alex4nder> werd
[04:00:09] <furrywolf> pretty much no factories or industry of any kind left. there's only two mills still running, and they have manual tools...
[04:00:24] <alex4nder> oregon and washington has a bunch still
[04:00:40] <furrywolf> we have something like fifty hydroponics stores, however.
[04:02:16] <furrywolf> fishing, and the industry that supported it, is dead and gone. the government did some program to buy out fishermen, and that was the end of that entire industry.
[04:02:53] -!- FreezingAlt [FreezingAlt!~FreezingC@135.0.41.14] has joined #linuxcnc
[04:03:00] <furrywolf> they overfished so heavily that boats were coming back empty, then the government fixed the problem by paying the fishermen not to fish...
[04:03:32] -!- FreezingCold has quit [Ping timeout: 246 seconds]
[04:03:34] <furrywolf> bbl, wolfy bedtime
[04:07:49] FreezingAlt is now known as FreezingCold
[04:10:14] -!- syyl has quit [Ping timeout: 265 seconds]
[04:12:30] -!- furrywolf has quit [Ping timeout: 252 seconds]
[04:20:52] -!- swingley has quit [Ping timeout: 265 seconds]
[04:25:49] -!- micges has quit [Ping timeout: 256 seconds]
[04:28:22] <roycroft> we have a good, strong fishery in oregon
[04:28:29] <roycroft> not like it used to be when we overfished
[04:28:33] <roycroft> but it's far from gone
[04:29:47] -!- nerdfiles has quit [Ping timeout: 256 seconds]
[04:30:54] -!- KimK_laptop [KimK_laptop!~Kim@ip68-102-30-143.ks.ok.cox.net] has joined #linuxcnc
[04:53:07] -!- xlogik has quit [Read error: No route to host]
[05:01:57] -!- anth0ny_ has quit [Quit: anth0ny_]
[05:07:21] -!- tris has quit [Quit: Leaving]
[05:12:14] -!- theorbtwo has quit [Remote host closed the connection]
[05:21:54] -!- swingley has quit [Ping timeout: 272 seconds]
[05:23:35] -!- tris [tris!tristan@65.50.210.4] has joined #linuxcnc
[05:35:17] -!- jerryitt has quit [Quit: Connection closed for inactivity]
[05:36:08] -!- memfrob has quit [Remote host closed the connection]
[05:43:45] -!- DGMurdockIII [DGMurdockIII!~dgmurdock@c-73-168-14-247.hsd1.in.comcast.net] has joined #linuxcnc
[05:49:56] -!- Miner_48er has quit [Ping timeout: 246 seconds]
[05:50:40] -!- theorbtwo [theorbtwo!~theorb@cpc3-swin16-2-0-cust28.3-1.cable.virginm.net] has joined #linuxcnc
[05:57:47] -!- ve7it has quit [Remote host closed the connection]
[06:21:56] -!- swingley has quit [Ping timeout: 252 seconds]
[06:33:10] -!- adam3999 has quit [Ping timeout: 256 seconds]
[06:34:45] -!- adam3999 [adam3999!~adam3999@pool-108-38-17-37.lsanca.fios.verizon.net] has joined #linuxcnc
[06:36:58] -!- [cube] has quit [Ping timeout: 252 seconds]
[06:42:17] -!- theorbtwo has quit [Read error: Connection reset by peer]
[06:43:36] -!- [cube] [[cube]!~cube@bas17-ottawa23-1279278196.dsl.bell.ca] has joined #linuxcnc
[06:53:50] -!- adam3999 has quit [Ping timeout: 252 seconds]
[06:54:02] -!- aakash_ [aakash_!~aakash@122.161.46.161] has joined #linuxcnc
[06:57:32] -!- theorbtwo [theorbtwo!~theorb@cpc3-swin16-2-0-cust28.3-1.cable.virginm.net] has joined #linuxcnc
[07:22:32] -!- swingley has quit [Ping timeout: 244 seconds]
[07:28:34] -!- Simoniou2 has quit [Ping timeout: 245 seconds]
[07:36:10] -!- dan2k3k4k5 has quit [Ping timeout: 272 seconds]
[07:42:05] -!- asdfasd [asdfasd!~332332@94.10.230.26] has joined #linuxcnc
[07:45:46] -!- skunkandroid has quit [Ping timeout: 264 seconds]
[07:51:38] -!- Deejay [Deejay!~Deejay@unaffiliated/dj9dj] has joined #linuxcnc
[07:51:47] <Deejay> moin
[07:52:27] <Tecan> aheeee
[07:52:40] -!- gambakufu has quit []
[07:56:52] -!- gambakufu [gambakufu!~ah@bzq-79-183-58-115.red.bezeqint.net] has joined #linuxcnc
[08:04:41] -!- gonzo_nb has quit [Remote host closed the connection]
[08:17:13] -!- mttr has quit [Ping timeout: 265 seconds]
[08:18:31] -!- Miner_48er has quit [Quit: Leaving]
[08:20:49] -!- jack16 has quit [Ping timeout: 264 seconds]
[08:23:14] -!- swingley has quit [Ping timeout: 246 seconds]
[08:24:57] -!- rob_h [rob_h!~robh@90.212.252.1] has joined #linuxcnc
[08:57:11] micges_ is now known as micges
[09:09:31] -!- Tecan has quit [Quit: Live Long And Phosphor!]
[09:14:47] -!- DGMurdockIII has quit [Quit: Leaving]
[09:23:39] -!- BellinganRoy [BellinganRoy!~Bellingan@host228-109-static.242-95-b.business.telecomitalia.it] has joined #linuxcnc
[09:23:52] -!- asdfasd has quit [Ping timeout: 240 seconds]
[09:24:01] -!- swingley has quit [Ping timeout: 252 seconds]
[09:27:19] -!- SpeedEvil has quit [Ping timeout: 252 seconds]
[09:28:50] -!- SpeedEvil [SpeedEvil!~quassel@tor/regular/SpeedEvil] has joined #linuxcnc
[10:00:15] -!- XXCoder has quit [Read error: Connection reset by peer]
[10:09:35] <Swapper> can i have a "run-in-place" install of linuxcnc and running my working "buildbot" version at the same time ?
[10:09:57] <Swapper> or is it better to run that on a other computer?
[10:19:02] -!- starbuck|ghost [starbuck|ghost!~irc@c-68-44-190-29.hsd1.in.comcast.net] has joined #linuxcnc
[10:19:27] -!- Valen [Valen!~Valen@c211-30-128-202.blktn6.nsw.optusnet.com.au] has joined #linuxcnc
[10:21:35] -!- TTN has quit [Ping timeout: 252 seconds]
[10:24:44] -!- swingley has quit [Ping timeout: 246 seconds]
[10:30:37] -!- [cube] has quit [Ping timeout: 265 seconds]
[10:35:32] -!- [cube] [[cube]!~cube@bas17-ottawa23-1242339686.dsl.bell.ca] has joined #linuxcnc
[10:37:52] -!- skunkworks has quit [Ping timeout: 240 seconds]
[10:53:38] -!- starbuck|ghost has quit [Ping timeout: 252 seconds]
[10:54:28] -!- sumpfralle [sumpfralle!~lars@erina.opennet-initiative.de] has joined #linuxcnc
[10:58:09] -!- sumpfralle1 [sumpfralle1!~lars@megumi.opennet-initiative.de] has joined #linuxcnc
[11:00:21] -!- sumpfralle has quit [Ping timeout: 250 seconds]
[11:11:00] <jthornton> you can only have one at a time running
[11:14:40] -!- Valen has quit [Remote host closed the connection]
[11:16:10] -!- skunkworks [skunkworks!~skunkwork@68-115-41-210.static.eucl.wi.charter.com] has joined #linuxcnc
[11:17:47] -!- nerdfiles has quit [Ping timeout: 256 seconds]
[11:19:26] -!- sumpfralle1 has quit [Ping timeout: 265 seconds]
[11:25:43] -!- swingley has quit [Ping timeout: 256 seconds]
[11:27:51] -!- Valen [Valen!~Valen@c211-30-128-202.blktn6.nsw.optusnet.com.au] has joined #linuxcnc
[11:29:21] -!- md-2 has quit [Read error: Connection reset by peer]
[11:30:51] <Swapper> yea i get that but only so the buildbot version dosent get broken to pices
[11:32:21] <jthornton> they live in different places so should live in harmony on your computer
[11:33:10] -!- archivist_herron has quit [Ping timeout: 264 seconds]
[11:33:14] <Swapper> thanks
[11:43:55] -!- robinsz has quit [Ping timeout: 255 seconds]
[11:44:27] <_methods> yeah i'm probably going to drop another hard drive in my main linuxcnc box so i can run a stable and master
[11:45:50] -!- archivist_herron [archivist_herron!~herron@herronwindows.co.uk] has joined #linuxcnc
[12:02:09] -!- Valen has quit [Remote host closed the connection]
[12:06:19] -!- dan2k3k4 has quit [Quit: Leaving]
[12:20:15] amnesic_away is now known as amnesic
[12:21:43] -!- analogLight has quit [Quit: ZNC - http://znc.in]
[12:26:49] -!- swingley has quit [Ping timeout: 264 seconds]
[12:31:44] -!- cox has quit [Remote host closed the connection]
[12:38:20] <_methods> http://news.softpedia.com/news/New-Linux-Kernel-Code-of-Conflict-Patch-Protects-Developers-from-Being-Abused-475454.shtml
[12:38:23] <_methods> lol
[12:38:35] <_methods> wah i'm a linux developer and i'm sensitive plz don't be mean to me
[12:42:33] -!- cox [cox!~quassel@188.226.208.53] has joined #linuxcnc
[12:46:40] -!- cox has quit [Remote host closed the connection]
[12:46:46] -!- cox [cox!~quassel@188.226.208.53] has joined #linuxcnc
[12:51:18] <CaptHindsight> other projects have been doing this as as well, you insensitive clod!
