[00:02:58] -!- AR_ [AR_!~AR@24.238.81.234.res-cmts.sth2.ptd.net] has joined #linuxcnc
[00:06:33] -!- Nick001-shop has quit [Ping timeout: 256 seconds]
[00:07:47] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.pools.arcor-ip.net] has joined #linuxcnc
[00:09:46] <alexchally_cnc> PCW, ok, commented out all PWMgens, EMC now opens
[00:09:52] <alexchally_cnc> more, axis now opens
[00:10:38] <PCW> so now in a terminal run:
[00:10:39] <PCW> halcmd show all >everything.txt
[00:11:53] -!- Flipp has quit [Remote host closed the connection]
[00:11:58] <alexchally_cnc> PCW, much output, such success
[00:12:03] <PCW> to get the names of the new pwmgens
[00:12:05] <PCW> (7I52S is on I/O 0..23)
[00:12:31] -!- eFuchs_mobil [eFuchs_mobil!~yaaic@2001:4dd0:ff00:8d54:b486:2f38:fc33:cc67] has joined #linuxcnc
[00:12:57] <alexchally_cnc> PCW,
http://pastebin.com/35XK5MbM
[00:14:11] -!- eFuchs_mobil has quit [Client Quit]
[00:14:17] <ssi> ok cool, relays are working now
[00:15:31] <alexchally_cnc> pcw, so what used to be: hm2_[HOSTMOT2](BOARD).0.pwmgen.01 should become hm2_5i23.0.3pwmgen.00 ?
[00:16:48] <PCW> hm2_5i23.0.3pwmgen.00.A-value
[00:17:28] <alexchally_cnc> and ...pwmgen.02 ---> hm2_5i23.0.3pwmgen.00.B-value
[00:17:30] <alexchally_cnc> ?
[00:17:55] <PCW> wait a sec your PWMgens should start at 0
[00:18:04] <alexchally_cnc> uhhhh they do
[00:18:04] <alexchally_cnc> sorry
[00:18:23] <alexchally_cnc> ...pwmgen.00 should map to A, .01 should map to B, etc?
[00:19:07] <PCW> so the first three pwmgens are 00.A, 00.B, 00.C
[00:19:09] <PCW> next three are 01.A,01.B,01.C
[00:19:24] -!- lucashodge has quit [Client Quit]
[00:20:28] <alexchally_cnc> ok, should 00.A and 01.A as the two differential lines?
[00:20:43] <alexchally_cnc> sorry if this is coming off as not so smart, not entirely sure what I am getting up to in here
[00:21:13] <PCW> No the pwmgen/hal has no knowledge of the differential aspect
[00:21:40] -!- badon [badon!~badon@pdpc/supporter/active/badon] has joined #linuxcnc
[00:22:31] <PCW> there are two 3 phase pwmgens ( 00 and 01)
[00:22:33] <PCW> each have three independent PWM outputs
[00:23:02] <PCW> you will want to set hm2_5i23.0.3pwmgen.00.deadtime and hm2_5i23.0.3pwmgen.01.deadtime to 0
[00:23:31] <PCW> and hm2_5i23.0.3pwmgen.frequency to 1600
[00:26:05] <PCW> you probably also need to set the PID maxoutput to about 95% of full PWM scale
[00:26:24] <alexchally_cnc> pcw, don't have deadtime in my .hal
[00:26:25] <alexchally_cnc> http://pastebin.com/kLGSy2ea
[00:26:36] <alexchally_cnc> that is the current .hal I am editing
[00:26:57] <PCW> you need to set it to 0
[00:27:54] <PCW> like
[00:27:56] <PCW> setp hm2_5i23.0.3pwmgen.00.deadtime 0
[00:28:09] <PCW> bbl ttgh
[00:28:49] <alexchally_cnc> PCW, I need to go home as well, can I hit you up on this tomorrow?
[00:28:53] <alexchally_cnc> much thanks for your help btw
[00:29:06] <PCW> np bye
[00:29:09] -!- PCW has quit [Quit: ChatZilla 0.9.90.1 [Firefox 30.0/20140605174243]]
[00:31:32] -!- jfigie [jfigie!~zephyr@cpe-65-30-63-127.wi.res.rr.com] has joined #linuxcnc
[00:47:42] -!- rob_h has quit [Ping timeout: 245 seconds]
[00:48:13] -!- PetefromTn_ has quit [Quit: Man who run behind car get exhausted]
[00:52:09] -!- Servos4ever [Servos4ever!~chatzilla@173-87-53-106.dr01.hnvr.mi.frontiernet.net] has joined #linuxcnc
[00:57:18] -!- tjb11 [tjb11!~tjb1@cpe-67-252-67-92.stny.res.rr.com] has joined #linuxcnc
[00:59:39] -!- tjb1 has quit [Ping timeout: 250 seconds]
[01:00:11] tjb11 is now known as tjb1
[01:00:12] -!- skorasaurus has quit [Ping timeout: 250 seconds]
[01:07:22] -!- tinkerer has quit [Quit: Leaving.]
[01:17:47] -!- Nick001 [Nick001!~Nick001@50-32-122-175.adr01.dlls.pa.frontiernet.net] has joined #linuxcnc
[01:22:17] -!- PetefromTn_ [PetefromTn_!~IceChat9@66-191-252-204.dhcp.kgpt.tn.charter.com] has joined #linuxcnc
[01:22:41] <ssi> peet
[01:23:00] <PetefromTn_> hey man!
[01:23:13] <PetefromTn_> whatsgoinon?
[01:23:32] <XXCoder> pee
[01:23:37] <XXCoder> Pee on it.
[01:23:49] <PetefromTn_> are you high?
[01:24:27] <XXCoder> nah just saw a chance to use my old user command I made to kinda mock one guy that kept asking about lathe constantly
[01:25:11] <PetefromTn_> I must have missed something LOL
[01:25:44] <XXCoder> asked for advice for one or 2 lathes everyday
[01:25:49] <XXCoder> sometimes more
[01:25:55] -!- Thetawaves has quit [Quit: This computer has gone to sleep]
[01:25:58] <PetefromTn_> Running the Cinci today a good bit....
[01:26:01] <XXCoder> its always too large or exensive or crappy
[01:26:39] <PetefromTn_> Right now working on a fixture for a project and it is a bit larger than I am used to.
[01:28:09] <XXCoder> hows it running so far
[01:28:37] <PetefromTn_> meh okay... I am still kinda working on the cam part LOL..
[01:28:48] <XXCoder> lol ok
[01:29:30] <PetefromTn_> Got the plate faced off and my offsets picked up. Drilled and tapped some holes for hold downs. Working on the code for the first part.
[01:30:08] -!- jfigie has quit [Quit: Ex-Chat]
[01:30:22] -!- jfigie [jfigie!~zephyr@cpe-65-30-63-127.wi.res.rr.com] has joined #linuxcnc
[01:30:53] -!- jfigie has quit [Client Quit]
[01:31:17] -!- jfigie [jfigie!~zephyr@cpe-65-30-63-127.wi.res.rr.com] has joined #linuxcnc
[01:32:33] <PetefromTn_> I really need to either buy or build a nice table mounted vise stop.
[01:35:46] <XXCoder> you do have cnc, wonder if vice is makable using cnc
[01:36:08] <XXCoder> probably only part not makable is screw unless you has lathe too
[01:36:10] <PetefromTn_> don
[01:36:27] <Valen> 4th axis
[01:36:28] <PetefromTn_> alraedy have a nice kurt vise Don't need one.
[01:36:37] <PetefromTn_> already
[01:36:42] <XXCoder> lol ok
[01:36:53] <XXCoder> I do need one lol but not plan to make or buy one for qhile
[01:37:17] <PetefromTn_> save your pennies and get a kurt it is worth every thin dime...
[01:38:13] <XXCoder> whoa. waaay overkill for wood lol
[01:39:02] <PetefromTn_> don't even really need a vise for wood..
[01:39:16] <Tom_itx> tslot mounted vise stop?
[01:39:17] <XXCoder> yeah
[01:39:24] -!- alexchally [alexchally!~alexchall@2601:7:b00:c1b:1c3c:895a:dc43:d1f0] has joined #linuxcnc
[01:39:38] <PetefromTn_> yeah..
[01:39:48] <PetefromTn_> I have several different vise jaw stops already.
[01:40:10] <Tom_itx> got a tool changer?
[01:40:14] <ssi> pete: workin on water system for the laser :)
[01:40:22] <PetefromTn_> I have seen several nice designs out there.
[01:40:30] <PetefromTn_> cool man.
[01:40:35] <ssi> tube came today
[01:40:36] <XXCoder> water system? to keep stock cool?
[01:40:39] <Tom_itx> use it with a 1/2" dowelpin to come down where the material will locate
[01:40:41] <PetefromTn_> you are really making progress on that monster.
[01:40:42] <ssi> to keep the tube cool
[01:40:43] <Tom_itx> we did that all the time
[01:40:47] <ssi> yeah... I've been busting ass on it
[01:40:49] <Tom_itx> no need for a stop then
[01:41:04] <Tom_itx> quite repeatable too
[01:41:05] <XXCoder> ahh laser tube cooler
[01:41:09] <XXCoder> co2 eh
[01:41:16] <PetefromTn_> yeah I HAVE a toolchanger LOL but it is just not currently operational due to my inability to get shit done
[01:41:17] <XXCoder> yeah recall you saying so lol
[01:41:34] <XXCoder> *to ssi
[01:41:37] <Tom_itx> still doable
[01:41:39] <ssi> hehe
[01:41:44] <Tom_itx> just fit a holder with a dowel pin
[01:41:57] <PetefromTn_> already have one actually..
[01:42:14] <Tom_itx> just make it part of the program with an OP stop
[01:42:19] <PetefromTn_> It has a point on it and I use it to generally locate shit that is not terribly important LOL.
[01:42:30] -!- h_maximilian has quit [Quit: Leaving.]
[01:42:50] <Tom_itx> no need to worry if the stop slipped then
[01:43:00] <Tom_itx> if it does, you got much bigger problems
[01:43:00] <PetefromTn_> This is really just for fixture location.
[01:44:07] <Tom_itx> good fixture plate will do that
[01:44:26] <Tom_itx> reamed for dowels on one grid and drilled and tapped on an ajacent grid
[01:44:41] <PetefromTn_> I must admit that they had a nice one at the shop I worked in and I used it quite a bit for many different projects.
[01:45:29] <PetefromTn_> http://www.ebay.com/itm/Heavy-Duty-Table-Mounted-Mill-Vise-Work-Stop-made-in-the-USA-/110492587615 Like this only shop built..
[01:46:57] <Tom_itx> we threw those together with bits of scrap and allthread
[01:47:24] <PetefromTn_> yup LOL... simple as shit..
[01:47:28] <os1r1s> PetefromTn_: Have you seen any open designs for the 5 axis type?
[01:47:31] <PetefromTn_> Just gotta find time to make one..
[01:47:45] <PetefromTn_> not sure what you mean>?
[01:48:32] <os1r1s> PetefromTn_:
http://www.roviproducts.com/Mill_Stop.htm
[01:49:14] <PetefromTn_> that looks juicy man... Kinda made me have a stiffie LOL
[01:49:26] <Tom_itx> looks a bit flimsy to me
[01:49:28] <os1r1s> haha
[01:49:31] <PetefromTn_> Don't feel like a hundred to me tho..
[01:50:07] <Tom_itx> not sure i'd admit to spending money on it personally
[01:50:12] <os1r1s> PetefromTn_: Another one ...
http://www.micro-machine-shop.com/5-axis_milling_stop_a.jpg
[01:50:32] <PetefromTn_> I have actually seen that one a lot.
[01:50:46] <PetefromTn_> Never used or handled one so who knows if it is a piece of shit or not..
[01:50:49] <XXCoder> hm so stopkeeps peice from moving towards that side?
[01:51:09] <Tom_itx> it's what you locate your material against
[01:51:10] <PetefromTn_> I don't much like the small footprint on the table.
[01:51:12] <Tom_itx> when loading it
[01:51:16] <XXCoder> ahh
[01:51:34] <Tom_itx> like i said.. a dowel pin in a collet will do nice
[01:51:36] <XXCoder> was thinking wtf wouldnt vice be enough to hold on in first place lol
[01:51:38] <PetefromTn_> it just need to be rigid enough to locate the part under hand pressure.
[01:52:26] <PetefromTn_> you basically slide the part atop the vise parallels and make it contact that pin and then lock down the vise. It does nothing to keep it located that is the vises job.
[01:52:40] <XXCoder> yeah figured it by now lol
[01:52:52] <Tom_itx> they often get in the way of the cutter too
[01:52:55] <PetefromTn_> just tryin to help LOL
[01:53:06] <Tom_itx> another plus for the dowel pin approach
[01:53:32] <PetefromTn_> That five axis one could be angled down but yeah you are right especially for facing ops.
[01:53:33] <Tom_itx> there when you need it and gone when you don't
[01:54:06] <os1r1s> Tom_itx: Scrolling back to read your approach ...
[01:54:08] <Tom_itx> if you move it during milling it defeats the purpose of having it
[01:54:21] <Tom_itx> os1r1s, just a dowel pin in a tool holder
[01:54:31] <Tom_itx> make it part of the program
[01:54:35] <Tom_itx> with an OP stop
[01:55:07] -!- Servos4ever has quit [Quit: ChatZilla 0.9.90.1 [SeaMonkey 2.26.1/20140612173529]]
[01:55:18] <os1r1s> Tom_itx: To indicate the part location in X/Y/Z? Do you use a wire conection with a G31?
[01:55:30] <Tom_itx> we always designated it tool 16 or 20 so it was high enough to not interfere with other tools
[01:55:35] <PetefromTn_> no wires just a mechanical stop
[01:55:37] <Tom_itx> and the programmer would know where it was
[01:56:08] <Tom_itx> os1r1s, no it just comes down and stops to give you a location point for the material
[01:56:24] <os1r1s> Ahh, ok
[01:56:26] <Tom_itx> then you push cycle start again and it carries on with the rest of the code
[01:56:35] <Tom_itx> and it's gone and out of your way
[01:56:57] <PetefromTn_> Yeah we used that approach a bunch of times in the shop too..works well.
[01:57:22] <Tom_itx> shortens setup time too
[01:57:36] <Tom_itx> one less thing to bolt to the table
[01:57:39] <Tom_itx> and adjust
[01:58:38] <Tom_itx> even when setups changed, nearly every machine in the shop had a holder with a dowel pin in the carousel
[01:58:48] <PetefromTn_> so did you mostly setup the stop tool after doing the initial setup in the machine and then take the postion to the cam or just make your adjustments in Cad cam beforehand?
[01:58:56] <Tom_itx> and it was constant so the programmer knew which tool to program
[01:59:42] <Tom_itx> draw the part in cad cam and send it to the operator. all he knew is that it was gonna be another tool
[02:00:00] <ssi> cooling s ystem is running
[02:00:02] <Tom_itx> set X0 off the part edge and Y0 off the back vise jaw
[02:00:05] <Tom_itx> generally
[02:00:17] <ssi> I wonder if the thing will fire with the potentiometer all the way down
[02:00:20] <ssi> ie wired to gnd
[02:00:25] <ssi> I don't really want to wire in a pot to test fire
[02:00:40] <ssi> also I meant to get some acrylic safety glasses at home depot and i forgot completely :'(
[02:00:44] <Tom_itx> i have a WORD template i used to print the tooling and fixture locations for the operators
[02:00:48] -!- jfigie has quit [Quit: Ex-Chat]
[02:00:56] <Tom_itx> and any general instructions
[02:01:07] <XXCoder> oh talking about safety glasses.. any no glare for em?
[02:01:13] <Tom_itx> they would be filed with the part prints
[02:01:16] <ssi> XXCoder: wat?
[02:01:39] <XXCoder> anti-glare
[02:02:24] <ssi> I don't know what you're asking
[02:02:30] <ssi> can you restate your question in the form of a question?
[02:02:38] <PetefromTn_> hehe
[02:02:48] <XXCoder> is there any anti-glare chemical for safety googles or something
[02:03:03] <ssi> I don't know
[02:03:52] <XXCoder> darn ok. place I work at is nice and bright, but googles refexct lights pretty often :P
[02:04:51] <Tom_itx> so get some tinted safety glasses
[02:05:03] <XXCoder> no thanjks lol
[02:05:53] <Tom_itx> anything you would spray on them would probably compromise their safety
[02:06:35] <XXCoder> yeah unfortunate. guess best bet is safety rated glasses
[02:06:41] <Tom_itx> then all you'd have would be a dorky pair of goggles
[02:07:02] <ssi> safety is boring
[02:07:04] <jdh> my Rx safety glasses have anti-glare
[02:07:20] <Tom_itx> ssi, not if you value your eyes
[02:07:23] <Tom_itx> etc
[02:09:06] <Tom_itx> the place i used to work gave us perscription safety glasses
[02:12:10] <Tom_itx> PetefromTn_, alot of times i would include the vise in the cad drawings
[02:12:25] <Tom_itx> i had one drawn up i could just drop in the drawing on a layer
[02:12:44] <Tom_itx> also the material block...
[02:12:51] <PetefromTn_> what did you setup the Z offset for?
[02:13:00] <XXCoder> https://www.youtube.com/watch?v=JlbH3snE5hA
[02:13:33] <Tom_itx> most of the time it would be either 3 or 6" above the base of the material depending on the part and how thick the material
[02:13:45] <Tom_itx> using a 123 block
[02:13:51] <Tom_itx> to set the tools
[02:14:09] <PetefromTn_> for the fixture location?
[02:14:21] <Tom_itx> for the material z location
[02:14:25] <Tom_itx> for safety
[02:14:40] <PetefromTn_> yeah that is what I do basically but not atop the part.
[02:14:42] <Tom_itx> then if you told the machine to go to Z0 it would clear the material and any clamps
[02:15:14] <Tom_itx> we would never set Z0 at the material top
[02:15:23] <PetefromTn_> I am wanting to use this to locate the fixture just in the odd chance the guy I am making this for sells a bazillion and I become a closet millionaire making them in my garage..
[02:15:50] <Tom_itx> just make a nice aluminum plate with grids in it
[02:15:59] <Tom_itx> i even made one for my cheap little sherline
[02:16:32] <Tom_itx> if you do it right your vise will fit right on it and be square when you bolt it down
[02:16:50] <Tom_itx> we always indicated them just to be sure
[02:17:02] <Tom_itx> and seldom had to move them much at all
[02:18:12] <PetefromTn_> meh I don't really want vise mounted to plates. This is actually a vise mounted fixture..
[02:18:36] <Tom_itx> use softjaws for it then
[02:19:49] <Tom_itx> notice in this one (hard to see the vise) i have the vise and material block shown for the operator:
http://tom-itx.ddns01.com:81/~webpage/cnc/P3.jpg
[02:20:05] <PetefromTn_> naah I would like to use the fixed jaws and parallels and some kinda fixture location this is probably NOT gonna be a massive number of parts but ya never know LOL.
[02:20:25] <Tom_itx> it just depends on the part
[02:20:34] <Tom_itx> as to how you hold it most efficiently
[02:22:15] <PetefromTn_> this is mostly just a large plate with a recatangular pocket out of the middle not thru cut and some holes tapped with an outside profile in 1/2 inch material really simple but I MAY have to make a bunch more possible.
[02:23:24] <Tom_itx> sounds like some step softjaws and a dowelpin is all you need for that
[02:23:42] <Tom_itx> or parallels i suppose
[02:23:51] <PetefromTn_> yeah don't even need the step jaws really..
[02:24:07] <Tom_itx> i'd sticky tape the parallels to the vise jaws
[02:24:30] <PetefromTn_> ?
[02:24:51] <Tom_itx> they won't move around on you when you swap parts
[02:25:35] <Tom_itx> double back tape
[02:26:25] <PetefromTn_> huh might try that. Got some carpet tape here.
[02:26:37] <Tom_itx> will you need to profile the blocks or are they to size to begin with?
[02:27:20] <PetefromTn_> no need to do a go around and finish pass of the profile...
[02:27:39] <Tom_itx> then step jaws are out
[02:28:02] <Tom_itx> unless i read that wrong
[02:28:24] <PetefromTn_> yeah that Is why I am making the fixture... Clamp it down to the fixture, drill holes, bolt it down and then finish machining.
[02:28:28] <Tom_itx> i read that as no, need to ....
