[02:58:13] <taiden> hi all
[02:58:39] <taiden> aside from the "SuperPID" controller, has anyone had luck setting up some kind of PID control for spindle speed with LinuxCNC?
[03:01:20] <os1r1s> taiden: I'm using a superpid, albeit not with linuxcnc
[03:01:32] <os1r1s> taiden: Its pretty easy to control though. I'm sure it would work
[03:02:35] <pcw_home> Linuxcnc can easily control spindle speed using PID
[03:03:39] <pcw_home> Typically a velocity loop uses just P and I (and FF0)
[03:03:43] <os1r1s> pcw_home: The superpid does the speed control portion. He can interface to it via PWM or an analog signal if memory serves
[03:04:00] <os1r1s> pcw_home: Its a bit like a kbic control.
[03:04:05] <LeelooMinai> I think 7i76 has spindle control output
[03:04:20] <LeelooMinai> So I guess no "superPID" is required for that case (?)
[03:04:32] <os1r1s> LeelooMinai: I don't think the 7i76 controls the mains
[03:04:46] <os1r1s> AC mains to vary the spindle speed
[03:04:58] <os1r1s> I could be wrong ...
[03:05:39] <taiden> the "spindle" im using is a Hitachi m12vc router
[03:06:04] <taiden> i'd love to have pid control for it, but $180 and 3 week lead time is no bueno
[03:06:26] <LeelooMinai> I think it can act as digital potentiometer - so as long as spindle speed can be controlled this way, it would work.
[03:06:38] <pcw_home> No SuperPID is needed with linuxcnc, but of course some kind of motor drive is required
[03:06:52] <LeelooMinai> As for AC spindles - they require VFDs anyways, no?
[03:06:55] <pcw_home> (LinuxCNC can do the PID just fine)
[03:07:00] <os1r1s> LeelooMinai: Thats exactly what he would need to do
[03:07:04] <pcw_home> yep
[03:07:05] <os1r1s> LeelooMinai: PWM it
[03:07:41] <LeelooMinai> Hmm, not sure what that SuperPID really does...
[03:07:47] <pcw_home> Typically VFDs have analog 0-10V inputs
[03:08:19] <taiden> "SuperPID" just takes frequency input from some kind of optical sensor for spindle RPM and then adjusts PWM frequency to the motor to match
[03:08:33] <taiden> uses PID logic to maintain RPM under changes in spindle load
[03:08:35] <os1r1s> taiden: No, it also flips the AC on and off
[03:08:42] <pcw_home> if you have a VFD you dont need a separate controller
[03:08:47] <os1r1s> taiden: Which is what linuxcnc needs an external controller to do
[03:09:00] <LeelooMinai> A, I just looked at it - it has some kind of triac or whatever to do switching
[03:09:27] <pcw_home> what kind of spindle are you driving?
[03:09:34] <taiden> no VFD, it's a Hitachi m12vc router
[03:09:54] <LeelooMinai> taiden: Does it have manual speed control knob?
[03:10:06] <taiden> Yep
[03:10:30] <LeelooMinai> I think you could hack into the knob and interface it with something like what 7i76 has
[03:10:49] <LeelooMinai> Because knob will be just a potentiometer
[03:11:41] <LeelooMinai> But you would also need some kind of feedback, but that's rather easy to do
[03:12:17] <XXCoder> someone installed windows 95 on icrap 6
[03:12:35] <XXCoder> http://techcrunch.com/2014/11/10/chinese-programmer-sticks-windows-95-on-an-iphone-6-plus/
[03:13:16] <XXCoder> emulator but still jeez lol
[03:13:26] <XXCoder> we probably will have new installs in year 2095
[03:14:03] <os1r1s> LeelooMinai: Its meant for CNC control. You don't need to hack it
[03:14:22] <LeelooMinai> os1r1s: What, the router?
[03:14:31] <os1r1s> LeelooMinai: The superpid
[03:14:39] <LeelooMinai> I was talking about the router
[03:14:42] <taiden> i think he was tlaking about hackng thr router knob
[03:14:47] <os1r1s> Ahh, ok
[03:14:49] <pcw_home> but you dont need it either(linuxCNC is happy doing PID)
[03:14:54] <LeelooMinai> I am she btw
[03:15:04] <taiden> my mistake, apologies
[03:15:20] <os1r1s> taiden: Here is mine for reference ... http://gallery.mounicou.com/photos/i-bh5ccft/0/L/i-bh5ccft-L.jpg
[03:15:26] <LeelooMinai> I googled the router - it's just, well, a hand router like any
[03:15:43] <os1r1s> I have it controlling a bosch colt router
[03:16:27] <taiden> pcw_home: bring in RPM signal via optical sensor and output spindle on/off with PID logic?