[12:51:19] <_methods> man what is this world coming too
[12:51:19] <_methods> this is what happens when you quit spanking kids
[12:51:34] <CaptHindsight> there's been a general loss in civility and sophistication in the west for the past few decades
[12:51:49] <archivist_herron> SpeedEvil, got an admission out of BT, their problem
[12:53:24] <SpeedEvil> archivist_herron: Woo!
[12:54:14] <archivist_herron> seems it is affecting lots of users
[12:54:55] <TekniQue> 12:38:35 < _methods> wah i'm a linux developer and i'm sensitive plz don't be mean to me
[12:54:58] <TekniQue> lol
[12:55:09] <archivist_herron> he wants a cuddle
[12:55:15] <TekniQue> translation: plz don't e-mail me, Linus
[12:55:29] <_methods> heheh
[12:55:34] <TekniQue> because Linus Torvalds is source of 100% of the abuse on the kernel mailing lists
[12:55:49] <_methods> that's why i thought it was especially entertaining
[12:56:04] <_methods> he's bred that into the system
[12:56:13] <TekniQue> Mauro, SHUT THE FUCK UP
[12:56:33] <TekniQue> my all time favorite kernel mailing list e-mail
[12:57:00] <_methods> well it covers all the bases
[12:57:10] <_methods> clear, concise, and to the point lol
[12:57:44] <CaptHindsight> I figured that some that cared would write a filter to catch "bad" words and replace them with terms like "doody head"
[12:58:18] <TekniQue> in the case of Mauro, I agree with Linus
[12:58:30] <TekniQue> Mauro committed something that broke a lot of user space code
[12:58:51] <TekniQue> and Mauro defended it saying that the interface was never documented to behave the way it did
[12:59:48] <CaptHindsight> thats the other problem, getting through to some people with the fewest number of words that have disabilities that limit their ability to pick up on subtleties
[13:00:49] <TekniQue> true
[13:00:50] <CaptHindsight> or people that just intentionally ignore everyone else until the terminology escalates to this level
[13:01:32] <malcom2073> The problem is, the loss of civility is due to the loss of sophistication.
[13:02:10] <malcom2073> Plus, the general air of elitism present in some open source project management.
[13:03:29] <CaptHindsight> it's the herd mentality that creeps in, some people just decide to vent since everyone else is doing it even though they do know better (Linus)
[13:10:20] <CaptHindsight> everyone else is doing it is the excuse for less than best efforts from many professionals, best effort what's that?
[13:10:20] <_methods> i like to call it trickle down douche-enomics
[13:10:20] <_methods> when the guy at the top is being a douche it just trickles down lol
[13:10:20] <TekniQue> I call it cancer
[13:10:20] <CaptHindsight> top and sides
[13:10:20] <TekniQue> that's how it spreads
[13:10:21] <CaptHindsight> you think the KML is silly, look what coreboot did
http://www.coreboot.org/Code_of_Conduct
[13:10:52] <TekniQue> It's not the user's fault if something goes wrong.
[13:10:56] <TekniQue> yeah fucking right it is
[13:15:03] -!- tom_o_t has quit [Ping timeout: 265 seconds]
[13:15:03] amnesic is now known as amnesic_away
[13:15:03] <cradek> sometimes it is, sometimes it isn't
[13:15:03] <TekniQue> exactly
[13:15:04] <cradek> either extreme of always/never is very silly
[13:16:33] -!- Simoniou1 [Simoniou1!~Simonious@h75-100-216-108.pqlkmn.broadband.dynamic.tds.net] has joined #linuxcnc
[13:16:58] <cradek> but good for them for trying to write that - it looks hard to get right
[13:17:12] <CaptHindsight> the FU Linux gave nvidia might be why they have the most open ARM SOC at the moment
[13:18:15] <CaptHindsight> well nobody said or did anything about the behavior until now, so now they have to write something up
[13:23:47] -!- tom_o_t has quit [Changing host]
[13:26:31] -!- amiri has quit [Ping timeout: 255 seconds]
[13:27:02] -!- swingley has quit [Ping timeout: 246 seconds]
[13:27:17] amnesic_away is now known as amnesic
[13:43:39] <malcom2073> I totally get their reasoning for putting that. To stop people from being abrasive to users regardless of fault
[13:44:56] <malcom2073> ive seen projects where the first inclination is the call the user an idiot, and while the user may be an idiot, smart until proven dumb is a better stance to take.
[13:45:00] -!- Roguish [Roguish!~chatzilla@c-50-143-183-159.hsd1.ca.comcast.net] has joined #linuxcnc
[13:45:56] <malcom2073> Easier to tell devs to treat all faults as their own, than to try and get them to understand that apparently complicated concept.
[13:51:00] -!- syyl [syyl!~sg@p200300632C236D16096C5B5516071149.dip0.t-ipconnect.de] has joined #linuxcnc
[13:52:27] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[14:00:01] -!- FinboySlick [FinboySlick!~shark@74.117.40.10] has joined #linuxcnc
[14:17:43] -!- kb8wmc [kb8wmc!~kb8wmc@64.25.194.29] has joined #linuxcnc
[14:21:10] -!- nerdfiles has quit [Ping timeout: 265 seconds]
[14:26:37] -!- miss0r|shop [miss0r|shop!~miss0r@87-59-179-253-dynamic.dk.customer.tdc.net] has joined #linuxcnc
[14:27:56] -!- swingley has quit [Ping timeout: 246 seconds]
[14:30:28] -!- anth0ny_ has quit [Quit: anth0ny_]
[14:41:17] -!- Simoniou1 has quit [Ping timeout: 246 seconds]
[14:45:56] -!- anth0ny_ has quit [Quit: anth0ny_]
[14:47:45] -!- mozmck [mozmck!~moses@67.210.159.245] has parted #linuxcnc
[14:47:47] -!- moorbo has quit [Ping timeout: 252 seconds]
[14:51:41] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[14:58:44] -!- kwallace has quit [Ping timeout: 246 seconds]
[15:01:45] -!- asdfasd [asdfasd!~332332@94.10.230.26] has joined #linuxcnc
[15:12:00] <ssi> _methods: I made another furnace last night and melted some aluminum with 80 amps, and didn't kill my firebrick! :D
[15:12:03] <ssi> I need to get some flux
[15:13:03] <SpeedEvil> Woo.
[15:17:00] <DaViruz> ssi: arc furnace?
[15:17:04] <ssi> yeah
[15:17:10] <DaViruz> neat
[15:17:20] <SpeedEvil> carbon arc?
[15:17:37] <ssi> yes
[15:18:04] -!- DGMurdockIII [DGMurdockIII!~dgmurdock@c-73-168-14-247.hsd1.in.comcast.net] has joined #linuxcnc
[15:18:26] <_methods> ah sweet
[15:18:30] <_methods> did you try the borax?
[15:18:35] <_methods> i got the fire bricks
[15:18:35] <ssi> haven't gotten any yet
[15:18:43] <_methods> i have borax at the house
[15:18:57] <_methods> i was busy cleaning my free surface plate last night lol
[15:19:09] <ssi> I threw four 1" long chunks of 20mm tslot extrusion in there and heated them
[15:19:19] <ssi> they collapsed but it didn't really look like they'd liquified
[15:19:22] <ssi> threw a bunch of chips on top
[15:19:32] <ssi> then I started stirring and realized that there was just a solid layer of crud on top
[15:19:36] <ssi> but underneath it was liquid
[15:19:36] <_methods> so 80amps isn't quite enough?
[15:19:42] <_methods> ahh
[15:19:51] <DaViruz> you need magnetic stirring
[15:19:59] <DaViruz> though i don't know if that works with aluminium
[15:20:14] <ssi> I'm thinking flux will make the crud dissolve and flow out easier
[15:20:17] <ssi> and be easier to skim
[15:20:27] <ssi> 80A works good but it's hard to keep a consistent arc
[15:20:40] <_methods> might have to make a cnc feeder
[15:20:47] <DaViruz> you have some sort of height control?
[15:20:51] <DaViruz> automatic
[15:20:52] <_methods> feed the electrodes into each other
[15:20:58] <ssi> yeah, my hands
[15:21:01] <_methods> heheh
[15:21:19] <_methods> ssi model 10
[15:21:23] <ssi> :D
[15:21:33] <_methods> 10i
[15:21:34] <_methods> lol
[15:21:45] <ssi> I also make a pretty good autopilot
[15:22:07] <_methods> cnc pilot/arc furnace
[15:22:35] <ssi> https://pbs.twimg.com/media/B_04Ph7XEAIN8Rr.jpg:large
[15:22:43] <ssi> flew tight formation like that for 350 miles yesterday
[15:22:50] <ssi> shit takes a LOT of concentration and fine motor control
[15:23:02] <ssi> and the RV I was in is extremely sensitive in pitch
[15:23:04] <_methods> i bet
[15:23:06] <DaViruz> i wonder if you get some free magnetic stirring from a three phase arc furnace
[15:23:15] <ssi> so it's laying my arm on my leg, holding the stick with thumb and forefinger
[15:23:17] <_methods> all that space up there and you want to fly right next to each other.........
[15:23:22] <ssi> the EFIS has a rate of change of airspeed indicator
[15:23:31] <ssi> and I basically fly that to null any change in airspeed for fine pitch control
[15:23:36] <ssi> trying to maintain +/- 1kt
[15:23:37] <ssi> it's HARD
[15:23:58] <ssi> a little bit of pitch up and I'm slowing down, and he has to throttle back to hold me... then on the corresponding pitch down, I'd run away from him
[15:24:10] -!- moorbo has quit [Ping timeout: 244 seconds]
[15:24:14] <_methods> you need a tow rope
[15:24:18] <_methods> lol
[15:24:22] <ssi> hah that's a horrible idea :D
[15:24:31] <ssi> the pitts is an awful glider :)
[15:24:32] <_methods> i'm full of good stuff like that lol
[15:24:37] -!- dirty_d [dirty_d!~dirty_d@50-205-178-174-static.hfc.comcastbusiness.net] has joined #linuxcnc
[15:24:53] <ssi> it flies on thrust and willpower almost exclusively :D
[15:25:16] <_methods> so it's a helicopter
[15:25:21] <DaViruz> i read a pretty interresting story on formation flying in sabres
[15:25:45] <DaViruz> http://oppositelock.jalopnik.com/fly-pasts-497272320
[15:25:54] <DaViruz> well worth a read
[15:26:02] <ssi> ever seen the sabredance?