[02:28:58] <PetefromTn_> It is about 13.5x8 inches and a funky outside shape.
[02:29:27] <Tom_itx> sounds like a work plate would work well for that
[02:29:53] <Tom_itx> 2 dowels in the back to locate it in y, pull them out once clamped
[02:30:13] <PetefromTn_> the interesting thing is the part is made from two different half inch plates both different but they share four holes so the fixture is working good I think.
[02:30:29] -!- XXCoder has quit [Ping timeout: 256 seconds]
[02:30:32] <Tom_itx> use the dowel in the tool holder for X
[02:31:04] <PetefromTn_> yup
[02:31:26] <Tom_itx> pre drill/tap those hole locations in the expendable plate
[02:31:36] <PetefromTn_> actually the plate along the x is not that important. Gonna be sawn off and just fit to the fixture.
[02:32:10] <Tom_itx> fixturing is an art
[02:32:11] <PetefromTn_> clamp to the fixture, drill four holes and screw it down then finish machine.
[02:34:43] -!- XXCoder [XXCoder!~XXCoder@c-24-19-85-77.hsd1.wa.comcast.net] has joined #linuxcnc
[02:34:47] <XXCoder> ohhh
http://www.phoronix.com/scan.php?page=news_item&px=MTc0NDQ
[02:39:14] -!- sumpfralle has quit [Ping timeout: 240 seconds]
[02:41:43] <PetefromTn_> Love watching Top Gear on netflix LOL... THose guys are hilarious.
[02:43:06] <Tom_itx> we've been watching them for days
[02:43:12] <Tom_itx> starting from the beginning
[02:43:21] <PetefromTn_> some cool shows for sure..
[02:43:32] <PetefromTn_> I love the one with the Ariel Atom..
[02:43:37] <Tom_itx> more after their 'adventures'
[02:44:10] <PetefromTn_> I also love watching the Formula 1 drivers run the track...
[02:50:50] <XXCoder> https://i.chzbgr.com/maxW500/4979184128/h8DA9C8FC/
[02:50:56] <XXCoder> old but probably new to you gyuys lol
[02:51:04] -!- asdfasd has quit [Ping timeout: 240 seconds]
[02:51:29] <zeeshan> http://i.imgur.com/dXuuifl.jpg
[02:51:30] <zeeshan> :)
[02:51:35] <zeeshan> cheapo wire rack
[02:52:03] <zeeshan> was getting tired of digging through boxes
[02:52:06] <zeeshan> to find spools of wire
[02:52:07] <Valen> nice
[02:54:28] <Connor> So, question about Coolant nozzles .. Which side.. or both sides.. and if both sides.. would they not cancel each other out to some degree ?
[02:54:51] <XXCoder> from inside
[02:55:14] <XXCoder> was joking but I think there IS some tools that do that? lathe mainly
[02:55:18] <PetefromTn_> My Cincinatti has one pointing to the back of the machine and one pointing from the right side to the left and with lots of flow chips are not a problem.
[02:55:41] <Connor> PetefromTn_: Yea.. I know how your setup is. :) ROFL
[02:55:50] <PetefromTn_> well you asked...
[02:55:59] <Connor> Yea.. I was asking about other setups..
[02:56:16] <PetefromTn_> but you did not specify that...LOL
[02:56:35] <Connor> Saw a setup for servo controlled nozzle. He had one on each side.
[02:56:39] <zeeshan> hi XXCoder
[02:56:44] <XXCoder> yo
[02:57:01] <Connor> Looks easy enough to do..
[02:57:03] <PetefromTn_> Haas machines have controllable coolant nozzles from one side.. they work decent.
[02:57:04] <zeeshan> er
[02:57:07] <zeeshan> http://www.sandvik.coromant.com/SiteCollectionImages/Technical%20guide/Pablo/E%20Drilling/061267_new.jpg
[02:57:10] <zeeshan> talking about that? :D
[02:57:21] <zeeshan> http://www.sandvik.coromant.com/SiteCollectionImages/News/12_2/HPC.jpg
[02:57:24] <zeeshan> theres that fancy one too
[02:57:25] <XXCoder> oh yeah. yeah
[02:58:42] <zeeshan> i wonder how they make those spiral holes
[02:58:48] <Connor> Still too much to do and not enough Ummph to do it..
[02:59:32] <XXCoder> zee dunno. molded into rod pre-cut?
[02:59:40] <PetefromTn_> My cincinatti actually could be ordered with coolant thru spindle but mine does not have it.
[02:59:51] <PetefromTn_> UNFORTUNATELY
[02:59:54] <Connor> By the end of the day.. I don't feel like doing much.. and weekends are recharge time.
[03:00:04] <zeeshan> XXCoder: yea i think casting might be how they do it
[03:01:16] <Connor> I think I'm going to order Ball Screws with double nuts soon.
[03:02:03] <Connor> I need to get my backlash figured out and go ahead and start milling out the ball nut mounts.
[03:02:06] <XXCoder> ball screwing with double nuts :P
[03:03:57] -!- AR_ has quit [Ping timeout: 245 seconds]
[03:05:31] <Connor> The Saddle will need some milling done to it.. and would like to go ahead and get oil groves cut and holes drilled/tapped too.
[03:06:24] <Tom_itx> Connor, coolant nozzles with valves to adjust output
[03:06:58] <PetefromTn_> I used my RF31 to machine all the slots and holes in my RF45
[03:06:58] <Tom_itx> those 'snakes' work pretty good
[03:07:38] <zeeshan> connor saddle needs to be machined
[03:07:40] <zeeshan> to fit double nutrs?
[03:07:52] <zeeshan> if it was a single nut, would it still need to be machined?
[03:08:43] <Connor> zeeshan: Yes.
[03:08:58] <Connor> Have to make a pocket for the nut to sit in.
[03:09:02] <zeeshan> ah
[03:09:08] <Connor> for the table.
[03:09:55] <Connor> the Y, Needs to have have to base opened up to get extended travel for single nut, or slightly more travel that stock with double.
[03:10:04] <PetefromTn_> You know what I am gonna say right... bring it by if you want..
[03:10:09] -!- Flipp_ has quit [Remote host closed the connection]
[03:10:25] <Connor> PetefromTn_: Yup. I plan on it. I need to send you the plans so you can see what we're going to be doing.
[03:11:11] <PetefromTn_> okee..
[03:11:13] <Connor> but, before I can do any of it.. I have to clean up my shop.. then tear it down.
[03:12:01] <Connor> saddle will be easy enough.. it's the base of the mill.. I have to remove the column from it..
[03:12:19] <Connor> which means removing the spindle head..
[03:12:23] <Connor> ugg..
[03:12:36] <PetefromTn_> yeah but it only weighs like 2 lbs right hehehe
[03:13:59] -!- tjtr33 [tjtr33!~tjtr33@76-216-190-185.lightspeed.cicril.sbcglobal.net] has joined #linuxcnc
[03:14:03] <Connor> Umm. No. a wee bit more than that.. I just hope I don't throw my back out trying to take it all apart.
[03:14:25] <Connor> I've never had the column off of it before.. I really don't like the idea of trying to tram it in.
[03:14:52] <Connor> bad enough tramming in the spindle..
[03:14:57] <zeeshan> why
[03:15:01] <zeeshan> it take slike 10 min
[03:15:09] <zeeshan> er nm
[03:15:15] <zeeshan> i dont know your machine :P
[03:16:17] <Connor> Tramming the head is a bit easier with my tramming aids.. but.. I've never done the column.. not sure how to do it.
[03:16:26] <zeeshan> all i see is a way to tilt the spindle about the y axis
[03:16:31] -!- Roguish has quit [Remote host closed the connection]
[03:16:35] <zeeshan> is there way to tilt it about the x axis?
[03:16:39] <zeeshan> (aka knod)
[03:16:44] <Connor> zeeshan: Shims.
[03:16:50] <zeeshan> ;/
[03:17:00] <Connor> for the X axis.
[03:17:12] <zeeshan> yea shimming can get annoying :p
[03:17:37] <Connor> column shimming for X too.. Y is just adjusting the column before locking down the bolts..
[03:18:25] <PetefromTn_> much as I am LOATHE to say it Hoss had a nice video showing a good way to do that..
[03:18:45] <Connor> PetefromTn_: Yea. Rolliedads method
[03:18:55] <PetefromTn_> yeah something like that.
[03:19:04] <zeeshan> i thought the generic method was to put 2 parallels
[03:19:11] <zeeshan> through in a test indicator
[03:19:36] <zeeshan> do the y rotation first
[03:19:39] <zeeshan> then do knod after
[03:20:03] <zeeshan> y rotation you just move the x axis side to side
[03:20:08] <zeeshan> and check for error
[03:20:19] <zeeshan> knod, you just raise/lower the table
[03:22:03] <Connor> Looks like I need a precession dowel rod.
[03:22:11] <zeeshan> no
[03:22:22] <PetefromTn_> I have a large sleeve here that I used for that.
[03:22:30] <zeeshan> you can do it with just parallels
[03:22:33] <zeeshan> mrpete shows how to do it
[03:22:35] <PetefromTn_> it is fround completely..
[03:22:50] <PetefromTn_> ground.
[03:23:20] <zeeshan> http://www.youtube.com/watch?v=HkVXJp61zLg
[03:23:24] <zeeshan> thats a good video
[03:23:36] <ssi> laser has been test fired :D
[03:23:38] <zeeshan> i bet you already have the tools to do it
[03:24:21] <Connor> zeeshan: First thing you have to do is tram the had to the COLUMN.
[03:24:30] <Connor> then tram the head + column to the table.
[03:24:43] <Connor> I have the tool to tram head or head+column to the table..
[03:24:46] <PetefromTn_> yup
[03:24:56] <Connor> it's tramming the head TO the column that is important.
[03:24:57] <zeeshan> i dont have a column!
[03:24:58] <zeeshan> :P
[03:26:54] <Connor> dinner time
[03:27:09] <PetefromTn_> at 11:30?
[03:28:41] <Tom_itx> well you can't have breakfast until you've had dinner...
[03:29:58] <jymmm> http://interestingengineering.com/toyota-create-free-piston-engine-with-no-crankshaft-and-electrical-output/
[03:32:24] <PetefromTn_> well Gnite all.
[03:32:44] -!- PetefromTn_ has quit [Quit: Hello, 911? Yeah, it's caught in the window this time.]
[03:34:04] -!- zzolo has quit [Ping timeout: 260 seconds]
[03:37:18] -!- w32stuxnet has quit [Quit: w32stuxnet]
[03:40:12] -!- tjtr33 [tjtr33!~tjtr33@76-216-190-185.lightspeed.cicril.sbcglobal.net] has parted #linuxcnc
[03:45:01] -!- phantom [phantom!destroy@a89-154-119-158.cpe.netcabo.pt] has joined #linuxcnc
[03:47:28] -!- phantoxeD has quit [Ping timeout: 250 seconds]
[03:59:26] -!- Roguish [Roguish!~chatzilla@c-67-188-44-176.hsd1.ca.comcast.net] has joined #linuxcnc
[04:01:23] -!- sureleo has quit [Quit: Leaving.]
[04:01:58] -!- anth0ny has quit [Quit: anth0ny]
[04:14:27] -!- sureleo has quit [Quit: Leaving.]
[04:19:27] -!- w32stuxnet has quit [Quit: w32stuxnet]
[04:42:32] <ssi> https://vine.co/v/M26P0FjeqAz
[04:42:33] <ssi> weeeeee
[04:42:43] <ssi> https://vine.co/v/M26PDi1d1Z0
[04:44:41] <XXCoder> thats awesome.
[04:48:15] <ssi> I'm so happy it works :D
[04:55:42] <alexchally> ssi, plz get some laser safety glasses if you don't have some!
[04:56:00] <alexchally> not that I don't think you do
[04:56:19] <alexchally> but damn, that is sweet, and its hard to chat on IRC with no eyeballs in your eyeholes
[04:57:42] <Valen> its a frikkin lazor
[04:58:04] <Valen> lol at goggles
[04:58:20] <Valen> I do hope you are using laser goggles suitable for the wavelength involved
[04:58:21] <alexchally> or I guess you could just get 1" thick plexy goggles, it would take a long time to burn through them :D
[04:59:04] <alexchally> Valen: I work with a bunch of very high power/scary wavelength lasers... there is nothing like 15W of 105nm to make you very... cautious
[05:01:23] -!- Fox_Muldr has quit [Ping timeout: 240 seconds]
[05:03:39] -!- Fox_Muldr [Fox_Muldr!quakeman@frnk-5f74077e.pool.mediaWays.net] has joined #linuxcnc
[05:03:39] -!- automata_ [automata_!~Amit@114.143.56.30] has joined #linuxcnc
[05:04:52] -!- Einar1 [Einar1!~Einar@108.90-149-34.nextgentel.com] has joined #linuxcnc
[05:10:27] <ssi> I don't have co2 specific goggles yet, but that's why i was doing the tests with the plastic goggles... they do stop the direct collimated beam, and don't burn through remarkably quickly
[05:10:35] <ssi> I'm gonna order some proper co2 goggles from mcmaster tomorrow
[05:10:41] -!- linuxcnc-build has quit [Remote host closed the connection]
[05:12:43] -!- jerryitt has quit [Quit: Connection closed for inactivity]
[05:13:00] -!- knownasilya has quit [Quit: Connection closed for inactivity]
[05:14:34] <XXCoder> good
[05:14:43] <XXCoder> blindness is SCARY ti nme
[05:15:35] <ssi> I wonder about ordering tubes from alibaba rather than ebay
[05:15:41] <ssi> seems a fair bit cheaper for the higher power tubes
[05:24:39] -!- sylphiae [sylphiae!~sylphiae@12.39.6.101] has joined #linuxcnc
[05:38:29] <Valen> aliexpres has a not too crap reputation
[05:42:34] -!- IvelfanFr_ has quit [Ping timeout: 240 seconds]
[05:48:47] -!- sureleo has quit [Quit: Leaving.]
[05:52:10] -!- Gulpi has quit [Ping timeout: 264 seconds]
[05:57:42] <Loetmichel> XXCoder/ ssi: you know the sing at tha laser lab? "Protect your remaining eye!" ;-)
[05:57:52] <Loetmichel> sign
[05:58:36] prtksxna is now known as zz_prtksxna
[05:59:33] -!- Tecan has quit [Ping timeout: 255 seconds]
[06:00:20] <Valen> burning in the beam doesn't mean you won't get a sufficent dose through them to be an issue
[06:00:26] <Valen> wrt goggles
[06:02:59] -!- sylphiae has quit [Ping timeout: 256 seconds]
[06:05:53] -!- kwallace3 has quit [Ping timeout: 240 seconds]
[06:08:13] <ssi> I'm gonna order proper goggles tomorrow, and I have plenty of motion work to do between now and then that won't involve firing the tube
[06:33:25] -!- ries has quit [Quit: ries]
[06:46:11] -!- archivist_herron has quit [Ping timeout: 264 seconds]
[06:48:11] -!- anth0ny has quit [Quit: anth0ny]
[06:49:41] -!- Deejay [Deejay!~Deejay@unaffiliated/dj9dj] has joined #linuxcnc
[06:50:02] <Deejay> moin
[06:51:56] -!- alexchally has quit [Ping timeout: 240 seconds]
[06:58:59] -!- archivist_herron [archivist_herron!~herron@herronwindows.co.uk] has joined #linuxcnc
[07:14:22] -!- larryone has quit [Ping timeout: 245 seconds]
[07:27:54] -!- ries [ries!~ries@D979EA84.cm-3-2d.dynamic.ziggo.nl] has joined #linuxcnc
[07:29:38] -!- The_Ball has quit [Remote host closed the connection]
[07:31:55] -!- sirdancealot [sirdancealot!~koo5@37-48-32-254.tmcz.cz] has joined #linuxcnc
[07:32:50] -!- syyl [syyl!~sg@p4FD111F9.dip0.t-ipconnect.de] has joined #linuxcnc
[07:41:54] -!- mle has quit [Read error: Connection reset by peer]
[07:46:11] -!- badon has quit [Ping timeout: 264 seconds]
[07:52:16] -!- rob_h [rob_h!~robh@176.250.56.144] has joined #linuxcnc
[07:54:58] -!- balestrino [balestrino!~balestrin@131.114.31.66] has joined #linuxcnc
[07:57:05] -!- sumpfralle [sumpfralle!~lars@on1.informatik.uni-rostock.de] has joined #linuxcnc
[08:03:46] -!- asdfasd [asdfasd!~332332@94.10.228.151] has joined #linuxcnc
[08:25:42] -!- micges-dev has quit [Quit: Wychodzi]
[08:27:31] -!- The_Ball [The_Ball!~ballen@c114-77-179-73.hillc3.qld.optusnet.com.au] has joined #linuxcnc
[08:42:48] zz_prtksxna is now known as prtksxna
[08:44:55] -!- syyl_ws [syyl_ws!~sg@p4FD111F9.dip0.t-ipconnect.de] has joined #linuxcnc
[08:55:02] md2 is now known as Guest62392
[08:57:37] -!- md-2 has quit [Ping timeout: 250 seconds]
[09:05:57] <pingufan> cradek: Hi, do you have a little bit of tiome for me, please? (adding .tap to "open file" browser)
[09:08:51] <pingufan> I cannot find out how to extend the search mask.
[09:13:18] -!- larryone has quit [Client Quit]
[09:16:23] -!- c-bob|| [c-bob||!~c@unaffiliated/c-bob] has joined #linuxcnc
[09:17:27] -!- syyl_ws has quit [Quit: Verlassend]
[09:21:48] -!- phantoxe [phantoxe!~destroy@acarlosss.broker.freenet6.net] has joined #linuxcnc
[09:25:29] <pingufan> Deejay, good morning!
[09:25:48] -!- sureleo has quit [Quit: Leaving.]
[09:27:57] <pingufan> does somebody know how to extend the file browser's file extensions in AXIS? It shall also show .tap files, they are identical to .ngc, but this crazy "Cut2D" software always stores as .tap.
[09:36:27] -!- tronwizard has quit [Ping timeout: 255 seconds]
[09:45:30] -!- Guest62392 has quit [Remote host closed the connection]
[09:48:06] <Deejay> moin pingufan
[09:50:17] -!- md-2 has quit [Ping timeout: 245 seconds]
[09:54:25] -!- w32stuxnet has quit [Quit: w32stuxnet]
[09:54:47] -!- Smidge204__ has quit [*.net *.split]
[09:54:48] -!- GJdan has quit [*.net *.split]
[09:54:48] -!- jymmm has quit [*.net *.split]
[09:54:48] -!- Demiurge has quit [*.net *.split]
[09:54:48] -!- tumdedum has quit [*.net *.split]
[09:54:48] -!- jdh has quit [*.net *.split]
[09:54:49] -!- aude has quit [*.net *.split]
[09:54:49] -!- marvi has quit [*.net *.split]
[09:54:49] -!- humble_sea_bass has quit [*.net *.split]
[09:54:56] -!- jdh [jdh!~jdh@miranda.org] has joined #linuxcnc
[09:54:57] -!- humble_sea_bass [humble_sea_bass!~hsb@ma.sdf.org] has joined #linuxcnc
[09:55:02] -!- tumdedum [tumdedum!~tumdedum@unaffiliated/espiral] has joined #linuxcnc
[09:55:19] -!- jymmm [jymmm!~jymmm@unaffiliated/jymmm] has joined #linuxcnc
[10:00:22] <archivist> pingufan, find where the file open dialog is in the source and modify the filetypes list to suit you
[10:00:44] -!- asdfasd has quit [Ping timeout: 240 seconds]
[10:11:05] <archivist> pingufan, specifically this line or whatever it looks like now axis.py: "-filetypes", ((_("rs274ngc files"), ".ngc"),))
[10:17:39] -!- badon [badon!~badon@pdpc/supporter/active/badon] has joined #linuxcnc
[10:22:46] -!- skunkworks has quit [Ping timeout: 264 seconds]
[10:25:11] <pingufan> archivist: I had the silent hope that such things can be preset in a config file. :) So I will run a cron job renaming the file in the background.
[10:25:54] <archivist> pingufan, it is a simple edit as that can be a list
[10:26:08] <archivist> simpler than a cron job
[10:26:29] -!- skorasaurus has quit [Ping timeout: 256 seconds]
[10:28:31] <jdh> I use Cut2D all the time. Never had it make a .tap file
[10:29:12] <DaViruz> cut2d makes a .tap if you set the postprocessor to just gcode
[10:29:25] <DaViruz> if you set it to emc2 it makes a .ngc
[10:29:37] <jdh> much easier than changing axis
[10:29:41] <archivist> even easier!