[03:17:02] <taiden> i wondered if HAL could do this somehow
[03:18:00] <LeelooMinai> I just wander if the speed by potentiometer on the router like this would not work much better than just brute force pwm
[03:18:03] <os1r1s> taiden: If you wire up a triac I'm sure you could
[03:18:06] <LeelooMinai> wonder*
[03:18:29] <taiden> usually the routers have their own soft start circuits etc
[03:18:43] <taiden> i suspect you wouldn't get the PID type feedback
[03:18:53] <taiden> which is half of its value IMO
[03:19:10] <os1r1s> taiden: The pid would be done in linuxcnc
[03:19:10] <LeelooMinai> PWM could mess the router's own circuits operation
[03:19:27] <taiden> its just a standard brushed motor
[03:19:42] <os1r1s> The triac is just a fast mosfet for controlling the power to it. The feedback loop would be done in linuxcnc
[03:20:11] <LeelooMinai> I mean something like this: "Electronic speed control, maintains constant RPMs even as load varies" <- this will probably fight PWM anyways
[03:20:15] <taiden> anyway PWM is probably not necessary
[03:20:42] <LeelooMinai> (that's from that Hitachi router)
[03:20:42] <taiden> just have it turn on when below target RPM and off when above target RPM
[03:21:33] <pcw_home> Yes you can do PID speed control on HAL so a dumb controler is fine for linuxCNC
[03:22:18] <pcw_home> (I suspect the SuperPID is made for Mach that has no real time control capabilities)
[03:22:59] <taiden> i mean, i have a solid state relay running the router
[03:23:21] <taiden> could I just bring in spindle frequency and wire it up in software easily?
[03:23:22] <LeelooMinai> Brutal imho:)
[03:23:57] <os1r1s> pcw_home: I think you are missing the idea that it is made to control a AC based handheld router. You still need a circuit to do that.
[03:24:02] <pcw_home> No because SSRs typically dont to phase control
[03:24:29] <pcw_home> Sure but no need to pay for the PID part
[03:24:46] <LeelooMinai> I don't see wpm -> relay -> router ending well
[03:24:51] <taiden> it's just a brushed ac motor :P you just plug it into the wall or switch it with a relay :)
[03:25:09] <os1r1s> taiden: A triac is made to switch on and off more frequently than a relay
[03:25:21] <os1r1s> So if you don't care that much about the exact speed, I'm sure a relay is ok
[03:25:32] <LeelooMinai> It can also detect zreo-crossing, which is good
[03:25:54] <os1r1s> But 2000 RPM swings up and down could be a problem
[03:26:05] <taiden> triacs are much faster than solid state relay?
[03:26:24] <LeelooMinai> That's pretty much same technology
[03:26:32] <taiden> that's what i thought
[03:26:45] <taiden> i thought SSRs were used for high frequency switching in many applications
[03:26:46] <os1r1s> LeelooMinai: I didn't think it was the same
[03:26:49] <pcw_home> SSRs use Triacs (or SCRs)
[03:27:10] <taiden> so yeah. spindle out to SSR to router
[03:27:31] <taiden> spindle rpm in via optical sensor aimed at spindle with white paint on half of it
[03:27:34] <os1r1s> I didn't realize an SSR used triacs internally
[03:28:01] <LeelooMinai> That's the "solid state" part - semiconductors basically
[03:28:10] <taiden> i'm fuzzy on how i would bring the frequency in, and im fuzzy on how i'd get linuxcnc to control the RPM at that point
[03:28:42] <LeelooMinai> Frequency in is just pulses into the linuxcnc
[03:28:57] <LeelooMinai> Using whatever means you have
[03:29:15] <LeelooMinai> Probably some optical sensor is easiest
[03:29:37] <taiden> will linuxcnc be able to handle stuff up to 24,000 hz?
[03:29:45] <taiden> stuff meaning pulse frequency
[03:29:54] <LeelooMinai> I think that depends on the hardware
[03:30:15] <taiden> i wonder if there is an IC to convert frequency to 0-5v. there must be