[15:26:08] <DaViruz> i have not
[15:26:36] <ssi> https://www.youtube.com/watch?v=mZL0x-gEDM8
[15:26:40] <DaViruz> i'm imagining that tubine lag makes formation flying even more of a bitch
[15:26:45] <ssi> yuup
[15:28:01] <DaViruz> heard brian schuls story on when he severely stalled the sr71 blackbird?
[15:28:10] <ssi> yeah
[15:28:15] <DaViruz> during a tower flyby at low altitude..
[15:28:16] <DaViruz> :)
[15:28:24] <ssi> friend of mine has a copy of sled driver
[15:28:28] <ssi> they're hard to come by
[15:28:30] <DaViruz> yeah
[15:28:31] <ssi> they go for like $500 now
[15:28:37] -!- swingley has quit [Ping timeout: 245 seconds]
[15:29:07] -!- phantoxeD has quit []
[15:29:51] <_Sync_> wtfucking shit
[15:30:00] <DaViruz> i recently got myself a copy of skunk works, haven't read it yet though
[15:35:58] <Rab> PDF of Sled Driver isn't too hard to find.
[15:40:15] -!- robinsz [robinsz!~robin@88.97.63.122] has joined #linuxcnc
[15:44:08] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[15:44:52] -!- robinsz has quit [Ping timeout: 240 seconds]
[15:49:42] -!- ktchk [ktchk!~eddie6929@n219073007134.netvigator.com] has joined #linuxcnc
[15:51:38] -!- ktchk has quit [Read error: Connection reset by peer]
[15:52:48] -!- starbuck|ghost [starbuck|ghost!~irc@c-68-44-190-29.hsd1.in.comcast.net] has joined #linuxcnc
[15:55:02] -!- quiqua has quit [Quit: quiqua]
[15:55:23] <Cromaglious> fried something in the yoocnc pw3618 power supply board last night
[15:55:59] -!- FreezingCold has quit [Ping timeout: 252 seconds]
[15:59:03] <archivist> chinese low cost supplies and flames go together
[15:59:20] <archivist> it is a free feature they add on
[15:59:59] <archivist> I had one fry in spectacular fashion one day
[16:00:27] <Cromaglious> true.. until I get another power supply... and or PWM spindle control board...
[16:05:42] <Rab> MeanWell, the Brand You Trust.
[16:07:14] <archivist> to fry
[16:07:36] <Cromaglious> looking at the schematic diagram... I'm burning the 100ohm resister going through the EL817 opticoupler which gets it power from the voltage drop across the R3 and R4 1ohm 2w resisters off the mosfett on the negative side of the spindle
[16:08:15] <archivist> 1 ohm and opto in the same sentence ?
[16:08:25] <Cromaglious> so a voltage drop across .5 ohm that's enough to fry a 1/4w 100ohm resister
[16:08:43] <Cromaglious> I was reading 57v last night
[16:10:01] <ssi> I've had good luck with meanwell supplies
[16:10:57] -!- toastydeath has quit [Read error: Connection reset by peer]
[16:11:11] -!- toastydeath [toastydeath!~toast@c-69-244-86-195.hsd1.md.comcast.net] has joined #linuxcnc
[16:11:24] -!- syyl_ [syyl_!~sg@p200300632C236D16096C5B5516071149.dip0.t-ipconnect.de] has joined #linuxcnc
[16:11:26] <archivist> Cromaglious, I think people will need to see the circuit
[16:11:42] -!- DGMurdockIII has quit [Ping timeout: 244 seconds]
[16:13:28] <CaptHindsight> heh Meanwell vs DoWell, the best of intentions :)
[16:13:34] <ssi> lolol
[16:14:16] -!- syyl has quit [Ping timeout: 265 seconds]
[16:14:16] -!- djinni`_ has quit [Ping timeout: 265 seconds]
[16:14:23] -!- Guest77845 [Guest77845!~chatzilla@50.255.22.90] has joined #linuxcnc
[16:14:23] Loetmichel2 is now known as Loetmichel
[16:14:45] -!- tom_o_t has quit [Ping timeout: 265 seconds]
[16:14:45] -!- sliptonic has quit [Ping timeout: 265 seconds]
[16:15:19] -!- djinni` [djinni`!~djinni@105.ip-167-114-152.net] has joined #linuxcnc
[16:15:31] -!- Guest77845 has quit [Client Quit]
[16:15:34] -!- tom_o_t has quit [Changing host]
[16:15:58] <archivist> BurnsWell
[16:16:50] -!- sliptonic [sliptonic!sliptonic@2600:3c00::f03c:91ff:fe89:1c2c] has joined #linuxcnc
[16:17:17] <Cromaglious> hmm 32 watts.. that 57v over 100 ohms I'll have to check the 1ohm resisters
[16:18:02] <Cromaglious> http://itslinux.org/pics/yoocnc.html
[16:18:07] <archivist> Cromaglious, the 1ohm may not have felt any pain
[16:20:52] -!- moorbo has quit [Read error: Connection reset by peer]
[16:21:30] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[16:22:51] <Cromaglious> the 100ohm resister is top right in the diagram straight to the left of the stop pin
[16:23:04] <archivist> I cannot see the web :(
[16:23:09] <Cromaglious> damn
[16:23:24] <Cromaglious> brb CUppa char need tending to
[16:24:05] <skunkworks> those caps to the right of the 100ohm resistor are grounded? that doesn't seem right
[16:24:13] -!- moorbo has quit [Client Quit]
[16:25:39] <skunkworks> if they are - that is your problem...
[16:25:44] <Cromaglious> no they are actually going to the other trace right below them in the diagram
[16:25:52] -!- DGMurdockIII [DGMurdockIII!~dgmurdock@c-73-168-14-247.hsd1.in.comcast.net] has joined #linuxcnc
[16:29:16] -!- swingley has quit [Read error: Connection reset by peer]
[16:32:12] -!- mttr [mttr!~mttr@0016019a1697.cpe.westmancom.com] has joined #linuxcnc
[16:39:23] <pcw_home> 100K seems closer to the right value
[16:41:27] -!- eFuchs_mobil [eFuchs_mobil!~voodoo@2001:4dd0:ff00:8d54:cc3e:acff:fe5e:85e4] has joined #linuxcnc
[16:43:58] <Cromaglious> ok updated diagram reload
[16:46:15] -!- FreezingCold [FreezingCold!~FreezingC@135.0.41.14] has joined #linuxcnc
[16:49:41] <Cromaglious> ok possible replacement for the motor control side at the bottom of
http://itslinux.org/pics/yoocnc.html
[16:54:11] <Roguish> pcw_home: would you look over my next post in the forum, please.
[16:54:22] <zeeshan> lol
[16:55:13] <Cromaglious> I'm liking the 15amp better but it's DC only... I can take that from the PW3618
[16:55:27] -!- Nick001-shop [Nick001-shop!~chatzilla@hrbg-74-46-17-65-pppoe.dsl.hrbg.epix.net] has joined #linuxcnc
[17:15:33] -!- PetefromTn_ [PetefromTn_!~IceChat9@75-136-60-251.dhcp.jcsn.tn.charter.com] has joined #linuxcnc
[17:21:03] -!- miss0r|shop has quit []
[17:26:15] -!- khalil has quit [Client Quit]
[17:27:40] -!- eFuchs_mobil has quit [Ping timeout: 256 seconds]
[17:29:07] -!- eFuchs_mobil [eFuchs_mobil!~voodoo@2001:4dd0:ff00:8d54:cc3e:acff:fe5e:85e4] has joined #linuxcnc
[17:33:28] -!- swingley_ has quit [Remote host closed the connection]
[17:35:36] <CaptHindsight> will this run the machinekit stepgens for the PRU?
https://www.kickstarter.com/projects/1177488680/bbp-making-your-3d-printer-faster
[17:37:04] <CaptHindsight> it must, it's the same ARM SOC
[17:37:08] <CaptHindsight> as the BBB
[17:38:30] <pcw_home> probably just a matter of setting up the pinouts
[17:39:29] <malcom2073> Nice
[17:40:05] <malcom2073> Nice, and fairly inexpensive.
[17:40:34] <CaptHindsight> I figured that someone would do this with one of the more recent TI SOC's with the PRU
[17:41:06] <malcom2073> I wonder if their stuff will be open source, I'd be interested in giving it a shot on the BBB
[17:41:30] <CaptHindsight> it doesn't look like it
[17:41:54] <ssi> I wouldn't mind trying that
[17:41:55] <CaptHindsight> http://linuxgizmos.com/sitara-am437x-dev-kit-targets-linux-based-industrial-apps/ this new Sitara also has a fast GPU
[17:42:03] <ssi> but I don't want to send them money and then wait and hope to receive something
[17:42:06] <malcom2073> It's open hardware, doesn't mention open software
[17:42:23] <CaptHindsight> are the schematics up somewhere?
[17:42:38] <malcom2073> "soon"
[17:42:48] <malcom2073> So it *may* be open hardware heh
[17:42:53] <CaptHindsight> I could spin a board using the AM437x
[17:43:05] <ssi> CaptHindsight: do it
[17:43:20] <ssi> spin a board with an AM437x and an s6lx9
[17:43:26] <ssi> and a pair of 26 pin IDC headers
[17:43:34] <CaptHindsight> or imx6 with s6lx9?