[10:30:05] <DaViruz> though i believe you need cut2d 1.5 to get the emc2 post
[10:30:52] <jdh> I used it with 1.0. Had to download it though
[10:33:01] <DaViruz> oh
[10:33:49] <pingufan> But don't I need the whole sources of AXIS to change that?
[10:34:24] -!- Deejay has quit [Quit: bbl]
[10:34:52] <jdh> you have it, but you don't need to change it.
[10:35:08] <jdh> use the correct cut2d postprocessor and it will default to .ngc
[10:35:15] -!- w32stuxnet has quit [Quit: w32stuxnet]
[10:35:16] <DaViruz> http://forum.vectric.com/viewtopic.php?p=88173&sid=a027b9a6d85d3528a1df00b0b532ca82#p88173
[10:35:25] <jdh> or use the same one you are using now, but when it prompts you for the file name, put in .ngc instead of .tap
[10:36:09] <jdh> it's not like cut2d makes the file without your assistance. You hit 'save' on the .tap file every time.
[10:38:28] <DaViruz> it's pretty simple to modifiy the cut2d post processors too, just open one in a text editor and among the first lines are FILE_EXTENSION = "tap"
[10:39:34] <pingufan> Oh, thank you!
[10:41:23] <jdh> PROGRAM_EXTENSION = .TAP Cut2D files with wrong post
[10:41:28] <jdh> or add that to your .ini file
[10:42:06] <jdh> maybe. Using the emc2 post in cut2d would be better.
[10:42:56] -!- MacGalempsy has quit [Remote host closed the connection]
[10:49:45] -!- ashcan__ [ashcan__!~robert@navsoft.plus.com] has joined #linuxcnc
[10:54:19] md2 is now known as Guest64317
[10:54:19] -!- bertrik [bertrik!~quassel@rockbox/developer/bertrik] has joined #linuxcnc
[10:55:20] -!- Lathe_newbie [Lathe_newbie!~newbie@46-126-219-87.dynamic.hispeed.ch] has joined #linuxcnc
[10:57:53] -!- md-2 has quit [Ping timeout: 240 seconds]
[10:58:48] -!- archivist_herron has quit [Ping timeout: 260 seconds]
[11:11:40] -!- archivist_herron [archivist_herron!~herron@herronwindows.co.uk] has joined #linuxcnc
[11:11:45] -!- thomaslindstr_m has quit [Quit: Leaving...]
[11:14:21] <pingufan> jdh: If I enter .ngc as filename in Cut2D, it makes a ".ngc.tap" filename.
[11:15:00] -!- theorbtwo has quit [Ping timeout: 255 seconds]
[11:15:39] -!- skunkworks [skunkworks!~chatzilla@68-115-41-210.static.eucl.wi.charter.com] has joined #linuxcnc
[11:16:21] <jthornton> probably need to change the post processor
[11:16:21] -!- h_maximilian [h_maximilian!~bonsai@p549DE68F.dip0.t-ipconnect.de] has joined #linuxcnc
[11:16:26] -!- h_maximilian [h_maximilian!~bonsai@p549DE68F.dip0.t-ipconnect.de] has parted #linuxcnc
[11:30:24] -!- mutilator [mutilator!muti@65.111.213.158] has joined #linuxcnc
[11:31:04] <mutilator> hey guys, anyone know of a table vice similar to
[11:31:05] <mutilator> http://www.harborfreight.com/4-inch-jaw-capacity-drill-press-vise-30999.html
[11:31:20] <mutilator> except not quite as tall
[11:32:09] -!- sureleo has quit [Quit: Leaving.]
[11:32:14] -!- sumpfralle has quit [Ping timeout: 240 seconds]
[11:32:27] <archivist> heh that is a short one with not enough metal for hard work
[11:32:38] <mutilator> yea
[11:32:44] <mutilator> i'm looking to hold small objects
[11:32:59] <archivist> define small :)
[11:33:00] <mutilator> easier to vice it in than to clamp down
[11:33:42] <mutilator> um
[11:33:53] <mutilator> 1.5x0.5"
[11:34:21] <jthornton> that is a crummy vise and barely good for a drill press... wanna know how I know?
[11:34:35] <archivist> ah big :) I often make stuff on the end of a stick
http://gears.archivist.info/gears/IMG_1214_hires.JPG
[11:34:45] <mutilator> i wasnt asking if it was a good vise
[11:35:31] <mutilator> thats tiny not small
[11:36:22] <archivist> also for plate work I clamp down a sheet
[11:36:39] <archivist> or mount on a pillar
[11:37:38] <mutilator> http://www.ebay.com/itm/REAL-Capacity-Tiny-USB-Flash-Drive-8GB-Metal-Ultra-thin-Mini-Flash-Memory-Stick-/281391446814
[11:37:40] <mutilator> i have a bunch of these
[11:38:39] <archivist> or clamp in a jig with an outer ring
http://www.collection.archivist.info/searchv13.php?searchstr=racing
[11:39:49] -!- Smidge204__ [Smidge204__!~UNICKS@ool-44c75868.dyn.optonline.net] has joined #linuxcnc
[11:42:17] -!- Lathe_newbie has quit [Ping timeout: 250 seconds]
[11:45:13] -!- Tecan [Tecan!~fasdf@unaffiliated/unit41] has joined #linuxcnc
[11:47:43] -!- Tecan has quit [Client Quit]
[11:52:59] -!- knownasilya has quit [Quit: Connection closed for inactivity]
[11:55:19] <Tom_itx> pingufan, in your main .ini file add:
[11:55:21] <Tom_itx> [FILTER]
[11:55:21] <Tom_itx> PROGRAM_EXTENSION = .tap
[11:55:25] <Tom_itx> [FILTER]
[11:55:25] <Tom_itx> PROGRAM_EXTENSION = .tap
[11:55:31] <Tom_itx> woops
[11:57:35] -!- theorbtwo [theorbtwo!~theorb@cpc8-swin16-2-0-cust252.3-1.cable.virginm.net] has joined #linuxcnc
[11:58:28] * jthornton hears an echo
[11:59:17] <Tom_itx> was reading scrollback when i posted that and didn't realize i did it since the first one didn't appear on my screen :)
[12:00:14] <Tom_itx> either that or it's just the hills around you
[12:03:05] <jdh> pingufan: that's pretty lame.
[12:03:37] <Tom_itx> how so?
[12:03:49] <Tom_itx> i'd never heard of .ngc files until i saw linuxcnc
[12:03:52] <jdh> but, use the correct post and life is better anyway. There were/are 4 choices for EMC2. metric/imperial and arcs or segments
[12:03:59] <Tom_itx> we always used .txt extensions :)
[12:04:19] <jdh> <pingufan> jdh: If I enter .ngc as filename in Cut2D, it makes a ".ngc.tap"
[12:04:43] <Tom_itx> so it want's to default to .tap extension...
[12:05:06] <jdh> yeah, if you type in foo.ngc though it should (IMO) leave you alone.
[12:05:12] <Tom_itx> i'm sure the author had some brilliant reasoning
[12:05:46] <jthornton> OneCNC is just as annoying if you type in foo.ngc it changes it to foo.NGC
[12:05:55] <jdh> I think it is a commondialog thing. Notepad adds a .txt if you leave it on 'text files' when saving vs. 'all files'
[12:07:32] <Tom_itx> jthornton, does it take long filenames or 8.3 like dos did?
[12:07:44] <Tom_itx> that's likely a dos leftover
[12:07:56] <Tom_itx> it would default to upper case too iirc
[12:08:06] <jthornton> it uses long file names
[12:08:24] <jthornton> it's just a programmer error
[12:08:52] <jthornton> if I click on foo.ngc to save an edit it does not change the extension
[12:09:09] <Tom_itx> odd
[12:09:41] <jthornton> they are from Australia...
[12:12:23] <jthornton> for anyone that is interested I've add a bit more
http://gnipsel.com/files/sfc/sfc-0.8.zip
[12:14:05] -!- automata__ [automata__!~Amit@114.143.56.30] has joined #linuxcnc
[12:14:17] -!- automata_ has quit [Read error: Connection reset by peer]
[12:15:29] <Tom_itx> JT-Shop, what is that?
[12:17:27] <jthornton> machinist calculator
[12:18:05] -!- automata_ [automata_!~Amit@114.143.56.30] has joined #linuxcnc
[12:18:12] -!- automata__ has quit [Read error: Connection reset by peer]
[12:19:20] <jthornton> been working on the drill calculator part
[12:20:17] <Tom_itx> guess i didn't realize you were working on that
[12:21:17] <Tom_itx> mill1.5.zip falls in the wrong directory :)
[12:21:18] <jthornton> I just got back to trying to get the drill feed/speed going
[12:22:07] <Tom_itx> call cleveland twist drill and i bet they'd send you a slide rule for it
[12:22:22] <Tom_itx> i've got 5-6 slide rules for various things
[12:22:28] <Tom_itx> from trade shows...
[12:23:43] <Tom_itx> l8r..
[12:23:48] <jthornton> I'd have to get my magnifier on to read a slide rule
[12:32:08] -!- Valen has quit [Quit: Leaving.]
[12:36:34] -!- syyl has quit [Ping timeout: 240 seconds]
[12:40:30] -!- Guest64317 has quit [Remote host closed the connection]
[12:40:52] -!- skunkworks_ [skunkworks_!~skunkwork@68-115-41-210.static.eucl.wi.charter.com] has joined #linuxcnc
[12:48:28] -!- rosslyoung has quit [Ping timeout: 260 seconds]
[12:49:13] -!- thesuss has quit [Ping timeout: 246 seconds]
[12:49:21] thesuss_ is now known as thesuss
[12:52:23] -!- larryone has quit [Ping timeout: 240 seconds]
[12:56:48] -!- pingufan has quit [Quit: Konversation terminated!]
[12:57:22] -!- b_b has quit [Changing host]
[12:58:40] -!- ravenlock has quit [Remote host closed the connection]
[13:01:32] -!- balestrino has quit [Ping timeout: 245 seconds]
[13:05:51] -!- howzus has quit [Client Quit]
[13:19:35] -!- FinboySlick [FinboySlick!~shark@74.117.40.10] has joined #linuxcnc
[13:52:55] -!- zz_Groguard [zz_Groguard!~Groguard@ip68-227-247-165.ph.ph.cox.net] has joined #linuxcnc
[13:53:09] zz_Groguard is now known as Groguard
[13:56:31] prtksxna is now known as zz_prtksxna
[13:58:15] -!- c-bob|| has quit [Ping timeout: 240 seconds]
[14:07:04] zz_prtksxna is now known as prtksxna
[14:21:41] -!- sumpfralle [sumpfralle!~lars@on1.informatik.uni-rostock.de] has joined #linuxcnc
[14:25:47] -!- dan2k3k4 has quit [Ping timeout: 264 seconds]
[14:28:54] -!- sumpfralle has quit [Quit: Leaving.]
[14:29:54] <ssi> morn
[14:30:18] prtksxna is now known as zz_prtksxna
[14:37:37] zz_prtksxna is now known as prtksxna
[14:38:51] -!- thesuss has quit [Quit: Page closed]
[14:42:00] -!- tronwzrd [tronwzrd!tronwizard@24.229.164.191.res-cmts.sm.ptd.net] has joined #linuxcnc
[14:43:09] tronwzrd is now known as tronwizard
[14:49:13] prtksxna is now known as zz_prtksxna
[14:51:15] <MrSunshine> any tips on what kind of router bit to use for lithophanes? i want a quite small one (ballnosed type) but i want the rigidity of a say 90 deg V bit =)
[14:55:02] zz_prtksxna is now known as prtksxna
[14:56:06] <SpeedEvil> you also get blunt v ones
[14:57:32] <MrSunshine> tapered ballnose bits i guess is what im looking for =)
[14:57:45] -!- toner has quit [Ping timeout: 255 seconds]
[14:58:21] -!- kwallace has quit [Read error: No route to host]
[14:59:23] -!- anth0ny has quit [Quit: anth0ny]
[15:01:10] -!- k6mle-CNC has quit [Ping timeout: 246 seconds]
[15:06:52] -!- alexchally [alexchally!~alexchall@131.252.138.250] has joined #linuxcnc
[15:08:07] -!- ler_hydra [ler_hydra!~ler_hydra@sailor-link.olf.sgsnet.se] has joined #linuxcnc
[15:10:53] -!- toner [toner!~ink@c-71-198-91-97.hsd1.ca.comcast.net] has joined #linuxcnc
[15:10:55] -!- bertrik has quit [Ping timeout: 272 seconds]
[15:12:42] -!- jduhls has quit [Ping timeout: 245 seconds]
[15:14:25] prtksxna is now known as zz_prtksxna
[15:20:55] -!- FinboySlick has quit [Quit: Leaving.]
[15:22:07] zz_prtksxna is now known as prtksxna
[15:25:08] -!- quiqua has quit [Quit: quiqua]
[15:27:50] -!- Nick001-shop [Nick001-shop!~chatzilla@50.107.167.148] has joined #linuxcnc
[15:29:01] -!- skorasaurus has quit [Remote host closed the connection]
[15:29:14] -!- automata_ has quit [Ping timeout: 255 seconds]
[15:34:00] -!- skors has quit [Remote host closed the connection]
[15:34:59] <Einar1> jdszaz4
[15:35:00] <Einar1> 'æød
[15:35:00] <Einar1> +0984rew
[15:35:02] <Einar1> 087643wq4
[15:35:05] -!- skorasaurus has quit [Ping timeout: 255 seconds]
[15:37:04] <archivist> you need a new password or kick the cat off the keyboard
[15:37:10] -!- skorasaurus2 has quit [Ping timeout: 260 seconds]
[15:37:11] -!- dan2k3k4 has quit [Ping timeout: 264 seconds]
[15:40:48] <Smidge204__> Or have your cat generate a new password
[15:43:33] -!- w32stuxnet has quit [Quit: w32stuxnet]
[15:43:45] -!- skors has quit [Remote host closed the connection]
[15:45:46] -!- FinboySlick [FinboySlick!~shark@74.117.40.10] has joined #linuxcnc
[15:45:57] <alexchally> the problem with that is that cats are notoriously poor at remembering what password they made for you
[15:46:44] -!- Connor has quit [Read error: No route to host]
[15:48:15] -!- dan2k3k4 has quit [Ping timeout: 240 seconds]
[15:49:08] -!- Connor [Connor!~Connor@24.214.127.194] has joined #linuxcnc
[15:49:10] -!- PetefromTn_ [PetefromTn_!~IceChat9@66-191-252-204.dhcp.kgpt.tn.charter.com] has joined #linuxcnc
[15:50:27] -!- amiri_ has quit [Read error: Connection reset by peer]
[15:55:12] -!- FinboySlick has quit [Quit: Leaving.]
[15:55:49] <Loetmichel> soo, work done for todday... now i just have to make 11 more sets and then the printers can come in for shielding... ->
http://www.cyrom.org/palbum/main.php?g2_itemId=15065
[15:56:25] prtksxna is now known as zz_prtksxna
[15:57:59] -!- skors has quit [Ping timeout: 256 seconds]
[15:59:34] -!- skorasaurus has quit [Ping timeout: 260 seconds]
[16:02:23] -!- FinboySlick [FinboySlick!~shark@74.117.40.10] has joined #linuxcnc
[16:10:46] -!- alexchally has quit [Ping timeout: 260 seconds]
[16:11:03] -!- rob_h has quit [Ping timeout: 240 seconds]
[16:11:52] -!- K6MLE has quit [Ping timeout: 246 seconds]
[16:13:21] -!- tjtr33 [tjtr33!~tjtr33@192.34.28.89] has joined #linuxcnc
[16:14:02] * Tom_itx wrings his shirt out
[16:14:09] <Tom_itx> must be like 80% RH here
[16:14:18] <tjtr33> hello, any suggestions for multi file text editor on windows?
[16:14:19] <Tom_itx> gonna hit 100F
[16:14:39] <Tom_itx> tjtr33, i use programmers notepad
[16:14:44] <jdh> tjtr33: notepad++
[16:14:46] <jthornton> notepad ++
[16:14:53] <tjtr33> PDE? seem to remember that, thx
[16:17:32] <jthornton> dang busted air line on the CHNC... off to town to get some new fittings
[16:17:34] <tjtr33> due to wacky windows env, will try notepad++ with 'installer' hope it doesnt trash clients sys
[16:17:58] <jdh> it's pretty benign.
[16:18:12] <jthornton> yea, I've been using it for years
[16:18:18] <jdh> does add 'edit with notepad++' to context menu if you let it.
[16:18:29] <jthornton> aye
[16:18:37] <jdh> has a nice search-all-files-in-dir too
[16:18:42] <Tom_itx> jthornton, thanks for reminding me
[16:18:53] <Tom_itx> i busted an air hose the other day too...
[16:18:59] <Tom_itx> need a new end for it
[16:18:59] <jthornton> lol
[16:19:03] <Tom_itx> :)
[16:19:09] <Tom_itx> hose went everywhere
[16:19:13] <jdh> HONEYWELL S&C WLS1A00AQBT1 LIMIT SWITCH, WIRELESS,
[16:19:24] <jthornton> this one is for my collet closer and was almost goo
[16:19:25] <tjtr33> Festo! great tubing and cnxrs
[16:19:34] <Tom_itx> coiled air line
[16:19:38] <jthornton> tough to get Festo at Menards
[16:19:43] <Tom_itx> need a new swivel fitting
[16:19:55] <Tom_itx> wonder who sells just the fittings...
[16:20:06] <jthornton> mcmaster carr
[16:20:11] <Tom_itx> local...
[16:20:25] <Tom_itx> there used to be a place but i think they may be closed now
[16:20:30] <jdh> HF
[16:20:36] <Tom_itx> meh
[16:20:39] <Tom_itx> i'll pass on them
[16:20:44] <Tom_itx> i want it to last
[16:21:09] <jdh> Lifetime Warranty!
[16:21:16] <jdh> or 6 minutes, whichever comes fist
[16:21:41] <Tom_itx> there's several industrial supplies here
[16:21:46] <Tom_itx> i'm sure grainger has em
[16:21:57] -!- Komzpa has quit [Ping timeout: 245 seconds]
[16:25:49] <jymmm> And vaseline too, because if you get it from grainger, you'll need it!
[16:25:57] <Tom_itx> no kidding
[16:26:09] <Tom_itx> that would be a last resort
[16:26:15] <Tom_itx> below HF even :)
[16:26:31] <jymmm> no sit, huh
[16:26:33] <jymmm> shit*
[16:27:04] <Tom_itx> there's a place over by Stuart's shop but i forget the name of it...
[16:27:25] <tjtr33> stuarts shop would have it :)
[16:27:39] <Tom_itx> yeah but those are probably in use
[16:28:59] -!- bedah [bedah!~bedah@g224242139.adsl.alicedsl.de] has joined #linuxcnc
[16:29:46] <tjtr33> notepad++ is nice, muilti file, tabbed and folding thx!
[16:30:06] <Tom_itx> http://www.pnotepad.org/
[16:30:09] <Tom_itx> there's the other one
[16:30:11] <Tom_itx> for comparison
[16:30:34] <Tom_itx> it came with avr-gcc
[16:35:44] -!- Roguish has quit [Remote host closed the connection]
[16:42:43] -!- jerryitt has quit [Quit: Connection closed for inactivity]
[16:50:30] <zeeshan> http://imgur.com/gallery/HgPPM6X
[16:50:31] <zeeshan> hah
[16:51:31] <cradek> that's pretty, but should be in conduit...?
[16:52:13] <Smidge204__> Depends on the codes, so not necessarily.
[16:52:29] <jymmm> is it rolmex?
[16:52:53] <Smidge204__> Probably
[16:53:11] -!- skorasaurus has quit [Remote host closed the connection]
[16:53:12] -!- ler_hydra has quit [Remote host closed the connection]
[16:53:18] <zeeshan> thats house wiring
[16:54:29] <Connor> Who the heck cables like that..
[16:54:37] <jymmm> Wht is that, a 200A main panel, then a sub panel next to it?