[17:43:59] <ssi> either, but I'd prefer the sitara
[17:44:39] <CaptHindsight> why? (he asked in a non-confrontational way)
[17:45:30] -!- cox has quit [Remote host closed the connection]
[17:45:35] <malcom2073> I'm still hoping for a good single board solution, I still have some hope heh
[17:45:37] -!- XXCoder [XXCoder!~XXCoder@c-24-19-85-77.hsd1.wa.comcast.net] has joined #linuxcnc
[17:45:41] <CaptHindsight> and steer the software back to linuxcnc
[17:45:52] <CaptHindsight> http://www.ti.com/product/am4379
[17:46:04] <ssi> I like the 33xx series sitara, the documentation is good
[17:46:19] <ssi> if the 43xx series is as good as the 33xx but with enough gpu power to run axis well, I think it'd be a winner
[17:46:49] <CaptHindsight> I'd only make it an SOC with a GPU fast enough to support a decent display size and frame rate
[17:46:50] <malcom2073> Thats the big thing that kills the BBB with machienkit, it can't run axis well
[17:47:27] <CaptHindsight> http://www.ti.com/general/docs/datasheetdiagram.tsp?genericPartNumber=AM4379&diagramId=50422
[17:47:33] <ssi> I personally don't care about the pru stepgens, etc
[17:47:57] <ssi> I think having an s6lx9 onboard running hm2, with externally attached mesa superport daughterboards would be a winner
[17:48:06] <CaptHindsight> ssi: are the imx6 docs lacking much? it also has PCIe
[17:48:28] <ssi> I dunno... I don't really know anything about the imx6
[17:48:33] <CaptHindsight> I could make that pretty quick
[17:48:37] <ssi> I've just done a lot of work with the sitara and it's very good
[17:48:46] <ssi> what EDA package do you use
[17:49:06] <CaptHindsight> capture + allegro mostly
[17:49:25] <ssi> bluh ok
[17:50:49] <CaptHindsight> http://imagebin.ca/v/1uJ6OZ4wgxeN boards that regularly are this dense or more
[17:52:09] -!- cox [cox!~quassel@188.226.208.53] has joined #linuxcnc
[17:52:59] <CaptHindsight> http://www.freescale.com/webapp/sps/site/taxonomy.jsp?code=IMX6X_SERIES&cof=0&am=0
[17:54:08] <CaptHindsight> well we already know that the TI devices run Linuxcnc
[17:54:28] <CaptHindsight> the imx6 should work, but it's not been done
[17:55:10] <CaptHindsight> are there gerbers for the TI dev board?
[17:56:38] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[17:57:24] -!- cox has quit [Remote host closed the connection]
[17:58:34] <CaptHindsight> http://www.ti.com/lit/df/tidc823/tidc823.zip yes there are
[17:59:09] -!- danylevskyi has quit [Ping timeout: 265 seconds]
[18:00:07] <CaptHindsight> well one reason for not posting designs files before you crowdfund is that some small co's will just take your design and run with it before you do
[18:02:01] <CaptHindsight> http://processors.wiki.ti.com/index.php/Sitara_AM437x_Portal
[18:02:15] <pcw_home> Jepler had linuxcnc running on a a Odriod
[18:02:54] <CaptHindsight> I don't recall it being a problem to compile or get running either
[18:03:03] -!- cox [cox!~quassel@188.226.208.53] has joined #linuxcnc
[18:03:03] -!- cox has quit [Read error: Connection reset by peer]
[18:04:56] <pcw_home> Sitara is still about a P3 performance wise, not a good choice if you have fancy hal stuff
[18:05:15] <CaptHindsight> 4 core imx6?
[18:05:28] <CaptHindsight> the 1-4 core versions all have the same pinouts
[18:05:42] <zeeshan> http://c4.staticflickr.com/8/7599/16160843563_dc50b272de_k.jpg
[18:05:58] <zeeshan> it'll be another late night in here tonight :[
[18:06:41] <Loetmichel> zeeshan: whats that wooden donut over there?
[18:07:02] <zeeshan> wind tunnel
[18:07:15] <CaptHindsight> TI uses capture and allegro as well
[18:07:43] <zeeshan> https://www.flickr.com/photos/128539016@N05/16779679362/in/photostream/
[18:07:48] <zeeshan> this is what i was cutting for students yesterday
[18:07:57] <zeeshan> they have some interesting designs
[18:07:57] <zeeshan> they
[18:07:59] <zeeshan> they
[18:08:06] <zeeshan> 'dsadkljaasjd .. they're building a stair climber
[18:08:36] <Tom_itx> zeeshan i went with 7... it comes with the update for 10
[18:08:42] <zeeshan> nice!
[18:08:47] <Tom_itx> pro
[18:08:55] <zeeshan> how much?
[18:08:57] -!- theorbtwo has quit [Remote host closed the connection]
[18:09:04] <Tom_itx> 150
[18:09:09] <zeeshan> not bad at all.
[18:09:52] <Tom_itx> now i gotta find a drive to put it on
[18:10:04] <CaptHindsight> zeeshan: you have a project there
[18:10:13] <zeeshan> no
[18:10:16] <zeeshan> just helping students
[18:10:31] <zeeshan> i was thinking of making myself a small bridge model
[18:10:35] <CaptHindsight> sorry projet, damn auto correct
[18:10:46] -!- karavanjo has quit [Ping timeout: 272 seconds]
[18:10:49] <zeeshan> yes we do
[18:10:51] <CaptHindsight> project hd3000
[18:11:00] <zeeshan> thats a DLP type printer right?
[18:11:16] <zeeshan> i just know it sprays some ink
[18:11:19] <CaptHindsight> no, inkjet
[18:11:24] <zeeshan> and cures it in plane.
[18:11:28] <zeeshan> .001" thick planes
[18:11:49] <Tom_itx> i wonder if an oem disk will do an upgrade
[18:11:53] <CaptHindsight> yeah, you could use it to print your sample parts
[18:12:07] <zeeshan> for my specimens?!
[18:12:35] <CaptHindsight> yes, they hide the fact that it's an inkjet
[18:13:04] <zeeshan> well if that thing can spray your polymer you sent me
[18:13:07] <zeeshan> the airbrush will also :)
[18:13:12] <zeeshan> and make a random pattern for me!
[18:13:30] <CaptHindsight> almost, it's not blended for that right now
[18:13:34] <zeeshan> o
[18:13:49] <CaptHindsight> but does it have a white?
[18:14:11] <CaptHindsight> http://www.3dcreationlab.co.uk/pdfs/projet-hd-3000.pdf
[18:14:26] -!- theorbtwo [theorbtwo!~theorb@cpc3-swin16-2-0-cust28.3-1.cable.virginm.net] has joined #linuxcnc
[18:15:11] <CaptHindsight> zeeshan: you might have to fool it to print your specimens
[18:15:59] <CaptHindsight> if it can start printing from right above your specimen then it's simple ...
[18:16:25] <zeeshan> needs hax
[18:16:43] <CaptHindsight> if it can't then you'll have to print something the same thickness and interrupt the print and then replace the print with your specimen
[18:17:40] <zeeshan> easier to air brush it :)
[18:17:49] <CaptHindsight> maybe :)
[18:18:36] -!- sumpfralle [sumpfralle!~lars@megumi.opennet-initiative.de] has joined #linuxcnc
[18:20:35] <Cromaglious> http://itslinux.org/cnc/ is now my cnc dir
[18:21:12] <Cromaglious> http://itslinux.org/cnc/psu_and_spindle_controller_schematic.PNG better diagram of the PS
[18:21:12] <PetefromTn_> Frak...
[18:21:56] <ssi> peeeet
[18:22:12] <Cromaglious> hmm R7 looks like it really need to go away
[18:22:41] <PetefromTn_> My most promising large company customer just came to me with a bunch of parts they need machined. four out of five are freaking CNC lathe parts and I am nowhere near to a CNC lathe being operational..
[18:22:49] <ssi> :(
[18:22:50] <Cromaglious> 4n25 pin 6 is the base and they have a 47Kohm resister to ground on it
[18:23:20] <CaptHindsight> ssi: the imx6 docs are very complete
[18:23:25] <ssi> ok
[18:23:26] <PetefromTn_> I quoted the plate parts and got that job it sounds like
[18:23:31] <ssi> if it'll do what we need, have at it
[18:23:53] <PetefromTn_> but I sure wish I had a freaking manual lathe here right now I would make them the hard way...
[18:24:05] <zeeshan> doh pete
[18:24:22] <ssi> PetefromTn_: come down and use my southbend if you want
[18:24:24] <CaptHindsight> http://www.freescale.com/webapp/sps/site/prod_summary.jsp?code=i.MX6Q&fpsp=1&tab=Design_Tools_Tab
[18:24:29] <zeeshan> ssi
[18:24:33] <zeeshan> how much did you get that chnc for?
[18:24:42] <ssi> mine's not a C
[18:24:47] <ssi> but i paid $1000 for it
[18:24:47] <CaptHindsight> http://www.freescale.com/webapp/sps/site/prod_summary.jsp?code=i.MX6Q&fpsp=1&tab=Documentation_Tab
[18:24:48] <zeeshan> o
[18:25:07] <ssi> PetefromTn_, zeeshan: my day yesterday:
https://pbs.twimg.com/media/B_04Ph7XEAIN8Rr.jpg:large
[18:25:09] <PetefromTn_> thats a kind offer man...
[18:25:20] <pcw_home> R7 is a speedup resistor
[18:25:31] <zeeshan> ssi nice!!
[18:25:31] <zeeshan> LOL
[18:25:33] <PetefromTn_> yeah I saw that on Facebook
[18:25:44] <PetefromTn_> so your plane is operational now?
[18:25:47] <pcw_home> (makes the OPTO faster by draining base charge)
[18:25:53] <ssi> nah neither of those is mine :D
[18:26:05] <CaptHindsight> ssi: you in the red one?
[18:26:08] <ssi> yea
[18:26:21] -!- jesseg has quit [Ping timeout: 276 seconds]
[18:26:27] <Cromaglious> Mach3 is controlling the speed worth a hoot right now...
[18:26:33] <Cromaglious> Mach3 isn't controlling the speed worth a hoot right now...
[18:27:12] <PetefromTn_> Mach3 doesn't control shit worth a hoot..
[18:27:30] <Cromaglious> also think I need to up the 100ohm resister at R5 to a 470ohm 1/2w
[18:28:49] <PetefromTn_> ssi you at work right now?
[18:28:53] <ssi> yeah
[18:29:02] <PetefromTn_> Ok I was gonna call you on phone
[18:29:08] <ssi> you can if you want
[18:29:13] <PetefromTn_> oh okay
[18:29:19] <CaptHindsight> 2 years ago the imx6 pricing was
http://pastebin.ca/2954732
[18:29:43] <anonimasu> hello
[18:29:50] <anonimasu> I am having a bit of config issue..
[18:29:51] <Cromaglious> or take it out completely
[18:29:55] <anonimasu> how the hell do i set up accel properly
[18:29:58] <anonimasu> (I want 0.5g)
[18:30:13] -!- robinsz [robinsz!~robin@88.97.63.122] has joined #linuxcnc
[18:30:26] <cradek> are you asking how to convert 0.5g into in/sec2 or mm/sec2?
[18:31:05] <cradek> looks like the answers are 190 and 4900
[18:31:31] <CaptHindsight> how about in mm/sec/sec? :)
[18:31:42] <Cromaglious> 4900
[18:31:44] <cradek> 4900
[18:32:02] <Cromaglious> mm/sec^2
[18:32:25] <zeeshan> .5 g means .5 * 9.81 m/s^2
[18:32:42] <CaptHindsight> earth G's?
[18:32:45] <zeeshan> yea :P
[18:34:54] <XXCoder> G is close to earth average G yes
[18:35:07] <CaptHindsight> ok so, imx6 with spartan6 with Anything I/O connectors and pinouts
[18:35:12] <CaptHindsight> anything else?
[18:35:13] <XXCoder> theres places where its more or less than g
[18:36:38] <ssi> CaptHindsight: the 50 pin io headers, or 26 pin superport headers?
[18:36:52] <CaptHindsight> maybe one board layout with option of anything I/O or onboard <3A stepper drivers
[18:36:52] -!- f1oat3 [f1oat3!~f1oat@AMontsouris-553-1-40-185.w92-151.abo.wanadoo.fr] has joined #linuxcnc
[18:36:59] <CaptHindsight> ssi: thats what I'm asking
[18:37:19] <ssi> I'd lean toward the 26 pin superport headers
[18:37:43] <ssi> basically like a singleboard computer with integrated 6i25
[18:38:41] <CaptHindsight> yeah, you want both the header for internal wiring and the external conn
[18:39:02] <ssi> the board doesn't necessarily need to carry the DB25
[18:39:39] <ssi> the hm2 firmware provides for two ports; 5i25 has one exposed as a DB25 and one as an IDC26
[18:39:47] <ssi> your board could just have two IDC26 and that would be fine
[18:39:49] <CaptHindsight> true, would be more flexible if there are no external connectors
[18:40:08] -!- tekniq [tekniq!~tekniq@198.179.137.221] has joined #linuxcnc
[18:40:21] -!- tekniq has quit [Client Quit]
[18:40:26] <CaptHindsight> then you're not forced to have a set enclosure design
[18:40:33] <ssi> yes
[18:40:34] <CaptHindsight> or openings anyway
[18:40:54] <CaptHindsight> and you can get adapter cables
[18:41:07] <ssi> yeah they're $3 from amazon :P
[18:41:44] <CaptHindsight> http://www.freescale.com/files/graphic/block_diagram/IMX6Q_BD_IMG.jpg PCIe 2.0, 1 lane
[18:42:04] <ssi> that works fine
[18:42:14] <ssi> if you can pin it the same as the 6i25 then the hm2 firmwares should be compatible
[18:42:16] <CaptHindsight> plus you could use hm2_eth for another fpga
[18:42:29] <ssi> does it have two eth phys?
[18:43:11] -!- eFuchs_mobil has quit [Quit: No Ping reply in 180 seconds.]
[18:43:26] <CaptHindsight> only one MAC as I recall.... checking the data sheet
[18:43:46] <ssi> I think you really need to have a dedicated ethernet for hm2_eth
[18:44:01] <ssi> and I certainly want to have an available eth for network connectivity
[18:44:05] <ssi> or maybe wifi
[18:44:13] <ssi> but that's just getting greedy :)
[18:44:17] -!- eFuchs_mobil [eFuchs_mobil!~voodoo@eduroam172-093.wlan.uni-ulm.de] has joined #linuxcnc
[18:44:25] <ssi> wifi would be amazing though; wiring a huge shop for ethernet is a hassle
[18:44:28] <CaptHindsight> wifi as a dingle
[18:44:31] <CaptHindsight> dongle
[18:44:34] <ssi> luldingle
[18:45:44] -!- syyl [syyl!~sg@p200300632C236D16096C5B5516071149.dip0.t-ipconnect.de] has joined #linuxcnc
[18:46:20] <CaptHindsight> only one 10/100/1000 Mbps Ethernet MAC
[18:46:34] <pcw_home> WIFI or USB/Ethernet should be fine for the non-rt channel
[18:46:43] <ssi> yeah
[18:46:53] <ssi> dedicated gbit for rt, and whatever else for lan
[18:47:00] <CaptHindsight> yeah, use the MAC for RT, USB ethernet for lan
[18:47:03] <ssi> but onboard wifi would be sooo sooo nice :D
[18:47:11] <ssi> maybe rev2 :)
[18:47:20] <CaptHindsight> why not just a dongle?
[18:47:28] <pcw_home> yeah USB/WIFI
[18:47:32] <CaptHindsight> people get all worked up over blob free
[18:47:36] <ssi> dongles are annoying
[18:47:53] <ssi> trying to find one that works easily in linux, etc
[18:48:01] <ssi> I dunno, I haven't fought that monster in a long time
[18:48:08] -!- syyl_ has quit [Ping timeout: 256 seconds]
[18:48:13] <CaptHindsight> oh and SATA-II
[18:48:25] <ssi> ooh while we're throwing shit at the wall
[18:48:32] <ssi> onboard ssd storage?!
[18:48:33] <ssi> :D
[18:48:35] -!- BellinganRoy has quit [Quit: Konversation terminated!]
[18:48:47] <CaptHindsight> no prob with SATA
[18:49:16] <CaptHindsight> also has MMC/SD
[18:49:28] <ssi> mmc would be perfectly adequate
[18:50:32] <CaptHindsight> I'll put it up on openlunchbox
[18:50:36] <ssi> ok
[18:51:00] <ssi> I don't even allegro or else I'd halp
[18:51:16] <CaptHindsight> u-boot works already
[18:51:37] <CaptHindsight> and there are several working Linux distis/images
[18:51:57] -!- jvrousseau has quit [Ping timeout: 245 seconds]
[18:52:13] <CaptHindsight> preempt_rt is also working
[18:52:22] -!- moorbo has quit [Remote host closed the connection]
[18:52:36] <CaptHindsight> guess debian would make things easiest for people here
[18:52:52] -!- dirty_d has quit [Quit: Leaving]
[18:52:57] <ssi> sometihng debian-flavored anyway
[18:53:15] <alex4nder> that sounds a lot like a novena
[18:53:20] <XXCoder> https://i.chzbgr.com/maxW500/7715960576/h8FFFCE4E/
[18:53:21] <XXCoder> sigh
[18:53:29] <XXCoder> not my pic thankfully
[18:53:44] <CaptHindsight> alex4nder: yes, only with connections to use Mesa IO
[18:53:55] <alex4nder> yup
[18:54:29] <CaptHindsight> https://eewiki.net/display/linuxonarm/i.MX6x+SABRE+Lite
[18:54:50] <alex4nder> CaptHindsight: what about just using a zynq?
[18:55:12] <CaptHindsight> alex4nder: too expensive and not enough stuff like GPU
[18:55:36] <CaptHindsight> the newer version looks nice but I haven't heard any pricing yet
[18:56:03] <alex4nder> yah, the gpu is annoying,.. but I've seen zynq dev boards for $100
[18:56:12] <CaptHindsight> imx6 has debian 7 and 8
[18:56:39] <CaptHindsight> whats the name for Debian 7?
[18:56:44] <alex4nder> wheezy
[18:56:51] <CaptHindsight> whats 8?
[18:56:55] <alex4nder> jessie
[18:57:10] <CaptHindsight> thanks, I never remember
[18:58:17] <CaptHindsight> ssi: won't take long once I get a bit of free time
[18:58:45] -!- tekniq [tekniq!~tekniq@198.179.137.221] has joined #linuxcnc
[18:59:22] <anonimasu> heh into unit's..
[18:59:25] <anonimasu> unit/s..
[18:59:32] -!- skunkworks has quit [Read error: Connection reset by peer]
[18:59:41] <anonimasu> trying to get the plasma set up, but the number looks insane
[18:59:48] <anonimasu> 333counts/mm
[19:00:07] <anonimasu> 1631700counts/sec^2 ?
[19:00:11] <anonimasu> for 0.5g..
[19:00:44] <Cromaglious> what drive are you using? belt, chain, rack, screw?
[19:01:27] <anonimasu> rack
[19:01:32] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[19:01:41] -!- sumpfralle1 [sumpfralle1!~lars@erina.opennet-initiative.de] has joined #linuxcnc
[19:01:45] <anonimasu> scale = 333
[19:01:51] <anonimasu> inch machine :S
[19:02:19] <Cromaglious> direct drive or gearing
[19:02:22] <anonimasu> gearing
[19:02:25] <anonimasu> 10:1
[19:02:42] <anonimasu> (I have torque) but not enough counts/rev) for direct drive
[19:03:18] <Cromaglious> how many revs per inch for tttttttttttttttttttttttttttttttttttttthe motor?
[19:03:23] -!- sumpfralle has quit [Ping timeout: 240 seconds]
[19:03:51] <Cromaglious> kb stutters not me, much
[19:03:58] <zeeshan> rofl
[19:04:01] <zeeshan> kb stutter i like that
[19:04:04] <anonimasu> about 4k..