[16:54:38] -!- zeitue has quit [Remote host closed the connection]
[16:54:40] <Smidge204__> Someone who cares
[16:55:10] <Connor> That wouldn't be easy to do.. Romex can be a b!tch to deal with..
[16:55:12] -!- sirdancealot has quit [Ping timeout: 255 seconds]
[16:56:05] <jymmm> I don't care for the the way the ourlets are just free wired the way they are
[16:56:26] <jymmm> you know some dumbass is gonna hang something from it
[16:56:31] <Smidge204__> Meh, it's fine.
[16:56:37] <Connor> Yea. I noticed that. Kinda makes it look ugly.
[16:56:57] <jymmm> They could have used a 2 gang box for that
[16:57:01] <Connor> I would have used a Duplex box.
[16:57:04] <Connor> yea.
[16:57:24] <Smidge204__> If that little floorplan is for the building it's in, that must be a hell of a house
[16:57:48] <jymmm> I'm guessing a 1800+ sf home
[16:58:23] <jymmm> RED being 220, kitchen?
[16:58:40] -!- skorasaurus has quit [Read error: Connection reset by peer]
[16:58:42] <jymmm> nfc on the sub panel
[16:59:35] <Smidge204__> They're certainly not out of circuits int he main panel
[16:59:43] <ssi> https://pbs.twimg.com/media/BtKdh2QIUAAD-n1.jpg
[16:59:48] <ssi> it's hard not to look cool in laser goggles
[16:59:59] <jymmm> Smidge204__: They must be, they added a sub-panel on the left
[17:00:30] <jymmm> ssi: Those are NOT laser goggles. They don't warp around on the sides.
[17:00:34] <jymmm> wrap*
[17:00:44] <ssi> then someone owes me a bunch of money and an explanation
[17:00:44] <Smidge204__> That looks to be a 42ckt panel. There are not 42 ckts worth fo wiers coming out of that.
[17:00:48] <ssi> because they're sold as laser goggles
[17:01:08] <jymmm> PT Barnum Lives!!!
[17:01:19] <ssi> http://www.phillips-safety.com/laser-safety/laser-safety-glasses/shop-by-laser-filters/polycarbonate-filters/co2-eximer/co2-eximer-model-808-s.html
[17:01:35] <ssi> I suppose they're lying to me tho
[17:01:44] <Smidge204__> Maybe they have a backup power source, like a generator, and have sub-paneled for standby circuits
[17:01:50] -!- dway has quit [Quit: NOOOOOOooooooooo……]
[17:01:58] <ssi> cause jymmmmmmm the almighty is the one source of truth in the universe
[17:02:02] <Smidge204__> Or maybe they're renting out part fo the building and it's submetered
[17:02:04] <jymmm> ssi: "No sweety, size doesn't matter"
[17:02:31] <ssi> and they do wrap around on the sides, just not clear
[17:03:39] <ssi> but it's ok; I wouldn't feel at home in here without either you or the cap'm shitting on everything I do
[17:04:53] <CaptHindsight> ssi: I'd stop following my advice then
[17:05:07] -!- Deejay [Deejay!~Deejay@unaffiliated/dj9dj] has joined #linuxcnc
[17:05:23] <Smidge204__> Including that advice?
[17:05:24] <ssi> I don't follow your advice, fear not :)
[17:05:31] <PetefromTn_> Oh my EYES!!! LOL
[17:05:34] <Smidge204__> Paradox loop!
[17:05:37] <Deejay> re
[17:06:07] <CaptHindsight> it's from the revisionists handbook :p
[17:06:54] <PetefromTn_> I thought we was all friends in here man.. what was I thinkin'?? hehhe
[17:07:05] <ssi> we are all friends in here
[17:07:10] <ssi> some of us just moreso than others :D
[17:07:32] <PetefromTn_> yup friends that shit on everything you do of course..
[17:07:43] <ssi> I dunno about you, but most of my friends shit on everything I do
[17:07:54] <PetefromTn_> is it all shitty?
[17:08:09] <ssi> I suppose
[17:08:19] <PetefromTn_> that's some kinda shit man...
[17:08:27] <PetefromTn_> wonder what their shittin' problem is..
[17:08:39] <PetefromTn_> damn guys can't be bothered to give a shit...
[17:08:41] <Smidge204__> Maybe your friends are just full of shit
[17:08:45] <PetefromTn_> jeez I gotta take a shit..
[17:08:58] <PetefromTn_> This Popcorn kinda tastes like shit.
[17:09:43] <PetefromTn_> If I don't get this damn drawing finished and cut some parts I am gonna be in DEEP ...... KIMCHI...?
[17:09:53] -!- skorasaurus has quit [Ping timeout: 240 seconds]
[17:10:29] <PetefromTn_> Okay it is past now I feel better.. kinda got carried away. Sorry!
[17:10:38] <PetefromTn_> ;)
[17:10:40] <ssi> glad you got it out of your system
[17:11:31] -!- patrickarlt has quit [Ping timeout: 255 seconds]
[17:11:54] <PetefromTn_> me too man...shit I thought I lost it there for a minute.
[17:12:07] -!- IchGuckLive [IchGuckLive!~chatzilla@95-89-98-199-dynip.superkabel.de] has joined #linuxcnc
[17:12:12] <IchGuckLive> hi all B)
[17:12:20] <PetefromTn_> Hey Ich.
[17:12:25] <kb8wmc> good day to you Ich
[17:13:28] <IchGuckLive> ;-)
[17:13:42] <PetefromTn_> Have you ever done a big 3d model and shown it to a customer and sold the part job and then when you go to machine it realize it is NOT GONNA WORK LOL?
[17:14:21] <IchGuckLive> then you are to blame as you are constructor
[17:14:32] <PetefromTn_> but of course I am....jeez
[17:14:58] <IchGuckLive> i show and hammer it to all the students construct as yoiu will build it
[17:14:59] <PetefromTn_> now I gotta fix it without radically changing the damn model to make it work correctly.
[17:15:02] <Connor> PetefromTn_: What did you do ?
[17:15:14] <IchGuckLive> a 20mm pin does not fit a 10mm hole
[17:15:16] <CaptHindsight> customers most often ask for solutions to the corner they have painted themselves into
[17:15:27] <PetefromTn_> I am working on a custom car part for those RX7 dudes...
[17:15:37] <IchGuckLive> even worse a 10mm pin does not work in 20mm hole
[17:15:46] <PetefromTn_> I did a nice cool looking 3d model of what I want to build for them and sold the job.
[17:15:53] <archivist> upgrade so it works charge more and make it for less...profit
[17:16:13] <CaptHindsight> IchGuckLive: ny customers would have that problem but insist that it has to work with that size difference
[17:16:14] <PetefromTn_> Now when I got home I was going over it and realized the part it holds will not fit correctly with the larger standoffs I decided to jazz it up with..
[17:16:47] <PetefromTn_> Adding more BEEF to it screwed the pooch...LOL
[17:16:49] <Connor> PetefromTn_: Well.. re-design it and let'm know. It happens.
[17:17:05] <IchGuckLive> cars can be reconfigurt its only thin steel
[17:17:20] <IchGuckLive> a simple grinder will give you lots of space
[17:17:25] <PetefromTn_> It is no big deal really I just need to widen the frame just a tad bit and there is ample room on the sides for that. Just not the front so the placement of the standoffs will be different.
[17:17:50] <Connor> They probably won't notice..
[17:18:00] <Connor> unless they have the 3D model in front of them.
[17:18:05] <PetefromTn_> Honestly I THINK the subtle changes I need to make here will not even be noticeable. They approved the drawing just looking at it and I never left them a copy so it is no big deal
[17:18:20] -!- Roguish [Roguish!~chatzilla@c-67-188-44-176.hsd1.ca.comcast.net] has joined #linuxcnc
[17:18:23] <PetefromTn_> Just having to back up and punt with my drawing is all. Takes some more time.
[17:18:28] <IchGuckLive> PetefromTn_: call to needs to be adjust at mounting
[17:18:41] <CaptHindsight> IchGuckLive: to be more accurate one would be a round 10mm hole and the other a 10mm square peg :)
[17:18:42] -!- ve7it [ve7it!~LawrenceG@S01060014d19d0b68.pk.shawcable.net] has joined #linuxcnc
[17:18:43] <IchGuckLive> and you are out
[17:19:06] <IchGuckLive> CaptHindsight: as you say
[17:19:53] <ssi> so... my 400 step motors should be here today; I guess I should swap them before I get too deep into getting motion calibrated
[17:19:56] -!- karavanjo_ has quit [Remote host closed the connection]
[17:19:58] <PetefromTn_> It has four posts and they will just be spaced outward along the X axis about 1/16" and the bottom two will be moved outward a tad on one side. Will still look basically the same but slightly different.
[17:20:12] <Connor> ssi 400 step motors ?
[17:20:14] <ssi> yes
[17:20:30] <Connor> Wow.. that's pretty odd.
[17:20:31] <PetefromTn_> 400 Oz in?
[17:20:35] <ssi> no, 400 step
[17:20:35] <Connor> where did you find them ?
[17:20:37] <ssi> 0.9 degree
[17:20:38] <ssi> sparkfun
[17:20:59] <PetefromTn_> hopefully you will not be having any sparkling fun when you power it up LOL
[17:21:20] <Connor> ssi What it for ?
[17:21:23] <ssi> the laser
[17:21:26] <Connor> Ah.
[17:21:30] <Connor> Belt Driven ?
[17:21:33] <ssi> yeah
[17:21:42] <ssi> I'm hoping to avoid having to build belt reductions
[17:21:44] <ssi> but I might s till
[17:21:45] <Connor> any gear reduction? or 1:1
[17:21:53] <PetefromTn_> He's like freakin' Buck Rodgers down there playin' with lasers and stuff...LOL
[17:21:55] <IchGuckLive> ssi: dont you gotr room for a cheep timingbelt gearing
[17:22:06] <ssi> yeah, I could make it work
[17:22:08] <ssi> but it'll be tight
[17:22:19] <ssi> especially on the gantry car, because of the way the cable chain lays directly over the motor
[17:22:29] <IchGuckLive> laser can work at high speed engraving
[17:22:41] <ssi> yeah I'm just worried about the precision
[17:22:56] <ssi> with 200 step motors, I'm at 0.008" per full step
[17:23:00] <ssi> the 400 step motors'll halve that
[17:23:05] <IchGuckLive> and you need only a tick on the extended axis not the working its continues
[17:23:47] <IchGuckLive> drivers as simple as they are can make half stepping
[17:23:55] <IchGuckLive> and give you better speed
[17:24:27] <ssi> I think speed isn't going to be a problem
[17:24:31] <IchGuckLive> ok its your design go for it
[17:24:50] <ssi> well I mean at 1.6" per rev
[17:24:54] <CaptHindsight> http://www.orientalmotor.com/products/stepper-motors/stepper-motor-only-0-36.html 0.36° Stepper Motors
[17:24:55] <ssi> it should be easy to make the thing move very fast
[17:25:15] <ssi> CaptHindsight: neat
[17:25:21] <ssi> I wish geared steppers weren't so much money
[17:25:47] <IchGuckLive> therefore hobbiest jump to 10USD tiingbelt gears
[17:26:05] -!- ler_hydra [ler_hydra!~ler_hydra@sailor-link.olf.sgsnet.se] has joined #linuxcnc
[17:26:12] <IchGuckLive> US use XL 5.08mm
[17:26:14] <ssi> it's not the cost of the gears that matters, it's the cost of the time of fabricating the reductions, and the space constraint
[17:26:17] <IchGuckLive> EU uses T5
[17:26:18] <CaptHindsight> ^^ those are not geared btw
[17:26:23] <ssi> yeah I know
[17:26:37] <Connor> geared ones might introduce backlash.
[17:26:44] <ssi> true
[17:26:45] <IchGuckLive> no
[17:26:52] -!- skorasaurus has quit [Ping timeout: 245 seconds]
[17:26:59] <IchGuckLive> not at 120deg Rotation clamp angel
[17:27:18] <ssi> anyway I think I'm gonna run the 400 step motors with a fairly high microstepping for now and see how it does
[17:27:22] <ssi> chances are it'll be fine
[17:27:28] <IchGuckLive> forgot backlash to timingbelt T V shape
[17:27:52] <ssi> timing belt doesn't really lash, but connor is talking about steppers with gearboxes, and they likely do have some lash
[17:28:22] <IchGuckLive> if you go to highend i agree but the backlash is pricise
[17:28:28] <Connor> Unless they're harmonic gear boxes.. then your really spending $$$
[17:28:33] <ssi> yeah
[17:28:38] <IchGuckLive> let me show a example
[17:28:43] <ssi> I'd much rather put my money into a higher power tube :)
[17:28:53] <CaptHindsight> planetary geared or harmonic?
[17:29:27] <IchGuckLive> i use this worms in my systems
[17:29:30] <IchGuckLive> http://www.maedler.de/product/1643/1331/1978/1367/schneckengetriebe-gii-ausf-b-achsabstand-33mm
[17:29:43] <IchGuckLive> its 120 box
[17:29:48] <IchGuckLive> Euro
[17:30:01] <IchGuckLive> but as ypou may need to trust mee
[17:30:10] <IchGuckLive> all and i got 50 in use
[17:30:14] <CaptHindsight> 120 Euro for the gearbox?
[17:30:21] <ssi> yeah I'm sure those work well
[17:30:22] <IchGuckLive> from 7,5 to 90 I
[17:30:26] <ssi> but they're also WAY too big for what I'm doing
[17:30:26] <CaptHindsight> thats not bad
[17:30:38] <IchGuckLive> got the same 0.130 backlash
[17:30:48] <IchGuckLive> i dident beleve it
[17:31:07] <IchGuckLive> as i got gantrys at that
[17:31:39] <IchGuckLive> with geraring at both different order times
[17:32:00] <IchGuckLive> all realy all the systems i ordert got the same backlash
[17:32:18] <IchGuckLive> so its the internal system fault
[17:32:26] <IchGuckLive> just a giuess
[17:32:52] <IchGuckLive> ssi only a information example
[17:33:01] <ssi> yeah
[17:33:26] <IchGuckLive> so 4:1 is at 130deg min timingbelt access
[17:33:58] <IchGuckLive> and as you got 6 teeth in working force no backlash can be produced
[17:34:16] <ssi> yeah if i need to, I'll build something similar to this:
[17:34:17] <ssi> https://lh5.googleusercontent.com/-BbDuItj7Znw/UuoQa1HvqWI/AAAAAAAALbk/MORKitksLl4/w1394-h785-no/IMG_20140128_215425129_HDR.jpg
[17:34:41] <ssi> I'm just gonna have to be judicious about how it mounts to the X car to clear everything
[17:35:12] <IchGuckLive> you gone make a realy good mashine i asume
[17:35:20] <ssi> I'd like to
[17:35:21] <ssi> within reason
[17:35:30] <ssi> I test fired the tube last night btw
[17:36:01] <IchGuckLive> and burned the naibourhouse to ground
[17:36:29] <IchGuckLive> be aware it may kill you
[17:36:42] <ssi> it can try
[17:37:35] <CaptHindsight> only the red ones kill or all those movies are wrong
[17:37:45] <IchGuckLive> i missfiered ones 100W and i will never ever do it again
[17:38:20] <ssi> IchGuckLive: I have lexan to fully enclose the machine
[17:38:34] <IchGuckLive> keep it cool down
[17:38:34] <ssi> as soon as all the motion is sorted out and alignment done, it's getting fully enclosed
[17:38:40] <ssi> water cooling system is already in place
[17:38:48] <ssi> but i don't have a chiller for it, just recirculating water
[17:39:02] -!- skorasaurus has quit [Ping timeout: 250 seconds]
[17:39:02] <ssi> there's 5gal in the system, I'm hoping it's enough volume to convection cool
[17:39:17] <IchGuckLive> keep it in wach mode by flot control
[17:39:24] <ssi> ?
[17:39:29] <IchGuckLive> oh now my english passes
[17:39:38] <ssi> :)
[17:39:46] <ssi> your english is better than my german
[17:39:56] <IchGuckLive> you need to get a floating control part that gets you green light on floting water
[17:40:03] <ssi> yeah, that's a good idea
[17:40:10] <IchGuckLive> its a simple part from plumbing
[17:40:13] <ssi> the power supply has a water interlock
[17:40:17] <PetefromTn_> burned down neighbors house... classic hilarious.
[17:40:29] <IchGuckLive> 30sec without cooling might kill your system
[17:40:55] <ssi> a float won't tell me whether the water's flowing though...
[17:40:58] <IchGuckLive> PetefromTn_: now we know how started the wildfire tonight
[17:41:03] <ssi> I have a flow sensor on hand, should I employ it?
[17:41:04] <PetefromTn_> I could see that with some meathead doing a CNC laser...not referring to you SSI LOL
[17:41:26] <ssi> PetefromTn_: I found some stuff on forums while i was looking for wiring information, and several people talked about having to patch holes in their walls :)
[17:41:31] <IchGuckLive> ssi yes on the laserout not in
[17:41:35] <ssi> yeah
[17:41:39] <PetefromTn_> some of the DIY stuff I see on the zone and elsewhere makes me cringe..
[17:41:43] <ssi> the flow meter I have is kinda large though
[17:41:54] <ssi> PetefromTn_: agreed
[17:42:09] <IchGuckLive> PetefromTn_: i worry more on lasershow junks
[17:42:12] <PetefromTn_> hell who am I bashing I nearly blew up my enitre machine with one wire poke LOL.
[17:42:22] <ssi> IchGuckLive: I'm still trying to figure out what to do about air assist
[17:42:34] <ssi> right now I'm leaning toward getting a cheapy airbrush compressor
[17:42:44] <IchGuckLive> you go to a party and someone got a 1W RGBA CHINA module pointing on you
[17:42:46] <PetefromTn_> the more I think about it... I AM that meathead LOL.
[17:42:55] <ssi> PetefromTn_: :D
[17:42:56] <PetefromTn_> I need to seek some professional help.
[17:43:29] <PetefromTn_> dead from the neck up....
[17:43:48] <PetefromTn_> :D
[17:44:01] -!- eFuchs_firefly [eFuchs_firefly!~lol@2001:4dd0:ff00:8d54:94c8:49ff:fe10:9f8c] has joined #linuxcnc
[17:44:06] <IchGuckLive> ssi: is the lexan your main target material
[17:44:11] -!- sirdancealot [sirdancealot!~koo5@37-48-32-254.tmcz.cz] has joined #linuxcnc
[17:44:12] <ssi> lexan and plywood
[17:44:22] <ssi> eventually thin metal, but not with this tube
[17:44:37] <PetefromTn_> https://www.youtube.com/watch?v=xPaM0A4GBBQ
[17:44:51] <IchGuckLive> there are Airsand nozzels to use with your laser
[17:45:05] <ssi> I have a nozzle with an air assist fitting
[17:45:15] <ssi> and there's tubing run through cable chain for it already
[17:45:22] <ssi> I just need to figure out what to use as a source for the air
[17:45:23] <IchGuckLive> is it pointed on maybe 1mm
[17:46:05] <IchGuckLive> the airflow needede depends on material thickness
[17:46:22] <IchGuckLive> a airbrush may only get you 5psi at full flow
[17:46:36] <PetefromTn_> Okay I think I got this damn drawing fixed now. Gotta get it cammed up and try again now.
[17:46:47] <IchGuckLive> not enove to get lexan meltdown stop
[17:46:49] <ssi> my other option is to try to get a secondhand refrigerated dryer, get it installed, and run air line upstairs
[17:46:58] <ssi> which is obviously a lot more work
[17:47:14] <ssi> IchGuckLive: here's the nozzle:
https://pbs.twimg.com/media/BtKoW6hIIAATj61.jpg:large
[17:47:23] <ssi> I have two of them, that's a 1.5" nozzle and lens, the other is 2"
[17:47:42] <IchGuckLive> ssi what if you stat at a standard one and as you then kow whats needed get the right
[17:47:59] <ssi> what do you mean by standard one?
[17:48:36] <IchGuckLive> a 8bar air compressor for paintig cartoos ...