[19:04:08] <anonimasu> (out of 6k)
[19:07:00] <Cromaglious> to travel one inch, I don't think it takes 4K revolutions, maybe 4K steps cuz that's like 0.00025" per rev of the motor, with 4K steps on a 200 step motor thats like 0.050" per rev
[19:09:08] <anonimasu> gah.
[19:09:11] <anonimasu> 333 steps/mm
[19:09:19] <anonimasu> err encoder counts that is.
[19:09:43] <Cromaglious> ahhh your using servo motors
[19:10:48] -!- starbuck|ghost has quit [Ping timeout: 256 seconds]
[19:12:52] <Cromaglious> so you're running 1 motor rev per 10 gear revs?
[19:14:30] <ssi> probably the other way around
[19:14:36] <Cromaglious> 8458.2 counts per inch
[19:14:36] <ssi> since servos are generally very fast
[19:14:49] <Cromaglious> <anonimasu> (I have torque) but not enough counts/rev) for direct drive
[19:15:07] <ssi> my plasma table runs 3:1 reductions and a 1" pinion, so it's approx 1 rev per inch
[19:15:19] <ssi> since the pinion travels pi inches per rev
[19:15:32] -!- koo5 [koo5!~sirdancea@236.152.broadband3.iol.cz] has joined #linuxcnc
[19:15:55] <CaptHindsight> http://www.st.com/web/catalog/sense_power/FM142/CL851/SC1794/SS1498/PF259084 powerSTEP01 drivers are only a few $ and handle 10A
[19:16:16] amnesic is now known as amnesic_away
[19:16:23] <ssi> if you do integral stepper drivers, what are you going to use for step generation?
[19:16:33] <ssi> does imx6 have something pru-like?
[19:17:03] <ssi> oh does that chip do its own step gen somehow?
[19:17:17] <CaptHindsight> no pru
[19:20:10] <CaptHindsight> http://www.st.com/web/en/catalog/sense_power/FM142/CL851/SC1794
[19:20:53] <CaptHindsight> 2.5A stepper drivers are ok for tiny things like repraps
[19:21:05] <ssi> they're touting position mode control
[19:21:10] <ssi> but it's hard to tell if it's realtime capable
[19:21:16] <ssi> that's the mess I got into with those damn parker servo drives
[19:21:26] <ssi> they could ONLY be controlled via serial position commands
[19:21:26] <CaptHindsight> but 6A drivers on board could be useful for small mills
[19:21:34] <ssi> and there was no way to do realtime position control for closed loop
[19:21:58] <CaptHindsight> yeah, the others in that series don't have the controller
[19:22:02] <ssi> I wouldn't bother doing integral stepper drivers if you don't have a good way to do hardware stepgen
[19:22:19] <CaptHindsight> thats what the FPGA is for
[19:22:26] <ssi> yeah I suppose that's true
[19:22:45] <ssi> but wouldn't it make more sense to just make a daughterboard for the IDC header which has stepper drivers on it?
[19:22:53] <ssi> 7i76 but with integral drivers?
[19:23:33] <ssi> there's gonna be a lot of power design considerations for the stepper drivers
[19:23:41] <ssi> a lot of complexity for a non-pop option on the sbc
[19:23:51] <CaptHindsight> difficult if you're new to it
[19:24:16] <ssi> I mean we could make that board as another product
[19:24:24] <CaptHindsight> also the target application for the board
[19:25:01] <CaptHindsight> hobbyist 3d printers with 2A stepper drivers like the one on kickstarter
[19:25:02] * anonimasu nods
[19:25:12] <anonimasu> so how fast do you set the accel for 0.5g?
[19:25:17] <ssi> there's already dozens of those out there
[19:25:37] <CaptHindsight> but none with a GPU for a GUI
[19:26:01] <ssi> I just feel like if you design around the stepper drivers, you're baking in a lot of inflexibility
[19:26:16] <ssi> if you design around something like superport, then a separate board can be your driver/breakout
[19:26:18] <PCW> all the smarts in that chip just make coordinated motion harder
[19:26:42] <CaptHindsight> yeah forget that one
[19:26:42] -!- skunkworks [skunkworks!~chatzilla@str-broadband-ccmts-ws-26.dsl.airstreamcomm.net] has joined #linuxcnc
[19:26:48] <ssi> the SBC replaces an off the shelf PC plus 6i25
[19:26:54] <CaptHindsight> I didn't see the comntroller in there
[19:27:03] <ssi> can drop into machine designs like many of us have with 7i76/7i77 etc
[19:27:13] <CaptHindsight> the others are just step and dir
[19:27:16] <ssi> or can use a new board we and/or pcw does with integral drivers
[19:27:20] <CaptHindsight> with microstepping
[19:27:44] <ssi> simple, elegant, flexible
[19:28:12] <CaptHindsight> as long as it replaces the smoothie and others :)
[19:29:23] <CaptHindsight> a daughter card with all the drivers is simple as well
[19:29:30] <ssi> yes, very simple
[19:29:39] <ssi> and makes it easier to isolate the high voltage stepper supply
[19:29:43] <PCW> If you add HDR26 FPGA I/O with PP pinout you can use our daughtercards or anyone elses BOB/step drive
[19:29:56] <ssi> PCW: that's exactly what I'm aiming toward
[19:29:57] <CaptHindsight> thats the plan
[19:30:30] <CaptHindsight> PCW: just deciding on weather to also add onboard 2A drivers
[19:30:44] <ssi> PCW: what I'd like to do is get the pinout of the s6lx9 on the SBC exactly the same as the pinout of the 6i25, so that hm2 firmwares work unchanged
[19:31:07] <_methods> make the drivers socketed so you can remove them
[19:31:29] <ssi> _methods: if the drivers are on a daughterboard, it'd just be a single 26 pin ribbon cable
[19:31:44] <CaptHindsight> _methods: for DIYers that's a must
[19:31:48] <_methods> yeah
[19:32:04] <ssi> buy this $100 sbc, and add either a $100 mesa breakout or a $x 6 axis 6A stepper driver breakout
[19:32:34] <PCW> depending on the host interface pin usage you may be able to support onboard drivers and 2 expansion connectors
[19:32:47] <ssi> looking like 1 lane pcie for the host interface
[19:32:48] <CaptHindsight> the GPU can run a display for SLA DLP/LCD printers as well
[19:32:57] -!- furrywolf [furrywolf!~randyg@107.25.193.17] has joined #linuxcnc
[19:33:00] <ssi> CaptHindsight: in addition to the user console?
[19:33:30] <PCW> 6i25 only has 2 exp connectors because ~50 I/O are used by PCI
[19:33:55] <ssi> really? i figured the pcie would have been lighter than that
[19:34:21] <CaptHindsight> ssi: yes
[19:34:26] <ssi> CaptHindsight: nice
[19:34:28] -!- eFuchs_mobil has quit [Remote host closed the connection]
[19:34:31] <PCW> its PCI internally
[19:34:56] <PCW> (SP6 SLX9 cannot support PCIE directly)
[19:35:01] <Cromaglious> hmm I wonder if I need to put a resistor on the pwm input to drop the mach3 output level down a bit
[19:35:12] <ssi> ah
[19:35:58] <PCW> but if you use the static memory interface its only 22 or so pins for a 16 bit interface
[19:35:59] <CaptHindsight> imx6 also has SPI
[19:36:34] <CaptHindsight> wasn't Jeplers hm2_SPI fast enough?
[19:36:39] -!- swingley has quit [Remote host closed the connection]
[19:36:41] <PCW> if you want the best performance(and are building a SBC), the static memory interface is better
[19:36:51] -!- motioncontrol [motioncontrol!~io@host29-31-dynamic.33-79-r.retail.telecomitalia.it] has joined #linuxcnc
[19:37:03] <CaptHindsight> yeah
[19:37:07] <ssi> looks like an SRAM?
[19:37:14] <PCW> yeah
[19:37:17] <ssi> nice
[19:37:33] <PCW> Both Sitara and IMX6 have this
[19:37:36] <ssi> I still haven't dug into the hm2 hdl in any seriousness
[19:37:43] <ssi> I knew about the sitara GPMC
[19:38:13] <PCW> it would need a interface shim (but thats a very simple one)
[19:39:36] <CaptHindsight> I'm leaning more towards the imx6 since it can be 1 - 4cores with same pinout + it has the GPU power
[19:39:53] <ssi> yeah that's fine
[19:40:26] <ssi> PCW: I guess an hm2_sram driver would need to be written also?
[19:40:32] <PCW> HM2_eth is run by a 16 bit ucontroller so the 16 bit hm2 interface could likely be stolen from it
[19:40:49] -!- skunksleep [skunksleep!~AndChat14@str-broadband-ccmts-ws-26.dsl.airstreamcomm.net] has joined #linuxcnc
[19:40:49] <CaptHindsight> and it's the most open except for the Vivante GPU
[19:41:45] <furrywolf> yay, a break in the rain... meh, the rain has been replaced by stiff winds.
[19:42:02] <PCW> you could bit-bang/SPI in the configs and save a flash chip
[19:42:41] <ssi> true, but flash chips are cheap cheap
[19:43:59] <PCW> I think we pay $0.55 for the 16 MBit ones
[19:44:24] <CaptHindsight> the PCIe could be a connector to cable off to another FPGA
[19:45:00] <CaptHindsight> or miniPCIe socket for wifi, BT, LTE etc
[19:45:03] <PCW> or 1/2 minipcie socket
[19:45:57] <PCW> I have a minipcie-cabled PCIE adapter
[19:47:18] <ssi> I'mma go battle the toyotas
[19:47:19] <ssi> back in a bit
[19:48:19] <furrywolf> what kind of toyotas? heh
[19:49:02] <CaptHindsight> mini-itx with 12V power
[19:51:19] -!- Komzzzpa has quit [Read error: Connection reset by peer]
[19:51:50] <CaptHindsight> the IO connectors could be on the edge or left out and also with all their signals on headers
[19:52:05] -!- FreezingCold has quit [Ping timeout: 246 seconds]
[19:53:10] <CaptHindsight> in what form factor is the board the most useful?