[17:48:41] <ssi> ok
[17:48:45] <ssi> yeah I can get one for under $100
[17:49:00] <ssi> this one claims 0.7cfm at 40psi
[17:49:09] <IchGuckLive> ask your naibours or friends for a test at one saturday
[17:49:12] -!- zzolo has quit [Quit: zzolo]
[17:49:45] -!- rosslyoung has quit [Ping timeout: 250 seconds]
[17:50:02] <ssi> I guess I could also just buy a little oilless pancake compressor from home depot
[17:50:08] <ssi> that'd give me a lot more pressure and flow
[17:50:45] <ssi> something quiet would be nice though
[17:51:17] <ssi> hm I have a little turbine hvlp system; maybe I could use that
[17:51:25] <ssi> might not be enough pressure ntho
[17:51:28] <IchGuckLive> 55.88USD Campbell Hausfeld FP2028
[17:51:41] <ssi> hehe yea that'd do it
[17:51:45] <JT-Shop> damn maintenance department should have changed that air line before it blew off...
[17:52:13] <JT-Shop> how do they expect the production department to get any work done?
[17:52:38] <ssi> all of $69 if I go buy it at the store
[17:52:58] <IchGuckLive> not that bad
[17:53:07] <IchGuckLive> ad you can give it back
[17:53:12] <IchGuckLive> on missfunction
[17:53:13] <ssi> HAHAHA
[17:53:18] <ssi> people around here do that all the time
[17:53:25] <IchGuckLive> as here
[17:53:28] <ssi> they'll buy a $500 paint sprayer, paint a house, and return it full of paint
[17:53:51] -!- automata [automata!~Amit@triband-mum-59.182.130.87.mtnl.net.in] has joined #linuxcnc
[17:54:05] <IchGuckLive> here at the local its the hypertherm 125
[17:54:06] <ssi> or I could spend som emoney
[17:54:07] <ssi> http://www.homedepot.com/p/California-Air-Tools-3-Gal-1-HP-Ultra-Quiet-and-Oil-Free-Air-Compressor-3010/203003949
[17:54:17] <ssi> quiet sounds nice :)
[17:54:25] <jdh> I have 6cfm@4500psi
[17:54:43] <IchGuckLive> jdh: you blow the best 1
[17:54:43] <ssi> jdh: dive compressor? :P
[17:54:50] <jdh> yep
[17:54:51] <ssi> heheh
[17:54:53] <jdh> and dry
[17:55:23] -!- micges-dev has quit [Ping timeout: 250 seconds]
[17:55:34] <IchGuckLive> diving in egypt is realy cool
[17:56:18] <jdh> yeah, red sea liveabaords look great.
[17:56:24] <jdh> I could say I was canadian.
[17:56:34] <jdh> I could even act nice and polite
[17:56:54] <IchGuckLive> hurgada or sham el shaik
[17:57:14] <ssi> jdh: when I get my bareboat sailing certificate, we should get together and have a cnc club dive liveaboard sailing trip
[17:57:18] <ssi> haha
[17:57:19] <ssi> I'll need to get my gear serviced
[17:57:23] <ssi> and maybe take a refresher
[17:57:31] <Connor> Hey.. Cool..
http://www.spidercool.com/
[17:57:32] <jdh> sailing is so.... slow.
[17:57:44] <ssi> slow and fuel efficient :)
[17:58:01] -!- phantoxe has quit []
[17:58:05] <IchGuckLive> slow ssi no way did you see americas cup this year
[17:58:14] <IchGuckLive> 45miles
[17:58:16] <ssi> fast sailboats are awesome
[17:58:21] <ssi> but they're still slow in the grand scheme of things :)
[17:58:26] <Tom_itx> ok, airlines all patched up
[17:58:55] <IchGuckLive> today here the airport gets insolvent
[17:59:06] <Tom_itx> air lines
[17:59:07] <IchGuckLive> no more flights from oktober
[17:59:11] <Tom_itx> as in compressor
[17:59:22] <IchGuckLive> oh
[17:59:25] <ssi> hahaha
[17:59:25] <IchGuckLive> O.O
[17:59:26] <Tom_itx> :)
[17:59:36] <PetefromTn_> I LOVE sailboats...
[17:59:44] <PetefromTn_> Especially catamarans.
[17:59:50] <ssi> PetefromTn_: cool, come down and we'll sail and listen to records
[17:59:51] <jdh> I have a catamaran
[17:59:55] <PetefromTn_> I just wish my wife loved them too.
[17:59:56] <jdh> but, it has twin engines
[17:59:57] <IchGuckLive> tennesiee no sailboat use
[18:00:11] <PetefromTn_> I had a Nacra I used to sail around here.
[18:00:15] <PetefromTn_> BS.
[18:00:21] <PetefromTn_> There are a lot of sailboats here.
[18:00:31] <PetefromTn_> There is even a regatta in Knoxville.
[18:00:40] <PetefromTn_> sailing club and whatnot.
[18:00:43] <jdh> redneck riviera regatta
[18:00:50] <PetefromTn_> ssi sounds good to me man..
[18:00:58] <ssi> redneck riviera is panama city beach :P
[18:01:02] <PetefromTn_> precisely. altho most of the guys there are NOT rednecks.
[18:01:02] <ssi> I've done some sailing in panama city too
[18:01:08] <Tom_itx> u r old
[18:01:11] <Tom_itx> records?
[18:01:15] <ssi> friend of mine has a 38' sailboat there
[18:01:17] <Tom_itx> CD's mp3 maybe
[18:01:21] <PetefromTn_> Hey man don't dis the records..
[18:01:23] <CaptHindsight> IchGuckLive: are you near Stuttgart?
[18:01:25] <ssi> Tom_itx: I think that means YOU are old actually
[18:01:26] <Tom_itx> hehe
[18:01:36] <PetefromTn_> records sound amazing with quality equipment.
[18:01:40] <Tom_itx> i may resemble that
[18:01:44] <ssi> was at frys the other day perusing records, all young folks looking at records, and one crusty old 50s dude flipping through CDs
[18:01:49] <ssi> the tables have turned :)
[18:01:51] <IchGuckLive> oh its quite a way to stutgart here CaptHindsight
[18:02:06] <PetefromTn_> where?
[18:02:24] <ssi> frys?
[18:02:25] <ssi> heh
[18:02:38] <IchGuckLive> CaptHindsight: im in Ramstein where 60.000 US soldiers are and lots of big C5 and C17 overhead every day
[18:02:39] <PetefromTn_> what's Frys
[18:02:44] <ssi> huge electronics store
[18:02:50] <PetefromTn_> oh.
[18:02:55] <ssi> I get a lot of my machine parts there :P
[18:03:01] <PetefromTn_> wheres the 38 footer?
[18:03:04] <ssi> that's where I bought my adorable little meanwell 12v and 5v supplies
[18:03:10] <ssi> panama city
[18:03:14] <PetefromTn_> wall warts.
[18:03:18] <ssi> no, frame supplies
[18:03:29] <PetefromTn_> do they sell Markaudio LOL?
[18:03:32] <ssi> nope
[18:03:39] <IchGuckLive> ssi: there is a 24V 5V in one for cnc starters
[18:03:43] <ssi> https://pbs.twimg.com/media/BtCzsOpCAAAuxT4.jpg:large
[18:03:47] <ssi> see the little guys?
[18:03:50] <IchGuckLive> i use them offen
[18:03:52] <ssi> that's actually two different supplies
[18:04:03] <ssi> IchGuckLive: yeah I've seen them but I needed them on sunday so I couldn't afford to wait
[18:04:04] <PetefromTn_> cute..
[18:04:34] <PetefromTn_> just enough to set your neighbor's house on fire from your garage...DIABOLICAL!
[18:04:41] <ssi> those supplies and the computer come on with the main power
[18:04:42] <IchGuckLive> ssi they are great for my nin mashines
[18:04:48] <ssi> all the other supplies come on by relay
[18:04:50] <CaptHindsight> IchGuckLive: ok, so ~200km, that's like 10 minutes on the autobahn :)
[18:04:57] <cpresser> with great supplies comes great power
[18:05:01] <ssi> cpresser: :)
[18:05:26] <ssi> turns out the laser psu can supply 24v and 5v, but in order to use those I'd have to have the laser psu come on with the main switch
[18:05:33] <ssi> and I really prefer to have it under software control for estop purposes
[18:05:34] <IchGuckLive> CaptHindsight: woudt be grweat nearly 2,5hr
[18:06:14] <PetefromTn_> Estop means NO software to me man...
[18:06:39] <IchGuckLive> ssi i use a 24V seperat to get the 5i25 supplyed and from thre start all other
[18:06:52] <IchGuckLive> so relai emergency on all parts
[18:06:53] <ssi> yeah that's basically what I'm doing
[18:07:04] <ssi> I added a 5V supply for the 5v side of the 7i76 as well, because my relays are 5v coil
[18:07:09] <PetefromTn_> Estop means....OH SHIT I just burned down the neighbor's house and set their dog on fire so it has to be off RIGHT NOW!!
[18:07:14] <ssi> PetefromTn_: yep
[18:07:27] <IchGuckLive> F1 starts all the power in the cabinet
[18:07:32] <IchGuckLive> F2 enables the drives
[18:07:48] <IchGuckLive> so i got 2 chances for a emergency
[18:07:50] <ssi> IchGuckLive: yeah that's what I'm going for too, although I dunno if I want to have the laser psu running with f1 or not
[18:08:09] -!- mozmck has quit [Quit: Leaving.]
[18:08:13] <jdh> I don't use f1 or f2 on my mill. Just push the start button.
[18:08:13] <ssi> IchGuckLive: the leadshine drives have an enable input, and I'm not sure if I should use it or not
[18:08:20] <IchGuckLive> on worm mashines i like the main emergency to be drive enable cut
[18:08:31] <IchGuckLive> i use it
[18:08:38] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[18:08:41] <ssi> the 7i76 doesn't have dedicated enable outs on the 5v side
[18:08:46] -!- tjtr33 has quit [Read error: No route to host]
[18:08:59] <IchGuckLive> use a GPIo
[18:09:02] <ssi> and the field io side is all sourcing outs, and I'm not sure what sort of input signal the enable in on the drive is
[18:09:10] <IchGuckLive> and got a 24V relay on it
[18:09:19] <ssi> the manual says that they're enabled by default,
[18:09:29] <ssi> and I tried just shorting the ena+ to ena-, and it didn't seem to disable the drive
[18:09:32] <ssi> at least there wasn't any indication
[18:09:42] <ssi> i guess I should check if the motor goes slack
[18:09:55] <Connor> anyone know of a 1/4 NPT Right angle connector.. that can "rotate" ? a
[18:09:56] <jymmm> https://www.youtube.com/watch?v=H04TJgWcVvU
[18:10:09] -!- k6mle-CNC [k6mle-CNC!ad0e4779@gateway/web/freenode/ip.173.14.71.121] has joined #linuxcnc
[18:10:43] -!- b_b has quit [Changing host]
[18:11:09] <IchGuckLive> ssi the 5V run to leadshine ena+ and the ena - runs to the relay and then to gnd
[18:11:15] <ssi> yeah got it
[18:11:18] <IchGuckLive> do F2 enables the drives
[18:11:19] <PetefromTn_> My neighbor kills me man... He and his son built this large shed with a whole bunch of work and board and batton siding. Looked pretty good and they even put some windown and doors in it.
[18:11:33] <ssi> and i can use the NC side of the relay to make them active high
[18:11:39] <PetefromTn_> Then they got it ready with trusses and ready to put the roof on.
[18:11:51] <PetefromTn_> Only they never finished the roof and that was like three years ago.
[18:11:52] <ssi> IchGuckLive: did you see my relay card hackery?
[18:12:04] <ssi> PetefromTn_: so now the whole thing is rot?
[18:12:08] <PetefromTn_> So it is not rotting away in the weather and looks like fido's ass..
[18:12:22] <ssi> CaptHindsight: you might be interested in this too
[18:12:23] <PetefromTn_> yup.
[18:12:44] <ssi> those cheapy sainsmart relay cards are active low, and they won't work with 7i76 sourcing outputs
[18:12:51] <IchGuckLive> ssi
[18:12:53] <IchGuckLive> net joy-mashine-off or2.2.in0 <= input.0.btn-tl
[18:12:55] <IchGuckLive> net mash-estop-but or2.2.in1 <= hm2_5i25.0.7i76.0.0.input-00-not
[18:12:56] <IchGuckLive> net maschinehaloff or2.2.out => halui.machine.off
[18:12:58] <PetefromTn_> its just a building with open trusses and no roof
[18:13:06] <ssi> so I hacked them up to make them active high
[18:13:07] <ssi> https://pbs.twimg.com/media/BtGt9k2CQAEMsyh.jpg:large
[18:13:14] <ssi> ugly, but functional
[18:13:19] <PetefromTn_> and now it is a smoldering pile of cow dung.
[18:13:24] <ssi> also changed the resistors out so they can run comfortably on 12v signals
[18:13:29] <ssi> though the coils still take 5v
[18:14:13] <ssi> there are 12v versions of this board out there; I ordered a few, but they're still active low
[18:14:30] <PetefromTn_> I got lucky with the relays in the Cinci.. It has a large bank of relays in a block and I was able to reuse them. Works well.
[18:14:44] <ssi> in order to convert them, the indicator leds need to be rotated 180 to swap polarity, and pins 1 and 2 on the opto need to be swapped to reverse polarity
[18:15:01] <ssi> and then the control header gets fed gnd on the VCC pin, and +12v on a signal pin to activate
[18:15:45] <ssi> PetefromTn_: these little cheapy relay cards actually are great for what they are... if they were active high out of the box they'd be perfect
[18:15:49] <ssi> but they're like $7 apiece
[18:15:53] <ssi> for 8 channels of relays
[18:16:17] -!- rob_h [rob_h!~robh@176.250.56.144] has joined #linuxcnc
[18:16:59] <Connor> http://www.ebay.com/itm/AIR-ANGLE-SWIVEL-ADAPTOR-1-4-NPT-/271257540415?pt=US_Hand_Tools&hash=item3f2835973f
[18:17:06] <Connor> says for air.. you think that would work for coolant ?
[18:17:44] <IchGuckLive> ssi:
http://foengarage.de/mesa_elek.jpg
[18:17:58] <IchGuckLive> right of the 7i76 the 2 relays
[18:17:58] <Connor> jdh: Your thoughts ?
[18:18:14] <ssi> IchGuckLive: ya
[18:18:28] <IchGuckLive> ssi and right of the leadshine the yelow one is the main cut off
[18:18:47] <ssi> latching contactor?
[18:19:00] <IchGuckLive> the prit telay socket combination is cheep and can host 5V 12V 24V relas
[18:19:04] <ssi> what are the three boxes to the right of the yellow one
[18:19:20] <IchGuckLive> 5V 12V 24V supply
[18:19:24] <ssi> gotcha
[18:19:35] <IchGuckLive> as i need to work 16hr + i go for sepperate
[18:19:37] <k6mle-CNC> Got the 5i25 installed, but need to have Linux recognize it ... not quite sure how that's done!
[18:19:52] <ssi> k6mle-CNC: linuxcnc will load the driver for it
[18:19:59] <ssi> k6mle-CNC: just configure your hal for it, it'll work :)
[18:20:24] <k6mle-CNC> Should I start with stepconf?
[18:20:34] <IchGuckLive> k6 are you on 2.5.4
[18:20:37] <ssi> pncconf I think you need to use
[18:20:53] <IchGuckLive> use pncconf
[18:21:05] <ssi> but I ran it yesterday and it didn't have 5i25 in it for some reason
[18:21:07] <ssi> not sure what version
[18:21:16] <IchGuckLive> and keep in mind the output on the pc back side is connector 2
[18:21:23] <k6mle-CNC> Okay ... I've not used that yet, but will give it a try.
[18:21:40] <PetefromTn_> Connor... I got a whole bunch of right angle fitting here from the RF45 build you are welcome to some if you want them. I think they are all for air but I used them for grease fittings at least the brass ones.
[18:22:09] <Connor> PetefromTn_: Idea I have to make a servo controlled coolant nozzle.
[18:22:20] <PetefromTn_> there is a firmware upgrade that works for that K6 its on the forum.
[18:22:25] <Connor> Need a right angle swivel connector 1/4npt
[18:22:50] <Connor> push-to-connect won't work.
[18:22:54] <PetefromTn_> I know the plastic ones for air pressure are swivel at least some of them are..
[18:23:04] <PetefromTn_> The plastic ones are push to connect.
[18:23:10] <PetefromTn_> the brass one I do not rememve.
[18:23:11] <Connor> Yea. that's the problem.
[18:23:13] <PetefromTn_> remember.
[18:23:21] <Connor> http://www.ebay.com/itm/AIR-ANGLE-SWIVEL-ADAPTOR-1-4-NPT-/271257540415?pt=US_Hand_Tools&hash=item3f2835973f
[18:23:24] <Connor> Might work.
[18:23:51] <PetefromTn_> they sell swivel fittings for pneumatics that are kinda nice at lowes...
[18:24:15] <PetefromTn_> I have one or two on some of my pneumo tools.
[18:25:00] <PetefromTn_> Just a piece of surgical tubing would probably swivel pretty good too... with a piece of brass stuck inside it to hold it maybe?
[18:25:15] <PetefromTn_> The HAAS programmable coolant just has a brass nozzle on it.
[18:25:23] <PetefromTn_> looks like a short piece of pipe.
[18:25:52] <PetefromTn_> I am sure they must charge 15 grand for the system tho LOL.
[18:26:03] <Connor> I want to bring the coolant in from the back... down a manifold, into the fitting..
[18:26:21] <Connor> the fitting then will be coupled with a servo.
[18:26:33] <Connor> and a "nozzle" screwed into the fitting.
[18:27:28] <automata> hi PCW_home
[18:27:48] -!- md-2 has quit [Remote host closed the connection]
[18:28:01] <automata> I am trying to compile a bit file for 7i90... but I run into the following error...
[18:28:02] <automata> ERROR:HDLCompiler:104 - "D:\Work\Projects\mesa\7i90\configs\hostmot2\source\hostmot2.vhd" Line 80: Cannot find <inputpinspermodule> in library <work>. Please ensure that the library was compiled, and that a library and a use clause are present in the VHDL file.
[18:28:20] <PetefromTn_> cool beans
[18:28:29] <automata> I am not able to find the VHDL source file called inputpinspermodule.vhd
[18:28:33] <PetefromTn_> how do you plan to control it?
[18:28:40] -!- ler_hydra has quit [Remote host closed the connection]
[18:28:49] -!- tmcw has quit [Remote host closed the connection]
[18:28:54] <automata> any suggestions?
[18:29:07] <Connor> External controller. Probably use modbus to connect it to LinuxCNC/Mach3 or whatever.
[18:29:27] <PetefromTn_> MACH3!!!! PLEASE SAY NO...
[18:29:44] -!- md-2 has quit [Read error: No route to host]
[18:29:45] <Connor> PetefromTn_: I don't care... The controller will talk modbus. :)
[18:29:45] <pcw_home> download the latest source (and you may need to add InputsPinsPerModel.vhd to the project)
[18:29:59] <PetefromTn_> the haas setup actually has positions settings in the tool table.
[18:30:19] <PetefromTn_> You set the tool length and then the coolant nozzle position and the control does the rest.
[18:30:23] <automata> ok..
[18:30:37] <Connor> Going to copy the
http://www.spidercool.com/ idea..
[18:31:11] <pcw_home> you can add source to the project by right clicking in the source pane
[18:31:15] <Connor> LinuxCNC sends over modbus, the tool number.. and the controller has the setting stored.
[18:31:26] <automata> ok trying that...
[18:32:45] <PetefromTn_> that looks basically just like the haas one only it looks like a smaller package footprint.
[18:32:58] <PetefromTn_> The nozzle need some good pressure tho.
[18:33:04] <Connor> I can replicate it. :)
[18:33:13] <PetefromTn_> of course.
[18:33:21] <PetefromTn_> make me one too LOL
[18:33:34] <PetefromTn_> Altho honestly my coolant setup works fine really.
[18:33:44] <PetefromTn_> I do have to adjust the nozzles occasionally which is tedious.
[18:33:56] <Connor> Hmm.. you use 1/4 or 3/8 ?
[18:33:57] <PetefromTn_> I need the toolchanger working more than programmable coolant right now tho.
[18:34:13] <PetefromTn_> It uses Loc Line larger diameter..
[18:34:20] <PetefromTn_> I do not know the size.
[18:34:28] <Connor> Those come in different sizes too. :)
[18:34:43] <Connor> Mine is 1/4npt
[18:34:49] <Connor> which is what I'm going to go with.
[18:35:05] <PetefromTn_> The pump puts out enough volume to make the garden nozzle feel like my houses garden nozzle so that is not a problem.
[18:35:19] <PetefromTn_> yeah I know but I have not tried to measure it.
[18:35:39] <PetefromTn_> Would be a nice addition tho. Needs to be pretty coolant proof motor and wiring tho.
[18:35:50] <PetefromTn_> it gets WET in there man.
[18:36:23] <PetefromTn_> I find sprinkling of coolant even coming out the top of the machine landing on me occasionally and that is like eight feet up or more..
[18:38:31] <PetefromTn_> How is your machine working?
[18:39:15] <Connor> Haven't done much with it lately. I need to finish up those cover panels for the enclosure.. and wire up the switches so I can run the coolant
[18:39:18] -!- mozmck has quit [Quit: Leaving.]
[18:39:46] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[18:39:55] -!- larryone has quit [Ping timeout: 272 seconds]
[18:41:25] -!- mozmck has quit [Client Quit]
[18:43:57] -!- IchGuckLive has quit [Quit: ChatZilla 0.9.87 [Firefox 20.0/20130329043827]]
[18:48:35] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[18:48:45] <PetefromTn_> Sounds like you are making progress tho...
[18:48:59] <PetefromTn_> I need to get back on mine and get this toolchanger working at some point here.
[18:49:42] <PetefromTn_> Still working on the damn kitchen tho. Got the base cabinets all installed and the counter tops are almost in gotta cut the sink out and install the new sink so we can use it again soon.
[18:51:19] -!- md-2 has quit [Remote host closed the connection]
[18:51:23] <Tom_itx> dude you need to get your priorities straight
[18:51:32] <ssi> heh
[18:51:34] <PetefromTn_> who me?
[18:51:39] * Tom_itx nods
[18:51:40] <ssi> the cabinetmaker's kitchen
[18:51:42] <PetefromTn_> how so..
[18:52:05] <Tom_itx> care for your machines at all cost
[18:52:07] <PetefromTn_> I thought the kitchen takes precedence over the CNC..
[18:52:46] <PetefromTn_> Gotta have a kitchen sink.. with no kitchen sink Momma Ain't happy....when Momma Ain't happy...well.... DADDY Ain't happy if you know what I mean.
[18:52:46] <ssi> next thing you know, you're gonna be telling me I should go to work instead of building machines
[18:52:47] <Tom_itx> boy have you been brainwashed...
[18:53:35] <PetefromTn_> Well since we have lived with shitty cabinets for a couple YEARS now with basically a makeshift counter top I figure it is about time or I may be out in the street...
[18:54:01] <PetefromTn_> Personally I like my nice warm bed and my wife's company in it LOL...
[18:54:20] <ssi> yeah, pretty much the definition of brainwashing
[18:54:36] <serp> i like the couch sometimes myself
[18:54:48] <PetefromTn_> so I have to put the other SCHTUFF on hold. Besides I have been busy making other stuff and trying to make money where I can so the encoder mount for the machine has been neglected.
[18:55:22] <PetefromTn_> I actually like the couch too but only when I KNOW I can head upstairs to my nice HUGE king sized warm bed LOL....
[18:55:31] <Tom_itx> get the tool changer working and you won't have to attend it nearly as much
[18:55:42] <Tom_itx> then you will have the free time to honey dew
[18:55:51] <ssi> why on earth do fedex and ups keep giving my packages to usps to deliver?!
[18:55:52] <PetefromTn_> so call me brainwashed, whipped, what have you. It works for me LOL...
[18:56:10] <serp> What part of Tn Pete.. Alcoa here
[18:56:12] <PetefromTn_> Oh I hear ya man I would love to have the toolchanger working..
[18:56:15] <PetefromTn_> NO SHIT..
[18:56:16] <Tom_itx> ssi i dunno, it's some sort of postal arrangement they have
[18:56:19] <ssi> it's annoying
[18:56:20] <PetefromTn_> I am in Maryville LOL..
[18:56:21] <Tom_itx> i get them too
[18:56:23] <serp> hah
[18:56:30] <ssi> one from fedex, one from ups
[18:56:34] <ssi> both scheduled to deliver today
[18:56:35] <ssi> by usps
[18:56:39] <serp> Basically the same thing except during football season
[18:56:40] -!- md-2 has quit [Ping timeout: 260 seconds]
[18:56:51] <PetefromTn_> huh?
[18:56:54] <ds3> because you asked for it
[18:57:10] <ssi> I asked for it?
[18:57:11] <PetefromTn_> where in Alcoa?
[18:57:12] <ds3> Fedex and UPS's low end services are delivered by USPS
[18:57:22] <ds3> SmartPost I think is one name Fedex uses
[18:57:26] <ds3> same with UPS
[18:57:38] <ssi> in one case, I asked for express shipping
[18:57:40] <ds3> you save like $1 on shipping but things get delayed by another 2-3 days
[18:57:41] <ssi> and they sent it china post
[18:57:43] <serp> PetefromTn_: well just a couple miles from teh airport.. i guess that could be said for all of alcoa though
[18:57:46] <ssi> and I complained, so they recalled it and sent it fedex
[18:57:49] <ssi> and it took two weeks
[18:57:53] <PetefromTn_> sweet..
[18:58:01] <PetefromTn_> You got any CNC's working?
[18:58:02] <ds3> they must have assumed all services of fedex are fast
[18:58:08] <PetefromTn_> Connor here is up in KTown..
[18:58:10] <ssi> also
[18:58:17] <serp> PetefromTn_: I came in here cause I have been helpin the KnoxMakers with their buildlog 2.x laser
[18:58:19] <ssi> why can usps get a package from california to atlanta in two days,
[18:58:30] <PetefromTn_> WHAT KNOXMAKERS?
[18:58:31] <ssi> but fedex takes a week and a half to get it from california to usps, who then takes one more day to get it to me
[18:58:42] <ds3> I used to order stuff from a place that's about 400miles away - ground service is same as next day here...then they started offering "smartpost"... 2-3 days for the same delivery...just $1 or less
[18:58:48] <serp> PetefromTn_: yes.. you know of them right? :)
[18:58:58] <PetefromTn_> NOPE... NOT A CLUE...
[18:59:19] <serp> PetefromTn_: they are currently housed in oak ridge but are about to move to Knoxville proper
[18:59:23] <PetefromTn_> thats some a dat makerbot stuff right.. All 3d printing and schtuff.
[18:59:36] <PetefromTn_> there is nothing PROPER about knoxville LOL
[19:00:00] <serp> they do 3d printing aplenty... they have a cnc of some sort i'm not familiar with yet.. the laser is just having the final touches on it
[19:00:32] <ds3> Oakridge, TN? do their 3d printings glow too?
[19:00:34] <ds3> :D
[19:00:35] <PetefromTn_> I have to build me one of those 3d thingies one of these days. Right now I want to build a large format CNC router tho.
[19:00:37] -!- theorbtwo has quit [Ping timeout: 245 seconds]
[19:00:47] <PetefromTn_> hell we all glow here man...
[19:00:52] <serp> ds3: heh yes... they are 3d printing cards out in oak ridge now for localmotors
[19:00:57] <PetefromTn_> my kids have six legs...
[19:00:58] <serp> err cars
[19:01:12] <ds3> self warming cars that glow ? :D
[19:01:16] <serp> no doubt
[19:01:17] <PetefromTn_> they are a nice shade of purple too..
[19:01:32] <PetefromTn_> thats a joke right...?
[19:01:40] <serp> what's a joke?
[19:01:49] <PetefromTn_> the printing car parts thing.
[19:01:55] <serp> no they are literally printing a car
[19:02:07] <PetefromTn_> car for a hamster?
[19:02:18] <serp> https://localmotors.com/AlexFi/the-3d-printed-car-aka-direct-digital-manufacturing/
[19:02:23] <ds3> they have done bikes before
[19:02:34] <ds3> (they as in generic they)
[19:02:58] <PetefromTn_> HOLY SCHNIKES!!
[19:03:02] <serp> like teh whole frame is 3d printed
[19:03:06] <PetefromTn_> Print me one man...
[19:03:14] <serp> i'm sure they'd sell you one
[19:03:16] <PetefromTn_> looks aluminum tig welded to me..
[19:03:54] <PetefromTn_> I want to buy SSI's formula 1 car first LOL...
[19:04:02] <ssi> formula 440 :P
[19:04:39] <PetefromTn_> That shock mount looks kinda flimsy to me man...
[19:05:19] <PetefromTn_> Ya shoulda called me I would love to be a part of building something like that dude! Is this for a college project or something?
[19:05:30] <serp> no just for the makerspace
[19:05:47] <serp> hackerspace.. whatever you wanna call it.. community collection of tools for members
[19:05:59] <ssi> most of those places do have tools for members
[19:06:42] <serp> it's kind of small still due to space issues... we've outgrown the current location.. thus the prompt to move to knoxville to a bigger place
[19:06:47] <PetefromTn_> I got a CNC machining center here man... Can I play too?
[19:06:54] <ssi> PetefromTn_: naw you're overqualified
[19:06:59] <PetefromTn_> LOL
[19:07:08] <ssi> seriously
[19:07:13] <ssi> I wanted to get involved with one here in atlanta
[19:07:20] <ssi> and they're obnoxious about it
[19:07:29] <PetefromTn_> how so do tell..
[19:07:30] <ssi> it's a bunch of fratty, culty, socialist bull
[19:07:41] <ssi> I am a one man hackerspace thank you very much
[19:07:50] <PetefromTn_> you sure as hell are sir...
[19:07:55] <JT-Shop> yea, my drill speed and feed works!
[19:08:06] <PetefromTn_> and you have my undying respect LOL...
[19:08:10] <ssi> haha
[19:08:26] <ssi> seriously I personally have a lot more equipment and tools than the entire freeside collective :P
[19:08:33] <PetefromTn_> anyone with the cajones to build thier own plane in the garage has balls as big as churchbells....
[19:08:50] <PetefromTn_> you are a giant among men.
[19:08:51] <alexchally_cnc> shiiiit yes, i done read some encoder output into EMC \o/
[19:08:57] <alexchally_cnc> time to get some victorylunch :D
[19:08:57] <ssi> reserve judgement for after I fly it :P
[19:09:10] <PetefromTn_> Can I have your CHNC when you crash?
[19:09:18] <PetefromTn_> ;)\
[19:09:22] <ssi> when am I getting a CHNC?!
[19:09:23] <ssi> :D
[19:09:33] <PetefromTn_> did you sell it?
[19:09:34] <JT-Shop> I put together a 170 once for my Dad
[19:09:41] <ssi> nah mine's an HNC
[19:09:48] <PetefromTn_> oh whatever...
[19:10:00] <ssi> smaller collet, no servo spindle
[19:10:01] <PetefromTn_> can I? LOL
[19:10:09] <ssi> heh sure
[19:10:33] <PetefromTn_> you are the best man.... whattaguy??!!!
[19:10:46] <ssi> tell you what
[19:10:47] <PetefromTn_> jeez I crack myself up...
[19:10:50] <ssi> you come down here and help me fix it,
[19:10:52] <ssi> I'll write you into the will
[19:10:53] <ssi> :)
[19:11:21] <PetefromTn_> I need to come down there just to witness the grandeur of the 2A3's man... everything else will be a BONUS!
[19:11:49] <zeeshan> man
[19:11:54] <zeeshan> how hard is it to follow a fucking drawing
[19:12:02] <zeeshan> i told this other masters student to machine something
[19:12:06] <PetefromTn_> pretty damn hard..
[19:12:06] <zeeshan> for a clearance fit
[19:12:18] <zeeshan> i specified -.001 undersize
[19:12:28] <zeeshan> he makes it 1/8" undersize..
[19:12:29] <zeeshan> ?
[19:12:36] <zeeshan> the whole part is scrap now
[19:12:40] <ssi> that's sorta like the same tihng
[19:12:52] <zeeshan> i spent 8 hours machining the other features on it
[19:13:43] <serp> PetefromTn_: everyone is welcome... look it up on the website... most all the tuesday nights (except tonight oddly enough) are open to the public with some little presentation or something
[19:14:07] <PetefromTn_> why not tonight?
[19:14:26] <serp> it's a member meeting to vote on stuff.. to be honest it's probably open too but would be boring
[19:14:35] <PetefromTn_> my new to me fullsize bronco is not registered yet. I need to get a new fuel tank for it. So I would have to take my wife's trooper.
[19:14:47] <PetefromTn_> what is your involvement?
[19:14:52] <serp> i'm a member
[19:14:58] <PetefromTn_> yeah I got that much.
[19:15:01] <serp> that's it
[19:15:11] <PetefromTn_> you have not made anything on the car?
[19:15:19] <zeeshan> interesting
[19:15:20] <zeeshan> theyre using alias
[19:15:22] <serp> the car is not part of the makerspace
[19:15:32] <serp> it's made by localmotors
[19:15:33] <zeeshan> that software drives me insane :{
[19:15:36] <PetefromTn_> I'm lost now...
[19:15:58] <PetefromTn_> I thought you said they were making the car in the makerspace...
[19:16:05] <serp> no in oak ridge...
[19:16:08] <serp> at ornl
[19:16:19] <serp> sorry it was a tangent comment to someone else saying something
[19:16:21] <zeeshan> ssi get yolur dryer yet?
[19:16:22] <zeeshan> :D
[19:16:32] <PetefromTn_> Those guys up there are working on some next gen stuff....
[19:16:44] <PetefromTn_> I wish I could be a part of some of that stuff.
[19:16:57] <ssi> zeeshan: I emailed the guy in canton
[19:17:03] <zeeshan> PetefromTn_: part of building plastic cars?
[19:17:05] <PetefromTn_> Maybe I need to come up there and meet and greet and stick my gnarled ugly toe in the door...
[19:17:11] <serp> yah ornl is some real stuff.. some of the supercomputer dudes are members
[19:17:17] <PetefromTn_> hell part of anything worth doing...
[19:17:37] <zeeshan> ssi i hope you low balled
[19:17:38] <zeeshan> :D
[19:17:45] <PetefromTn_> maybe I can get some business going with my own shop here for them.
[19:17:47] <serp> PetefromTn_: if you are interested in the car i think they do tours.. you could contact the localmotors guys.. they are pretty good about that stuff usually
[19:18:24] <PetefromTn_> might have to do that.
[19:18:26] <ssi> haven't made an offer, just trying to make contact
[19:18:40] <PetefromTn_> Gotta go out in the shop now and try to make this damn fixture again.
[19:18:44] <PetefromTn_> Cya guys later..
[19:18:48] <zeeshan> bi
[19:18:51] <PetefromTn_> wish me luck LIL..
[19:18:54] <PetefromTn_> LOL
[19:19:02] <PetefromTn_> who you callin' BI??? heheh
[19:19:54] <zeeshan> =]
[19:20:07] -!- PetefromTn_ has quit [Quit: It's a dud! It's a dud! It's a du...]
[19:24:08] -!- mozmck has quit [Quit: Leaving.]
[19:24:25] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[19:24:38] -!- tmcw has quit []
[19:27:22] -!- Roguish has quit [Ping timeout: 245 seconds]
[19:28:38] -!- Roguish [Roguish!~chatzilla@c-67-188-44-176.hsd1.ca.comcast.net] has joined #linuxcnc
[19:32:39] -!- eFuchs_firefly has quit [Quit: ping timeout]
[19:33:07] -!- mozmck has quit [Quit: Leaving.]
[19:33:23] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[19:35:46] <JT-Shop> what a pain to powder coat one thing... an hour to set up 5 min to coat and 25 to bake then another hour to put everything away
[19:39:52] <zeeshan> !
[19:40:04] <zeeshan> is there an easy way to mount 10 spacers on a milling table
[19:40:08] <zeeshan> and face mill em all at once
[19:41:56] -!- theorbtwo [theorbtwo!~theorb@cpc8-swin16-2-0-cust252.3-1.cable.virginm.net] has joined #linuxcnc
[19:44:10] -!- PCW [PCW!~chatzilla@99.88.10.65] has joined #linuxcnc
[19:44:31] <Connor> Serp: We may have met
[19:45:27] <Connor> I went to one of the KnoxMakers meetings.. was on CNC. Guy Brought a little CNC machine built for pcb engraving.
[19:46:03] micges-dev1 is now known as micges-dev
[19:48:47] <alexchally_cnc> PCW, I got my encoders reading into linuxcnc today, thanks for your help yesterday!
[19:52:14] <PCW> NP
[19:52:16] <PCW> Make sure you read the 7I52S manual section about the TX0B and TX3B enables (though those outputs dont happen to be ones used for PWM)
[19:52:54] -!- skunkworks has quit [Ping timeout: 260 seconds]
[19:53:18] <alexchally_cnc> PCW, will do, I have not even plugged in or looked at the outputs yet, will have to muck around more later today
[19:55:08] <PCW> I really need a xml file or something that translates from GPIO pin# to daughtercard output pin for a given daughtercard
[19:55:09] -!- md-2 has quit [Quit: Leaving...]
[19:56:34] -!- skunkworks_ has quit [Read error: Connection reset by peer]
[19:59:09] <k6mle-CNC> PCW: In setting up a 5i25 (configured for the G540), can I accept all the defaults in pncconfig?
[20:01:07] <PCW> not sure about pncconf, if you haven't got the latest pncconf you need to install the xml files for the 5I25 in the 5i25 firmware directory
[20:01:52] <PCW> pretty sure the latest pncconf has them built-in
[20:02:09] <k6mle-CNC> I have the 5i25 appearing in the pncconf dropdown, is that what you mean?
[20:02:29] <k6mle-CNC> I located a SH file in the forum and ran it ...
[20:03:21] <PCW> does the g540 firmware option show up?
[20:03:44] -!- sumpfralle [sumpfralle!~lars@p5B2CC031.dip0.t-ipconnect.de] has joined #linuxcnc
[20:04:10] phantom is now known as phantoxeD
[20:06:58] -!- mozmck has quit [Read error: Connection reset by peer]
[20:07:51] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[20:08:27] <serp> Connor: I don't remember that one.. how long ago?
[20:08:39] <Connor> year or longer.
[20:08:50] <serp> i just found them about a year ago myself
[20:08:54] <serp> so might have been before then
[20:08:58] <Connor> I brought in a Robot.. (based on power chair)
[20:09:14] <serp> I don't remember those things so probably prior to me :)
[20:09:23] <Connor> ok
[20:10:40] <k6mle-CNC> show up where?
[20:11:23] <serp> k6mle-CNC: the local hackerspace
[20:11:54] -!- alexchally [alexchally!~alexchall@131.252.138.250] has joined #linuxcnc
[20:11:57] -!- Cylly [Cylly!cylly@p54B12A73.dip0.t-ipconnect.de] has joined #linuxcnc
[20:12:33] <k6mle-CNC> Ah ... found it ... hadn't gotten that far in the screens ... I see 7ixx for selections ... nothing that says 5ixx
[20:14:06] -!- Loetmichel has quit [Ping timeout: 255 seconds]
[20:14:40] <k6mle-CNC> PCW: In the Mesa0 I/O setup page it gives the board name as 5i25 and has a drop-down for the firmware ...
[20:14:42] <alexchally> PCW: you said the other day that you had only included the firmware in the BIT file you gave me for the 5i23 and the 7i52s, but not the 7i37TA. Any chance you could hook me up with the completed file?
[20:15:00] -!- sumpfralle has quit [Ping timeout: 255 seconds]
[20:15:21] -!- Komzpa has quit [Ping timeout: 250 seconds]
[20:15:36] -!- ashcan__ has quit [Remote host closed the connection]
[20:16:11] <Tom_itx> isn't the 37 just a buffer board?
[20:16:19] -!- automata_ [automata_!~Amit@triband-mum-59.182.146.119.mtnl.net.in] has joined #linuxcnc
[20:16:22] <Tom_itx> ... i didn't check before speaking...
[20:18:10] -!- toastyde1th [toastyde1th!~toast@c-69-244-86-195.hsd1.md.comcast.net] has joined #linuxcnc
[20:18:18] -!- toastydeath has quit [Read error: Connection reset by peer]
[20:18:31] <JT-Shop> hmmm the radius I need to measure is bigger than my gauges... any ideas on how to measure it?
[20:19:08] <ssi> how accurately do you need to measure it?