[19:53:37] -!- motioncontrol has quit [Quit: Sto andando via]
[19:55:43] <PetefromTn_> http://bleacherreport.com/articles/2393127-report-gigantic-alligator-taking-over-greens-at-florida-golf-course?utm_source=cnn.com&utm_medium=referral&utm_campaign=editorial AAaah Florida!!
[19:55:59] <_methods> heheh
[19:56:05] -!- KimK_laptop has quit [Remote host closed the connection]
[19:56:07] -!- dirty_d [dirty_d!~dirty_d@50-205-178-174-static.hfc.comcastbusiness.net] has joined #linuxcnc
[19:56:59] <dirty_d> well thats just insane
https://www.youtube.com/watch?v=s9IdZ2pI5dA
[19:57:07] <PetefromTn_> that is actually NOT the largest gator I ever saw down there tho...
[19:57:54] <LeelooMinai> And who said golf is not an extreme sport
[19:58:31] <LeelooMinai> I bet some Japanese would pay a lot of money to play on that golf course:)
[19:58:35] <PetefromTn_> When I was growing up we lived in Wellington and they had a series of lakes throuought the area with Golf Courses on there. They once pulled a gator out of there that barely fit in the back of a fullsize pickup truck width wise.... IT was a real monster.
[19:59:20] <furrywolf> no gators here. bears and bobcats, however.
[20:00:06] <PetefromTn_> http://www.wtsp.com/story/news/2014/11/28/lakeland-man-catches-719-pound-gator/19632717/
[20:00:27] <Cromaglious> damn yoocnc for making thier 3040 spindle integral to the Z carriage. I'm stuck using a 52mm motor
[20:00:39] <furrywolf> bears don't tend to show up here too often, but they do show up from time to time... once one got in my garbage and bit clean through a steel can.
[20:00:44] <_methods> they just started letting people hunt for them again around here
[20:01:08] <CaptHindsight> golfers?
[20:01:12] <_methods> hahah
[20:01:17] <_methods> they've always been open season
[20:01:53] <PetefromTn_> I LOVE me some Gator Tail snacks it is DELICIOUS!!
[20:01:55] <Cromaglious> ones in the short skirts tend to be more tender and juicier
[20:02:53] <PetefromTn_> that is a bigass gator tho they photographed yesterday.... Would not want to be looking for my ball near the water traps over there LOL. I enjoyed the chubbs comment Hehehe
[20:02:57] <_methods> https://www.youtube.com/watch?v=Gf3QIkQRGtI
[20:03:05] <Cromaglious> ss .22 short or long 9shot revolver is about the best gator gun
[20:03:31] <dirty_d> why?
[20:03:48] -!- ffurrywol [ffurrywol!~randyg@174-144-149-10.pools.spcsdns.net] has joined #linuxcnc
[20:03:58] <ffurrywol> <furrywolf> bears don't tend to show up here too often, but they do show up from time to time... once one got in my garbage and bit clean through a steel can.
[20:03:59] <Cromaglious> 1 it takes .22 shorts, 2 doesn't tear up much of the hide
[20:03:59] <ffurrywol> <furrywolf> Cromaglious: I'm sure you can find a way to belt any motor you want off to the side...
[20:03:59] -!- tekniq has quit [Ping timeout: 246 seconds]
[20:04:03] <LeelooMinai> I thought when you hunt for them you can only use a knife.
[20:04:21] <PCW> Golfers?
[20:04:42] <PetefromTn_> you gotta jump in with the knife between your teeth mumbling AARRRGGGhhhhh
[20:04:43] <LeelooMinai> Not Gophers, Alligators
[20:05:00] <PetefromTn_> an eye patch helps too
[20:05:21] -!- furrywolf has quit [Ping timeout: 256 seconds]
[20:05:33] amnesic_away is now known as amnesic
[20:06:11] <Cromaglious> ffurrywol, I'm thinking I' just hack it off with a hack saw or sawzall, the rig up my router with a bit and have the machine run back and forth to clean is up, then drill some holes and use a bigger mount
[20:07:10] <Cromaglious> smallest VFD brushless I can find is 65mm
[20:07:31] <Cromaglious> and over $300 including shipping
[20:08:18] -!- Valen1 [Valen1!~Valen@c211-30-128-202.blktn6.nsw.optusnet.com.au] has joined #linuxcnc
[20:08:39] <_methods> and a mullet
[20:08:54] <_methods> you can't wrestle gators or golfers without a mullet
[20:09:26] <Cromaglious> $125 for a 500w dc brushed w/ power supply and it's a 52mm
[20:10:05] <Cromaglious> _methods, so true or bald on top with long hair on the sides a Bullet
[20:10:13] <PetefromTn_> classicly speaking no a mullet would definitely be a prerequisite.
[20:10:34] <_methods> heheh
[20:10:52] <Cromaglious> and a wife beater which doesn't cover the beer belly
[20:11:35] <PetefromTn_> yeah but if you are golfing out in the Florida Sunshine that guy is your HERO man... respect LOL
[20:12:17] <Cromaglious> I can carry my own .44spl since I'm not worried about ruining the hide
[20:12:18] -!- TTN_ [TTN_!~TTN@27.110.122.139] has joined #linuxcnc
[20:12:48] <CaptHindsight> the new imx6 quad has a POP with 1GB LPDDR2
[20:13:01] <CaptHindsight> wish there was a 2GB option
[20:13:16] -!- dirty_d has quit [Quit: Leaving]
[20:14:15] <CaptHindsight> http://blogs.freescale.com/mcus/2015/03/the-mobile-package-just-got-smaller/
[20:16:37] <ffurrywol> blah, and now it's raining again.
[20:18:02] -!- Tecan [Tecan!~fasdf@unaffiliated/unit41] has joined #linuxcnc
[20:22:47] -!- adb [adb!~IonMoldov@2a02:120b:c3d1:5780:baac:6fff:fe67:305f] has joined #linuxcnc
[20:25:23] -!- FreezingCold [FreezingCold!~FreezingC@135.0.41.14] has joined #linuxcnc
[20:26:23] -!- dr0w has quit [Read error: Connection reset by peer]
[20:26:39] -!- TTN_ has quit [Quit: gnight :)]
[20:27:01] -!- TTN_ [TTN_!~TTN@27.110.122.139] has joined #linuxcnc
[20:27:11] -!- TTN_ has quit [Read error: Connection reset by peer]
[20:27:47] -!- BellinganRoy [BellinganRoy!~Bellingan@host52-233-dynamic.23-79-r.retail.telecomitalia.it] has joined #linuxcnc
[20:28:34] <tjtr33> i think the new 2.7 has hal function pins.
[20:28:41] <tjtr33> maybe: if we have a dummy function forced to be 1st and another forced to execute last...
[20:28:42] <tjtr33> then can we monitor the time the entire hal function collection takes to execute?
[20:31:25] <skunksleep> tjtr33: would you know the removal rate for a 30 amp edm?
[20:31:31] -!- TTN_ [TTN_!~TTN@27.110.122.139] has joined #linuxcnc
[20:31:49] <skunksleep> (Just for an idea)
[20:34:36] <tjtr33> given a 1" sqr, decent graphite, flush thru center of tool, 100on 30off, pos polarity, 30V servo target, about 1/2" in 45 min
[20:35:40] <tjtr33> do you have the Handsvedt tech books?
[20:36:30] <skunksleep> Yes just scanned them so far. Seem like it has nice theory in it
[20:36:50] <tjtr33> good tech really
[20:37:45] <tjtr33> begin with the paarung ( material of electrode and wkpc) then size of shadow ( inerface contact area ) then finish desired
[20:38:32] <tjtr33> you walk down to the final finish thru several power settings, and at least 2 sizes of tool, one ruffer, one finished
[20:40:04] -!- Rickta59 has quit [Quit: leaving]
[20:40:21] Valen1 is now known as Valen
[20:53:14] -!- dr0w [dr0w!~george@adsl-184-45-52-131.sdf.bellsouth.net] has joined #linuxcnc
[20:56:15] <ffurrywol> bbl
[21:00:31] -!- ffurrywol has quit [Ping timeout: 250 seconds]
[21:10:00] -!- syyl_ [syyl_!~sg@p200300632C236D16096C5B5516071149.dip0.t-ipconnect.de] has joined #linuxcnc
[21:10:58] -!- TTN [TTN!~TTN@unaffiliated/ttn] has joined #linuxcnc
[21:13:01] -!- FinboySlick has quit [Quit: Leaving.]
[21:13:12] -!- syyl has quit [Ping timeout: 256 seconds]
[21:17:17] -!- syyl [syyl!~sg@p200300632C236D96096C5B5516071149.dip0.t-ipconnect.de] has joined #linuxcnc
[21:18:57] -!- tekniq [tekniq!~tekniq@198.179.137.221] has joined #linuxcnc
[21:19:44] -!- syyl_ has quit [Ping timeout: 265 seconds]
[21:19:52] -!- [cube] has quit [Ping timeout: 240 seconds]
[21:21:09] -!- XXCoder has quit [Read error: Connection reset by peer]
[21:21:35] -!- swingley has quit [Remote host closed the connection]
[21:27:53] -!- [cube] [[cube]!~cube@70.50.50.74] has joined #linuxcnc
[21:34:14] -!- Miner_48er has quit [Ping timeout: 265 seconds]
[21:36:03] -!- Rickta59 [Rickta59!~Rickta59@cpe-174-106-151-175.ec.res.rr.com] has joined #linuxcnc
[21:44:27] <CaptHindsight> ssi:
http://openlunchbox.com/?attachment_id=287 sbc-imx6-block00
[21:44:34] <CaptHindsight> PCW: ^^
[21:46:03] -!- TTN_ has quit [Quit: gnight :)]
[22:01:33] -!- f1oat3 has quit [Ping timeout: 252 seconds]
[22:05:17] <Simonious> I'm using Sketchup->CamBam to generate my Gcode and that's working (I'm still quite novice) I'm interested in generating gcode to cut some images - both text and actual pictures - suggestions on how to do this?