[20:19:10] -!- automata has quit [Ping timeout: 255 seconds]
[20:19:29] <ssi> should be able to scribe or mark vertical and horizontal lines at the tangent points and measure from the edge to those lines
[20:19:33] <alexchally> JT-Shop: I laser cut some radius gauges to eyeball it, or you can cut a taper of a known angle and then measure how far down the taper you go before the taper matches the radius
[20:20:09] <alexchally> or if its a nice 2d part you can print a bunch of circles on paper and match it that way
[20:21:09] -!- EW57 [EW57!ad1426b1@gateway/web/freenode/ip.173.20.38.177] has joined #linuxcnc
[20:21:21] <PCW> 7i37/7i37TA just uses GPIO so the file you have is appropriate
[20:21:43] <JT-Shop> alexchally, it's a ball socket on a muffler
[20:23:04] <alexchally> JT-Shop: I would try paper cutouts first, its probably a nice nominal size
[20:24:03] -!- larryone has quit [Quit: This computer has gone to sleep]
[20:24:56] <EW57> Good afternoon all! PCW, the computer I intend to use for linuxcnc as both pci & pci-e ports, with that in mind, which would you recommend between the 5i25 & 6i25?
[20:25:08] <JT-Shop> looks close to 2.375, I'd bet it is 60mm
[20:26:13] <PCW> 5I25 as its cheaper
[20:26:42] -!- mozmck has quit [Quit: Leaving.]
[20:26:58] -!- mozmck [mozmck!~moses@67.210.159.245] has joined #linuxcnc
[20:27:00] <alexchally> PCW, you mentioned the TX0B/TX3B enable thing, do I have to drive those with a jumper, or is there a way to do that in software?
[20:27:31] <alexchally> that is, do I need to actually run a wire from a +5V out to the TXOBENA pin?
[20:29:21] <PCW> No, its just something that needs to be done in the HAL file
[20:30:44] <alexchally> PCW: ok. mooore questions, what do I need to do to make the differential outputs swing the PWM duty cycle around to control my servo?
[20:31:02] <alexchally> is that all going to happen in the .HAL file?
[20:31:51] <PCW> use a servo config and connect the pid outputs to the A,B,C PWM values
[20:32:09] <EW57> & the difference between the 5i25&6i25 is just the bus configuration, or is there more to it?
[20:32:39] <PCW> bus only the 6I25 normally just uses 5I25 configs
[20:33:44] <EW57> great, thank you sir!
[20:34:21] <PCW> alexchally: you will probably have to limit the PID output so the PWM doesn't dissappear if the output saturates
[20:34:26] -!- sumpfralle [sumpfralle!~lars@p5B2CC031.dip0.t-ipconnect.de] has joined #linuxcnc
[20:34:41] <PCW> (theres a pin on the PID comp for this)
[20:35:07] <alexchally> PCW, that is, so it does not drive it to a +5VDC high?
[20:35:37] <alexchally> or I guess drive it low
[20:35:44] <PCW> so it doesn not stop generating pulses at either extreme
[20:35:52] -!- EW57 has quit [Quit: Page closed]
[20:36:05] <ssi> aw BALLS
[20:36:11] <ssi> these motors have a different shaft size :(
[20:36:13] <PCW> I suspect your drives will fault if this happens
[20:37:09] <alexchally> PCW, it seems reasonable, I will take a close look at it with my 'scope to see what happens when I drive it with the original controller
[20:37:25] <alexchally> I don't know how else they keep it from running away at startup if they don't do that
[20:38:20] <PCW> its actually kind of clever
[20:39:08] <PCW> does it have a processor that interprets the PWM?
[20:40:01] <alexchally> PCW, it must have one in the servo driver, because the drive takes that input and outputs +-100VDC to drive the servos
[20:40:22] <alexchally> Its clever, noise resistant, and kind of a pain in my ass :D
[20:40:55] <JT-Shop> three different answers to the same question, 1st answer "it takes about an hour to get through our system", 2nd "it takes a couple of hours..." 3rd "it takes a couple of days..."
[20:41:44] * JT-Shop wonders what takes so long for a fax to get "into their system" so they can see if they received it
[20:42:01] <JT-Shop> rant off
[20:42:10] <alexchally> JT-Shop: I just had another idea, you could measure that radius using the chord length:
http://www.mathopenref.com/chord.html
[20:42:26] <alexchally> kind of a PITA, but if you have a lathe and a dial indicator it could be done
[20:43:43] <Connor> ssi: You didn't check that when you ordered ?
[20:44:21] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has joined #linuxcnc
[20:44:23] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has parted #linuxcnc
[20:47:53] <JT-Shop> alexchally, this is a big part...
[20:48:12] <alexchally> JT-Shop: sounds like an excuse for a big lathe :D
[20:49:04] <ssi> jesus christ connor, give it a rest
[20:50:07] <JT-Shop> I have a drop bed that can swing 14" give or take and 36" long but only 12" at that length
[20:50:34] <Tom_itx> JT-Shop do you have any tooling diameter enough to measure the radius?
[20:51:16] <JT-Shop> I used a drop from a piece of 2 3/8 round bar to measure it with
[20:51:21] <Tom_itx> or a socket
[20:52:56] sudobangbang is now known as register
[20:53:00] -!- h_maximilian1 [h_maximilian1!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has joined #linuxcnc
[20:53:11] -!- h_maximilian1 [h_maximilian1!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has parted #linuxcnc
[20:53:12] <Connor> ssi: Just messing with ya. :)
[20:53:26] -!- PetefromTn_ [PetefromTn_!~IceChat9@66-191-252-204.dhcp.kgpt.tn.charter.com] has joined #linuxcnc
[20:53:26] register is now known as Guest23906
[20:54:00] Guest23906 is now known as sudobangbang
[20:55:12] -!- FinboySlick has quit [Quit: Leaving.]
[20:59:10] -!- spatialbrew has quit []
[21:01:45] -!- rob_h has quit [Ping timeout: 240 seconds]
[21:02:09] -!- rob_h [rob_h!~robh@90.219.183.62] has joined #linuxcnc
[21:03:22] <ssi> ugh... I hate 5mm shafts
[21:03:32] <ssi> american timing pulleys don't come in frenchyfrench bullshit sizes
[21:03:33] Cylly is now known as Loetmichel
[21:07:25] <DaViruz> you mean restoftheworls bullshit sizes?
[21:07:59] <DaViruz> it's not like it's jsut the french that's backwards and awkward
[21:08:21] <DaViruz> it is in fact you :P
[21:09:37] -!- likevinyl [likevinyl!~mythbuste@unaffiliated/likevinyl] has parted #linuxcnc
[21:10:05] <ssi> except we make things that can be used
[21:10:17] <ssi> and purchased in a timely fashion
[21:10:40] <alexchally> ssi, you can get a pully with a 11/64 shaft and ream it without having to drill it
[21:10:44] <alexchally> and a 5mm reamer
[21:10:49] <DaViruz> surely the rest of the world manages
[21:10:53] <ssi> this assumes one has a 5mm reamer :)
[21:11:03] <ssi> I drilled some 3/16" bore pulleys that I have on hand
[21:11:11] <jdh> dont you have a lathe?
[21:11:12] <ssi> they wobble a bit but they'll have to do for now
[21:11:34] <DaViruz> like you said, you make things that can be used ;)
[21:11:39] <ssi> fixturing a 14 tooth mxl pulley on a lathe and boring a 5mm hole is not a trivial thing to do
[21:11:43] <ssi> and not worth the hassle today
[21:12:30] <ssi> it wouldn't bother me if there was a store I could drive to and buy GT2 belt and pulleys, but there's not
[21:12:36] <ssi> I can drive somewhere and buy MXL hardware
[21:13:40] <DaViruz> surely gt2 pulleys come in 5mm
[21:13:45] <DaViruz> in fact i have several with metric bores
[21:14:11] <DaViruz> i belive i even got them in a timely fashion
[21:16:08] -!- fenugrec [fenugrec!~sac@69.165.193.237] has joined #linuxcnc
[21:16:23] -!- automata_ has quit [Ping timeout: 240 seconds]
[21:16:52] <Deejay> gn8
[21:16:58] <alexchally> ssi, just hold the pully through the bore ;)
[21:17:12] -!- Deejay has quit [Quit: bye]
[21:18:24] <alexchally> if I set Scale to 0, will axis report the number of counts as the distance?
[21:18:36] <alexchally> the number of encoder counts
[21:18:41] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has joined #linuxcnc
[21:20:09] <ssi> gt2 pulleys do, in fact, come in 5mm
[21:20:18] <ssi> they're the ones I can't buy
[21:21:17] <PCW> 0 scale would not work but if you set the input scale to 1 you will have 1 encoder count per machine unit
[21:21:20] <DaViruz> oh you wanted mxl
[21:21:33] <DaViruz> never used those
[21:22:05] <DaViruz> http://openbuildspartstore.com/5mm-mxl-aluminum-timing-pulley/
[21:22:10] <DaViruz> doesn't seem too rare
[21:22:56] <ssi> I guess you missed the part where I said "That I can drive to a store and buy today"
[21:23:32] <DaViruz> i guess i didn't miss the part where you said the pulleys don't come in metric sizes
[21:23:56] <ssi> feel free to cherry-pick from the conversation to make your point
[21:24:49] <jymmm> LMAO
https://www.youtube.com/watch?v=tHvExOg4NI0
[21:26:28] -!- alexchally has quit [Ping timeout: 260 seconds]
[21:28:47] <DaViruz> well it was that sentiment that i found strange. i guess i didn't pay attention to the later stages. i guess i'll shut up if i can't contribute something useful
[21:28:49] -!- larryone has quit [Quit: This computer has gone to sleep]
[21:29:05] <PetefromTn_> Daisy can kiss my ass COOPER needs some damn ICE CREAM MAN!!
[21:29:31] <PetefromTn_> well managed to get the damn fixture machined nice and pretty.
[21:29:40] <PetefromTn_> Now working on the CAM for the part finally.
[21:29:50] <PetefromTn_> Gotta cut some stock here now.
[21:31:09] <PetefromTn_> I am loving my shop built stainless fly cutter with cemented carbide custom radius ground inserts. Makes for a SMOOTH SHINY finish!! I like smooth and shiny.
[21:31:38] <ssi> DaViruz: I'm trying to swap a set of motors out and get back to work, and the new motors have 5mm shafts instead of 1/4" shafts. I can drive to mcmaster and buy pulleys in any imperial size I need, but ordering something from god knows where maker kids online store and waiting a week doesn't fit my schedule
[21:31:45] -!- theorbtwo has quit [Ping timeout: 240 seconds]
[21:31:45] <ssi> does that clear up my intentions?
[21:33:27] <PetefromTn_> SSI Jeez man are your panties in a bunch today LOL... his name IS the virus after all.
[21:33:39] <PetefromTn_> ;)
[21:33:50] <ssi> yeah, I'm hungry and cranky
[21:33:57] <PetefromTn_> LOL me too...
[21:34:09] <PetefromTn_> I need to get this part machined and it is taking too damn long.
[21:34:22] * jymmm hands out midol to the lot of ya!
[21:34:23] <ssi> I had to completely disassemble the motion of the machine to install limit switches
[21:34:24] <PetefromTn_> I am slow as molasses with this shite.
[21:34:28] <ssi> and decided to swap these motors at the same time
[21:34:41] <PetefromTn_> a mans gotta have limits!
[21:35:18] <PetefromTn_> incidentally CamBam's holding tab feature kicks ass... Never used it before today.
[21:35:33] <ssi> haha
[21:35:50] <PetefromTn_> seriously it has auto and manual modes and lots of nice settings.
[21:35:54] <DaViruz> is it that diffult to bore them then? when i get timing belt pulleys localy they usually only stock unbored ones
[21:35:56] <Connor> PetefromTn_: Really? You haven't used that I've used it..
[21:36:14] <PetefromTn_> well LA DEE DA!!
[21:36:28] <PetefromTn_> you have had CamBam a lot longer than I have man LOL
[21:36:37] <PetefromTn_> it is quite nice tho.
[21:36:59] -!- dgarr [dgarr!~dgarrett@184.101.132.16] has joined #linuxcnc
[21:37:15] <PetefromTn_> will keep me from slinging this large piece of drop around the outside of this plate across the machine hopefully LOL.
[21:38:04] <PetefromTn_> Don't feel like milling away the entirety of this funky shape from solid will take too long and who knows maybe I can find something to do with the drop pieces they are half inch thick.
[21:38:50] <jymmm> ssi: JB Weld
[21:38:59] <ssi> jymmm: for?
[21:39:02] -!- fenugrec has quit [Quit: Leaving]
[21:39:09] <jymmm> 5mm to 1/4"
[21:39:09] <PetefromTn_> goes with the midol...
[21:39:13] <ssi> heheh
[21:39:28] <ssi> 1.35mm is a hell of a lot of clearance to take up with jbweld :P
[21:39:45] <ssi> I got these 3/16" pulleys mounted
[21:39:49] <ssi> they're a little wobbly, but it'll do
[21:39:53] <PetefromTn_> throw those bitches in that nice lathe and get er done man...
[21:39:55] <ssi> I think they might actually be 10 tooth pulleys
[21:40:04] <ssi> PetefromTn_: lathe isn't working cause you won't come help me fix it ;)
[21:40:20] <ssi> 10 tooth pulleys further doubles my resolution
[21:40:23] <PetefromTn_> Oh I will fix it right onto my trailer and haul that monster home LOL...
[21:40:37] <ssi> so between the 400 step motors and the 10 tooth pulleys, I should be down to 0.002"/step
[21:41:00] <PetefromTn_> before or after microstepping?
[21:41:05] <ssi> before
[21:41:12] <PetefromTn_> cool.
[21:41:18] <ssi> and I can microstep up to 128 :P
[21:41:40] <ssi> so what is that, 15 microinch? :P
[21:41:45] -!- larryone has quit [Ping timeout: 240 seconds]
[21:41:50] -!- pjm_ has quit [Read error: Connection reset by peer]
[21:42:01] <PetefromTn_> I want you to burn me a huge Bronco emblem into some plastic so I can put it in my shop LOL...
[21:42:13] <ssi> haha ok
[21:42:26] -!- pjm_ [pjm_!~pjm@uhfsatcom.plus.com] has joined #linuxcnc
[21:42:30] <ssi> I think I might have to make the first project be the obligatory "do not stare into beam with remaining eye" sign for the shop
[21:42:56] <PetefromTn_> how about if you can see this it wil be the last time...
[21:43:16] <PetefromTn_> or maybe don't go into the light carol anne..
[21:44:06] <PetefromTn_> how about no officer I don't have any idea why my neighbors house burst into flames hehehe
[21:44:47] <ssi> I wonder if I actually could set my neighbor's house on fire with the laser
[21:44:50] <ssi> that's sorta intriguing
[21:44:50] <ssi> haha
[21:44:53] <PetefromTn_> and how did I get this burn hole in my crotch...
[21:45:20] <PetefromTn_> I got a million of em. just ask me LOL
[21:45:53] <ssi> gah I'm hungry... what's for dinner?
[21:46:22] <PetefromTn_> We are making some mussels Marinara with pasta
[21:46:48] <ssi> sweet brt
[21:46:49] <PetefromTn_> Dacia made the Sauce yesterday it was pretty tasty!
[21:47:38] -!- theorbtwo [theorbtwo!~theorb@cpc8-swin16-2-0-cust252.3-1.cable.virginm.net] has joined #linuxcnc
[21:48:14] <PetefromTn_> Speaking of which I gotta get that stuff ready here. I also need to finish this damn program and get it ready to mill. Gonna clamp the part down first then drill and then bolt to fixture. Wish me luck man I NEED it.
[21:48:28] <ssi> haha good luck
[21:48:54] <PetefromTn_> I like the show cut widths feature of CamBam it saves my bacon a lot.
[21:49:17] -!- alexchally [alexchally!~alexchall@131.252.138.250] has joined #linuxcnc
[21:49:21] <PetefromTn_> especially when I put the lead in in the wrong spot which is kinda easy to do in CamBam.
[21:49:52] -!- zeitue [zeitue!~z@67.221.132.234] has joined #linuxcnc
[21:53:49] <PetefromTn_> Connor Hey man is there a way to transfer tabs from one machining operation to the next?
[21:54:18] -!- syyl [syyl!~sg@p4FD111F9.dip0.t-ipconnect.de] has joined #linuxcnc
[21:56:05] <zeeshan> found another mistake in this part this guy made
[21:56:10] <zeeshan> he drilled the bolt circle wrong
[21:56:24] <zeeshan> :{
[21:56:28] <PetefromTn_> ya sure you are not "THIS GUY"
[21:56:31] <zeeshan> no
[21:56:39] <zeeshan> i dont make stupid mistakes like that
[21:56:42] <PetefromTn_> just checkin man hehehe
[21:56:54] <PetefromTn_> EVERYBODY makes stupid mistakes man...
[21:56:59] <zeeshan> my mistakes consist of dyslexia
[21:57:04] <zeeshan> thats about it
[21:57:08] <zeeshan> but im consistent
[21:57:09] <zeeshan> haha
[21:57:25] <zeeshan> 2.625 ?
[21:57:26] <PetefromTn_> I'm consistent too... I CONSISTENLY screw up stuff
[21:57:28] <zeeshan> 2.652!
[21:57:29] <zeeshan> :)
[21:57:42] <zeeshan> the rule of machining is
[21:57:45] <zeeshan> double check double check!
[21:57:49] <zeeshan> if im doing bolt circles
[21:57:52] <zeeshan> ill always bust out the ruler
[21:57:55] <zeeshan> just to double check
[21:58:04] <t12> mistakes can actively evade double checks
[21:58:07] <zeeshan> this guy is out by 1.118"
[21:58:07] <PetefromTn_> I usually spot drill and check the positions.
[21:58:09] <t12> for example if you double check the pattern
[21:58:11] <zeeshan> not sure how that happens
[21:58:15] <t12> your drawing dimensions are instead wrong
[21:58:26] -!- bedah has quit [Quit: Ex-Chat]
[21:58:31] <zeeshan> i don't mean to sound cocky
[21:58:39] <zeeshan> but after doing 290381320912380932890 problems
[21:58:42] <PetefromTn_> Oh sure ya do..LOL
[21:58:56] <zeeshan> #1 rule is double/triple check work
[21:59:04] <zeeshan> like for example, some of our problems have a solution 3 pages long
[21:59:15] <zeeshan> if you make a mistake early on, it screws up the entire solution
[21:59:40] <zeeshan> so usually i read numbers forward and then backwards
[21:59:44] <zeeshan> then if im adding numbers
[21:59:53] <zeeshan> i'll subtract the answer from either of the numbers i added
[22:00:12] <zeeshan> its almost ADD
[22:00:40] <zeeshan> some of these profs are not lenient at all
[22:00:50] <zeeshan> if you scre wup in the beginingm, they'll mark the whole question wrong
[22:01:02] <zeeshan> but some of them will cary on your mistake and see if you arrive at the right answer using your numbers
[22:01:04] <ssi> good for them
[22:01:20] <ssi> I hate the whole "it's not the answer that counts, it's how you solved the problem" mentality
[22:01:23] <ssi> the answer's still wrong
[22:01:31] <ssi> you've still arrived at the wrong place
[22:01:36] <zeeshan> the ones that mark harsh usually write "if this was a bridge, people have died"
[22:01:37] <zeeshan> haha
[22:01:38] <ssi> you need to learn how to check your work, which it sounds like you've done :P
[22:01:49] <PetefromTn_> The last part I made working for that shop was a small steel bracket. I was being VERY Careful because it had several features on it. I still managed to machine some champfers on the bottom instead of the top. Basically lunched a half dozen parts and an entire days work.
[22:02:21] <zeeshan> im just pissed off cause
[22:02:27] <zeeshan> this other guy quit the masters program
[22:02:29] <zeeshan> a couple days ago
[22:02:44] <zeeshan> so all the work he was supposed to do
[22:02:47] <zeeshan> got thrown back at me
[22:02:49] <PetefromTn_> luckily I made a couple spare extras so we were not out anything really just time.
[22:03:10] <PetefromTn_> The drawing was plain to see but somehow I missed the forest for the trees.
[22:03:40] <PetefromTn_> What kills me is I stared at that drawing most of the damn day and still got it wrong. WHAT A JACKASS!
[22:03:43] <zeeshan> http://imgur.com/a/mHZ89
[22:03:44] <zeeshan> er
[22:03:53] <zeeshan> whoops :)
[22:04:08] <zeeshan> PetefromTn_: more coffee!
[22:04:09] <zeeshan> :]
[22:04:54] <PetefromTn_> Unfortunately I am not a coffee drinker.
[22:04:59] <zeeshan> the holes hje made for press fitting dowels
[22:05:03] <zeeshan> are -.002 undersize
[22:05:08] <zeeshan> so its a clearance fit, not a press fit
[22:05:18] <PetefromTn_> hell just smash em in there..
[22:05:19] <zeeshan> i actually fixed that by using loctite!
[22:05:21] <zeeshan> no
[22:05:22] <zeeshan> its a clearance
[22:05:24] <ssi> loctite green
[22:05:24] <zeeshan> so they slide in
[22:05:24] <ssi> :D
[22:05:26] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has parted #linuxcnc
[22:05:28] <zeeshan> i used loctite red
[22:05:31] <zeeshan> its all i had
[22:05:41] <alexchally> zeeshan, are you at a university?
[22:05:50] <zeeshan> alexchally: yes
[22:05:58] <alexchally> ME?
[22:06:02] <zeeshan> yes
[22:06:24] <alexchally> nice, I am an ME as well, also one of the machinists/engineers in our science support shop.
[22:06:38] <zeeshan> which university?
[22:06:44] <alexchally> Portland State
[22:06:51] <zeeshan> nice
[22:06:58] <alexchally> you?
[22:07:03] <zeeshan> mcmaster
[22:07:06] <zeeshan> near toronto
[22:07:12] <alexchally> so fancy
[22:07:30] <alexchally> I wish I got a fancy ring when I graduated :/
[22:07:37] <zeeshan> im just venting about a project me and another graduate student were working on
[22:07:42] <zeeshan> which he screwed machining wise
[22:07:43] <zeeshan> :)
[22:07:58] <zeeshan> you guys dont get a ring in the states?
[22:08:09] <alexchally> nope
[22:08:15] <zeeshan> do you have any other symbol that is supposed to remind you of your obligation?
[22:08:20] <alexchally> no order of the engineer, no iron ring...
[22:08:28] <alexchally> zeeshan: the threat of a lawsuit?
[22:08:32] <zeeshan> hahah
[22:08:50] <alexchally> i would actually love to machine myself one, but it seems kinda... douchey?
[22:09:11] <zeeshan> it's kind of cool to have
[22:09:27] <zeeshan> i was in the middle of no where (outskirts of thunder bay ontario) at a bar
[22:09:42] <zeeshan> and an older engineer recognized the ring and he had one too
[22:09:43] <zeeshan> and we chatter
[22:09:45] <zeeshan> *chatted
[22:10:51] <alexchally> zeeshan: the only thing is I would feel really uncomfortable wearing jewlery in the shop... that shit is how you get your finger cut off
[22:11:00] <alexchally> ...says the man with a gigantic beard
[22:11:18] <zeeshan> yep, i always take it off when working on a machine
[22:11:50] <zeeshan> also it sucks if you're not a ring type of person
[22:11:54] <zeeshan> i never used to wear one
[22:12:00] <zeeshan> so it took a couple of months to get used to it
[22:12:31] <zeeshan> alexchally: do you help the science students machine their projects?
[22:13:41] <alexchally> zeeshan, yes. I spend about 80% of my time designing/machining parts for professors and graduate students, and the other 20% teaching people how to use machine tools and the like
[22:14:28] -!- Baltzar has quit [Ping timeout: 246 seconds]
[22:14:29] <alexchally> zeeshan: imgur.com/a/hgmcm#0
[22:14:33] <alexchally> a few things I have made
[22:14:37] <alexchally> but by no means all of them
[22:14:53] <zeeshan> looks like a tensile test specimen
[22:14:54] <zeeshan> :)
[22:15:09] <zeeshan> the first one
[22:15:33] <alexchally> just about everything does when you pull on it hard enough :D
[22:15:37] <zeeshan> http://i.imgur.com/RUu3oNO.jpg
[22:15:42] <zeeshan> that is a nice clamp.
[22:15:45] <alexchally> but yeah, that was for scooping some nasty something
[22:16:16] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has joined #linuxcnc
[22:16:19] -!- h_maximilian [h_maximilian!~bonsai@dslb-178-002-228-151.178.002.pools.vodafone-ip.de] has parted #linuxcnc
[22:16:47] <alexchally> zeeshan: thanks! I took step by step pictures of it being made, used it as a project for my last machining class imgur.com/a/hgmcm#0
[22:16:51] <alexchally> errr
[22:16:55] <alexchally> http://imgur.com/a/ocxkc#0
[22:17:01] <ssi> home/limit switches are always the most tedious part of any machine build
[22:17:34] <zeeshan> ssi i dont have any home / limit switches
[22:17:34] <zeeshan> :D
[22:17:42] <zeeshan> my machine work space is technically 12x36
[22:17:48] <zeeshan> but ive set ot to 100x100
[22:17:49] <zeeshan> :D
[22:17:55] <zeeshan> i will have a bad crash one day
[22:18:00] -!- tjtr33 [tjtr33!~tjtr33@192.34.28.89] has joined #linuxcnc
[22:18:32] <ssi> yeah I didn't have limits on the plasma table for years
[22:18:36] <ssi> but laser is getting them up front
[22:18:59] <ssi> hey guys anyone know offhand how to use halrun or something to dump all the pins on a hm2 device?
[22:19:15] -!- sumpfralle has quit [Ping timeout: 240 seconds]
[22:19:54] <ssi> halrun show all works for me, but it's not working for k6mle-CNC and I suspect it's because linuxcnc isn't already running for him
[22:20:39] <zeeshan> http://i.imgur.com/iavYTAu.jpg
[22:20:43] <zeeshan> nice
[22:20:48] -!- zzolo has quit [Quit: zzolo]
[22:20:49] <zeeshan> i didnt think of setting up like that
[22:20:53] <zeeshan> ive always used wedges
[22:20:58] <zeeshan> or whatever you call them
[22:21:07] <zeeshan> premachined triangles
[22:21:28] <ssi> yea I have some of those
[22:21:32] <alexchally> i would call them precision triangles. or angle blocks
[22:21:41] <PCW> halcmd needs linuxcnc running
[22:21:41] <ssi> a 30/60/90 and a 45/45/90
[22:21:42] <PCW> halrun doesn't
[22:21:54] <alexchally> zeeshan, its a super quick way when +-1deg is all you need
[22:22:05] <zeeshan> alexchally: looks like it!
[22:22:09] <alexchally> for when a sine bar is overkill :D
[22:22:26] <ssi> PCW: thx
[22:22:37] <zeeshan> http://ecx.images-amazon.com/images/I/A1XSrodB9oL.jpg
[22:22:39] <zeeshan> thats what i has
[22:23:01] <ssi> his hm2 driver seems like it might be diffeernt than mine
[22:23:14] <ssi> I have a hm2_5i25.0.stepgen.xx.enable, he doesn't seem to
[22:23:18] <ssi> at least it's complaining about it
[22:23:53] <ssi> oh nm i think i see his issue
[22:23:53] -!- uwe_ has quit [Ping timeout: 256 seconds]
[22:24:11] -!- uwe_ [uwe_!~uwe_@ipservice-092-211-039-181.092.211.pools.vodafone-ip.de] has joined #linuxcnc
[22:24:16] <PCW> halrun
[22:24:17] <PCW> halcmd: loadrt hostmot2
[22:24:19] <PCW> halcmd: loadrt hm2_pci
[22:24:24] -!- asdfasd [asdfasd!~332332@90.219.66.103] has joined #linuxcnc
[22:26:34] -!- alexchally has quit [Ping timeout: 240 seconds]
[22:32:58] <PetefromTn_> Hope this works LOL.
[22:34:45] -!- tomp3 [tomp3!~tjtr33@173-29-36-96.client.mchsi.com] has joined #linuxcnc
[22:38:12] -!- tjtr33 has quit [Ping timeout: 245 seconds]
[22:40:58] <k6mle-CNC> PCW: in my debug info, I'm also getting "Can not find -sec EMC - var NML_FILE -num 1"
[22:42:13] <PCW> try this
[22:42:15] <PCW> halrun
[22:42:17] <PCW> halcmd: loadrt hostmot2
[22:42:18] <PCW> halcmd: loadrt hm2_pci
[22:42:20] <PCW> halcmd: show all
[22:42:58] -!- The_Ball has quit [Remote host closed the connection]
[22:44:35] <k6mle-CNC> PCW: Okay ... did that ...
[22:44:50] -!- tjb11 [tjb11!~tjb1@cpe-67-252-67-92.stny.res.rr.com] has joined #linuxcnc
[22:45:23] <PCW> no complaints?
[22:45:26] -!- syyl_ [syyl_!~sg@p4FD13A75.dip0.t-ipconnect.de] has joined #linuxcnc
[22:45:52] <k6mle-CNC> Not sure what a complaint would look like ...
[22:46:04] <k6mle-CNC> I see component pins, etc
[22:47:22] <k6mle-CNC> Shall I use pastbin?
[22:47:45] <ssi> paste your hal and ini files
[22:48:04] <k6mle-CNC> along with the output from show all?
[22:48:12] <ssi> sure
[22:48:21] <k6mle-CNC> okay ... just a sec ...
[22:48:34] -!- syyl has quit [Ping timeout: 255 seconds]
[22:48:48] <PCW> so the hardware/linuxcnc are working you likely have hal/ini file issues (or wrong firmware)
[22:48:49] -!- tjb1 has quit [Ping timeout: 256 seconds]
[22:49:04] <ssi> yeah that's what we're trying to sort out
[22:49:25] <ssi> I have no idea where "Can not find -sec EMC - var NML_FILE -num 1" is coming from
[22:49:36] <k6mle-CNC> http://pastebin.com/aFw9LtwU
[22:49:40] <k6mle-CNC> show all output
[22:50:11] <ssi> yea that looks fine
[22:50:47] <k6mle-CNC> http://pastebin.com/wmcbuy2d
[22:50:50] <k6mle-CNC> HAL file
[22:51:31] <k6mle-CNC> http://pastebin.com/ffrgB2N2
[22:51:36] <k6mle-CNC> INI file.
[22:52:14] <ssi> ok what about RCSG540A.hal, custom.hal, and custom_postgui.hal?
[22:52:17] <ssi> your ini is loading those
[22:52:36] <k6mle-CNC> I can post those as well ... just a sec ....
[22:53:23] <k6mle-CNC> custom.hal is empty ... just a pair of comments.
[22:53:33] <ssi> ok
[22:53:39] <ssi> it's mostly the first one I'm concerned about
[22:54:32] <k6mle-CNC> The 2nd link is the Hal file RCSG540A
[22:54:57] <ssi> oh ok
[22:55:21] <k6mle-CNC> custom_postgui.hal has a pair of comments along with this: sets spindle-at-speed true
[22:55:27] tjb11 is now known as tjb1
[22:55:34] <ssi> well there's where that problem's coming from
[22:55:35] <k6mle-CNC> I control the spindle speed manually on this unit.
[22:55:42] <k6mle-CNC> :)
[22:55:55] <ssi> comment that out for now
[22:56:12] <k6mle-CNC> just did that ...
[22:56:23] <ssi> k retry
[22:56:45] <k6mle-CNC> it came up with no errors ... now I'll turn on the power to the driver ...
[22:58:59] <k6mle-CNC> Okay ... I'm running a small chunk of gcode that just moves along the Y axis for .5" up and back ... in a loop ...
[22:59:09] <k6mle-CNC> getting an occaisonal missed DIR
[22:59:15] <k6mle-CNC> not as bad as before ...
[22:59:43] <ssi> that's really strange
[23:00:13] -!- Einar1 has quit [Quit: Leaving.]
[23:00:25] <k6mle-CNC> I've not done anything with the little pots on the G540 yet ... will that effect it?
[23:01:22] <ssi> that i don't know
[23:01:47] <k6mle-CNC> hmm
[23:04:47] -!- tomp3 has quit [Ping timeout: 250 seconds]
[23:04:58] -!- sumpfralle [sumpfralle!~lars@on1.informatik.uni-rostock.de] has joined #linuxcnc
[23:05:16] -!- Roguish has quit [Remote host closed the connection]
[23:06:43] <alexchally_cnc> PCW, so now I am trying to get my output working, but am getting an error after I uncommented everything that had to do with 3pwmgen
[23:06:45] <alexchally_cnc> http://pastebin.com/FgQ3z3kw
[23:06:49] <alexchally_cnc> thats my .hal
[23:07:25] <alexchally_cnc> the error is on line 82: pin hm2_5i23.0.3pwmgen.00.A-value.enable does not exist
[23:08:05] <PCW> thats correct
[23:08:12] <PCW> no such pin
[23:09:05] <k6mle-CNC> PCW: getting an occaisional missed DIR, but not as bad as before ...
[23:09:21] <PCW> bad G540?
[23:09:28] <alexchally_cnc> PCW, ok, any thoughts on how I might get from where I am to where I would like to be?
[23:09:57] <k6mle-CNC> the G540 is brand new ...
[23:09:58] <PCW> do halcmd, show pin and use only what you have :-)
[23:11:00] <PCW> well if thye G540 doesnt follow the DIR signal I would suspect it
[23:11:30] <PCW> Should never happen
[23:12:05] <k6mle-CNC> okay ... I'll try the folks at Gecko tomorrow ...
[23:12:24] <PCW> maybe there are other issues (mechanics?)
[23:13:06] <k6mle-CNC> Not sure it's a mechanical issue, as the mill was working fine (albeit slower) with the old driver ...
[23:13:42] <alexchally_cnc> PCW, when I try halcmd show pin I get: RTAPI: ERROR: could not open shared memory (errno=2)
[23:13:42] <alexchally_cnc> Segmentation fault
[23:14:14] <PCW> alexchally_cnc note that the three phase pwmgen only has one enable per 3 pwmgens
[23:14:27] <PCW> linuxcnc has to be running
[23:14:37] <PCW> (for halcmd)
[23:14:55] <PCW> (or the realtime needs to be setup somehow)
[23:15:57] <alexchally_cnc> PCW, but I can't get linuxcnc to run because I need the info from that command?
[23:16:13] <alexchally_cnc> or am I missing something? I feel like I am missing something
[23:16:42] <k6mle-CNC> alex: try halrun from the command line.
[23:16:59] <alexchally_cnc> k6mle-CNC, such success
[23:17:07] <PCW> OK
[23:17:09] <PCW> halrun
[23:17:11] <PCW> halcmd: loadrt hostmot2
[23:17:13] <PCW> halcmd: loadrt hm2_pci
[23:17:15] <PCW> halcmd: show all
[23:17:30] <k6mle-CNC> That's how I got around the same problem!
[23:17:48] <ssi> hehehe
[23:17:51] <ssi> we're all learning today :)
[23:17:58] <k6mle-CNC> dang!
[23:18:27] <zeeshan> i have a 24"x24" 14 gauge sheet of steel
[23:18:46] <zeeshan> i need to drill 120mm holes
[23:18:49] <zeeshan> suggestion? :)
[23:18:55] <alexchally_cnc> hole saw
[23:19:09] <zeeshan> i was thinkin
[23:19:09] <zeeshan> yes
[23:19:09] <zeeshan> but i'm not sure how i'll hold it down
[23:19:09] <ssi> plasma :P
[23:19:09] <zeeshan> my drill press table is kind of small
[23:19:15] <alexchally_cnc> double stick on top of wood?
[23:19:16] <zeeshan> i have plasma
[23:19:21] <zeeshan> but no circlecutting attachment
[23:19:25] <ssi> CNC plasma :)
[23:19:26] <alexchally_cnc> zeeshan, isn't holding it what undergrads are for?
[23:19:35] <zeeshan> alexchally_cnc: haha
[23:19:37] <zeeshan> i'm doing this at home
[23:19:58] -!- The_Ball [The_Ball!~ballen@202.10.92.134] has joined #linuxcnc
[23:20:04] <zeeshan> http://i.imgur.com/UcxpeZO.jpg
[23:20:07] <zeeshan> on the right drill press
[23:20:21] <alexchally_cnc> PCW, ok, that worked, i now have a list of things, but I am not sure how to turn that list of things into a working hal
[23:20:25] <zeeshan> i usually like to clamp stuff down good when using a hole saw
[23:20:27] <zeeshan> cause its violent
[23:20:32] <ssi> yes, it is
[23:20:39] <zeeshan> hehe
[23:20:59] <alexchally_cnc> if you have a welder you could tack it down to something easier to hold onto
[23:21:24] <alexchally_cnc> actually, I would do it with a hand drill while standing on the thing
[23:21:39] <alexchally_cnc> if you have something sacrificial to put under it, like say a pallet
[23:22:01] <k6mle-CNC> pallet --- better than an undergrad! :)
[23:22:03] <zeeshan> got a couple of 2xx4
[23:22:10] <zeeshan> i like the standing idea
[23:22:19] <PCW> first thing is consider is that you only have one enable per three pwm outputs so you need to delete some stuff
[23:22:26] <zeeshan> lemme try it out
[23:24:28] -!- thomaslindstr_m has quit [Quit: Leaving...]
[23:25:22] <alexchally_cnc> PCW, ok, the lines net emcmot.00.enable => hm2_5i23.0.3pwmgen.00.A-value.enable have been commented out for all three axis
[23:25:59] <alexchally_cnc> now its unhappy with... setp hm2_5i23.0.3pwmgen.00.A-value.output-type 1 #pwm on pin1, dir on pin2
[23:26:11] <alexchally_cnc> "parameter or pin not found"
[23:26:20] <PCW> thats not a pin from your list...
[23:26:35] <PCW> copy paste from your list
[23:29:58] <alexchally_cnc> ahhh, the full list had run off the top
[23:30:18] <PCW> there is no output type for 3pwmgens
[23:31:10] <PCW> and the enable for three channe;ls is probably like
[23:31:12] <PCW> net emcmot.00.enable => hm2_5i23.0.3pwmgen.00.enable
[23:32:01] <PCW> (thats the enable for pwm.00 A,B,C)
[23:33:01] -!- PetefromTn_ has quit [Ping timeout: 256 seconds]
[23:33:21] -!- malcom2073 has quit [Quit: http://quassel-irc.org - Chat comfortably. Anywhere.]
[23:37:10] -!- sirdancealot has quit [Ping timeout: 264 seconds]
[23:47:39] -!- PetefromTn_ [PetefromTn_!~IceChat9@66-191-252-204.dhcp.kgpt.tn.charter.com] has joined #linuxcnc
[23:48:53] <ssi> http://www.autofocus.ca/media/5kfyb9i6n5ag3r/source/06_turbonique-Rocket.jpg?t=6006364ba32a3c2cee500b65b68127e7
[23:48:56] <ssi> holy crap i want that
[23:50:18] -!- h_maximilian1 [h_maximilian1!~bonsai@dslb-094-216-255-022.094.216.pools.vodafone-ip.de] has joined #linuxcnc
[23:50:26] -!- sirdancealot [sirdancealot!~koo5@37-48-36-28.tmcz.cz] has joined #linuxcnc
[23:51:05] <XXCoder> random thought
[23:51:13] <XXCoder> robot arm using CNC parts?
[23:51:31] <ssi> um
[23:51:33] <ssi> cnc machines are robots
[23:51:36] <ssi> just specialized ones :
[23:51:48] <XXCoder> I know, but how adoptable is software anyway
[23:51:54] <ssi> plenty
[23:52:12] <XXCoder> interesting. was it actually real motor?
[23:52:18] <ssi> ya
[23:53:15] -!- AR_ [AR_!~AR@24.238.81.234.res-cmts.sth2.ptd.net] has joined #linuxcnc
[23:53:18] <XXCoder> http://justacarguy.blogspot.com/2009/06/turbonique-advertising-turbo-axle-and.html
[23:53:20] <syyl_> i saw a kuka robot with a jaeger highspeed spindle on a trade show a few years ago
[23:53:22] <syyl_> machining foam
[23:53:38] -!- patricka_ has quit [Remote host closed the connection]
[23:56:50] -!- i_tarzan has quit [Read error: Connection reset by peer]
[23:58:14] -!- XXCoder1 [XXCoder1!~XXCoder@c-24-19-85-77.hsd1.wa.comcast.net] has joined #linuxcnc
[23:58:57] -!- XXCoder has quit [Ping timeout: 250 seconds]
[23:59:56] -!- phantom [phantom!destroy@a89-154-119-158.cpe.netcabo.pt] has joined #linuxcnc