[22:06:51] <Deejay> gn8
[22:07:53] -!- Deejay has quit [Quit: bye]
[22:10:43] <CaptHindsight> Simonious: suggestions for other than what you are already using?
[22:11:06] <Simonious> CaptHindsight: I'm not sure how to use what I'm already using to cut an image.. models sure..
[22:17:18] <CaptHindsight> Simonious: what are you starting with? images or are you drawing using CAD?
[22:18:06] <Simonious> In this case images
[22:18:48] <CaptHindsight> http://linuxcnc.org/docs/html/gui/image-to-gcode.html
[22:19:35] <Simonious> cool, I'll check it out
[22:19:39] <Simonious> I'm also looking into inkscape
[22:20:42] <CaptHindsight> http://www.linuxcnc.org/docs/2.4/html/gui_image-to-gcode.html
[22:20:56] <Simonious> http://www.cambam.co.uk/forum/index.php?topic=1507.0
[22:21:06] <CaptHindsight> http://wiki.linuxcnc.org/cgi-bin/wiki.pl?InkscapeHowto
[22:27:01] -!- MrSunshine has quit [Ping timeout: 256 seconds]
[22:32:20] <ssi> CaptHindsight: awesome
[22:32:39] <anonimasu> mhm..
[22:33:18] * anonimasu sighs
[22:33:24] <anonimasu> why did i explain about my setup again?
[22:33:25] <anonimasu> :S
[22:34:17] <anonimasu> I am trying to get this accel setting, is it units/sec^2?
[22:34:34] <ssi> yes
[22:35:07] <anonimasu> if that is the case my max_accel ends up as (9810mm/sec^2)*333 for one g..
[22:35:35] -!- jvrousseau has quit [Quit: My Mac has gone to sleep. ZZZzzz…]
[22:35:51] <ssi> wouldn't that be 333g? :P
[22:35:58] <anonimasu> -_-
[22:36:02] <anonimasu> that's what I dont get.
[22:36:06] -!- syyl has quit [Ping timeout: 265 seconds]
[22:36:15] <anonimasu> haah
[22:36:26] <anonimasu> 333encoder counts/mm
[22:36:45] <anonimasu> 1633365 counts/sec
[22:36:48] <ssi> I have no idea what your question is
[22:36:49] <anonimasu> for 0.5...
[22:36:55] <anonimasu> how do i get 0.5g of accel with my setup :D
[22:37:15] <anonimasu> I have (333 encoder counts/mm)..
[22:37:32] <PCW> inch or mm machine?
[22:37:47] -!- kb8wmc [kb8wmc!~kb8wmc@64.25.194.29] has parted #linuxcnc
[22:37:48] <anonimasu> mm
[22:38:06] <PCW> encoder counts dont matter
[22:38:15] <anonimasu> err scale is 333..
[22:38:27] -!- Bushman [Bushman!bushman@91-146-248-112.internetia.net.pl] has joined #linuxcnc
[22:38:30] <Bushman> ave
[22:39:19] <PCW> didn't someone already say 4900 mm/s^2 ?
[22:39:25] -!- phantoneD [phantoneD!destroy@a89-152-21-144.cpe.netcabo.pt] has joined #linuxcnc
[22:39:39] phantoneD is now known as phantoxeD
[22:39:46] <anonimasu> i did
[22:39:50] <Bushman> i'm trying to understand what is happening but i have no idea how it bite it...
[22:39:53] <Bushman> this code:
[22:39:54] <Bushman> G0 Z 5.00000
[22:39:54] <Bushman> T1 M6
[22:39:54] <Bushman> S6000
[22:39:55] <Bushman> G0 X 113.58405 Y 280.95901
[22:39:58] <anonimasu> i just didnt get if that's in the "units" like mm or the encoder counts
[22:40:08] <Bushman> goes to Z5 and then back to Z0
[22:40:11] <ssi> units is mm or inch
[22:40:26] <anonimasu> heh.. that was easy.
[22:40:27] <Bushman> and THEN it goes back up to tool change position
[22:40:31] <Bushman> what's happening?
[22:40:36] <Cromaglious> it's the setting.. G20 is a inch file, G21 is a metric file
[22:40:40] <PCW> yes accel is in machine units per second squared
[22:40:51] <anonimasu> let me throw my rail axis into the wall.
[22:40:54] <anonimasu> brb.
[22:41:04] <PCW> just like velocity is in machine units per second
[22:41:22] <Cromaglious> Which is NOT controlled by G20 or G21
[22:42:03] <PCW> right those are only for interpretation, machine limits are not changed
[22:42:23] -!- MrSunshine [MrSunshine!~mrsun@c-c825e255.4551536--62697410.cust.bredbandsbolaget.se] has joined #linuxcnc
[22:43:35] <Bushman> anyone? o_O?
[22:45:16] -!- jerryitt has quit [Quit: Connection closed for inactivity]
[22:46:22] <Cromaglious> Bushman what's the Safe Z setting like?
[22:46:48] <Bushman> umm
[22:46:59] <Bushman> you got me there... need to check
[22:47:42] <Cromaglious> also you might look in the M6 macro file
[22:48:06] <Bushman> the safe z... is it in ini?
[22:50:09] -!- micges [micges!~micges@dgu133.neoplus.adsl.tpnet.pl] has joined #linuxcnc
[22:50:14] <Cromaglious> heh sorry was thinking Mach3
[22:50:39] -!- finnpixel [finnpixel!~finnpixel@av-217-129-135-231.netvisao.pt] has joined #linuxcnc
[22:52:25] <Bushman> umm... where are the macros?
[22:54:19] -!- Roguish has quit [Quit: ChatZilla 0.9.91.1 [Firefox 36.0.1/20150305021524]]
[22:55:10] <Bushman> Cromaglious: where can i find the tool change macros in linuxcnc?
[22:56:57] <Cromaglious> looking I was thinking Mach3 not linuxcnc
[22:59:01] <Cromaglious> TOOL_CHANGE_POSITION = 0 0 2 - Specifies the XYZ location to move to when performing a tool change if three digits are used. Specifies the XYZABC location when 6 digits are used. S
[22:59:13] <Cromaglious> that's in the ini file
[22:59:31] <Cromaglious> TOOL_CHANGE_QUILL_UP = 1 - The Z axis will be moved to machine zero prior to the tool change when the value is 1. This is the same as issuing a G0 G53 Z0.
[23:00:18] <Cromaglious> they're from this file
http://www.linuxcnc.org/docs/html/config/ini_config.html
[23:00:26] <Bushman> oh
[23:00:56] <Bushman> quill up? what does it mean?
[23:01:13] <Cromaglious> so open up your mymill.ini or what ever it's called..
[23:01:17] <PCW> dangerous porcupine?
[23:01:20] <Bushman> my tool is already above the surface... bringing it to machine 0 will cause it colide
[23:01:29] <Cromaglious> quill == Z
[23:01:49] amnesic is now known as amnesic_away
[23:02:00] <Cromaglious> so use = 0 on that config if you have it in your ini file
[23:02:30] <Bushman> then it will do linear move from where it is. right?
[23:02:40] <Cromaglious> My Z 0 is at top, and all Z moves are to negative numbers
[23:03:22] <Bushman> my z is not on top :(
[23:03:29] <Bushman> Z0
[23:03:33] <Bushman> hmm...
[23:03:38] <Cromaglious> well I'll be back laters... I have to go see if I can get a 3040 going again
[23:03:51] <Bushman> laterz
[23:04:02] -!- starbuck|ghost [starbuck|ghost!~irc@c-68-44-190-29.hsd1.in.comcast.net] has joined #linuxcnc
[23:05:04] -!- BellinganRoy has quit [Quit: Konversation terminated!]
[23:05:25] <Cromaglious> but first a wifely pit stop..
[23:05:27] <Simonious> CaptHindsight: inkscape -> trace bitmap -> export DXF -> import to sketchup (for touchup and resize as needed) -> export DXF -> cambam -> router
[23:05:43] <Simonious> I think I'm going to be able to cut images as desired this way.
[23:05:52] <Simonious> So far the DXF looks great.
[23:06:58] HSD is now known as HSD_afk
[23:08:48] -!- adb has quit [Ping timeout: 252 seconds]
[23:09:03] -!- gonzo_nb [gonzo_nb!~gonzo@host-92-14-209-118.as43234.net] has joined #linuxcnc
[23:09:04] -!- gonzo__nb [gonzo__nb!~gonzo@host-92-14-209-118.as43234.net] has joined #linuxcnc
[23:10:22] -!- gonzo_nb has quit [Client Quit]
[23:13:18] -!- swingley has quit [Remote host closed the connection]
[23:14:46] -!- koo5 has quit [Ping timeout: 272 seconds]
[23:16:37] -!- md-2 has quit [Remote host closed the connection]
[23:18:11] -!- swingley has quit [Ping timeout: 252 seconds]
[23:20:08] -!- md-2 has quit [Client Quit]
[23:21:25] -!- tinkerer has quit [Remote host closed the connection]
[23:24:16] -!- PetefromTn_ has quit [Quit: I'm Outta here!!]
[23:26:55] -!- AR_ [AR_!~AR@24.238.81.234.res-cmts.sth2.ptd.net] has joined #linuxcnc
[23:29:49] -!- moorbo has quit [Ping timeout: 245 seconds]
[23:32:28] -!- moorbo [moorbo!~moorbo@dyn-21-121.mdm.its.uni-kassel.de] has joined #linuxcnc
[23:39:12] -!- Miner_48er has quit [Quit: Leaving]
[23:42:55] -!- gonzo__nb has quit [Remote host closed the connection]
[23:47:44] -!- starbuck|ghost has quit [Ping timeout: 245 seconds]
[23:48:37] -!- swingley has quit [Ping timeout: 256 seconds]
[23:51:54] -!- TTN has quit [Quit: gnight :)]
[23:54:08] -!- asdfasd has quit [Ping timeout: 256 seconds]
[23:54:56] -!- TTN [TTN!~TTN@unaffiliated/ttn] has joined #linuxcnc
[23:59:14] -!- kwallace2 has quit [Read error: Connection reset by peer]
