[07:46:57] <zeeshan|2> archivist: how the heck do you even inspect them after :P
[07:48:36] <archivist> in that case it is a simple one that I just compared to the original
[07:48:43] <zeeshan|2> i see
[07:48:51] <zeeshan|2> sometime by the end of this year
[07:48:58] <zeeshan|2> i'd like to start producing some metal helical gears
[07:49:00] <zeeshan|2> for transmissions
[07:49:08] <archivist> for a lot of stuff the tolerance is wider than you may be expecting
[07:49:23] <zeeshan|2> for car stuff
[07:49:28] <zeeshan|2> i can only persume the tolerances are tight
[07:49:41] <archivist> very tight
[07:50:07] <zeeshan|2> so to do this, i'd need to have at least a 4 axis
[07:50:11] <zeeshan|2> and some way to inspect
[07:50:15] <zeeshan|2> i need to research it more :P
[07:50:41] <archivist> hob them, not sure if some production is ground
[07:50:56] <zeeshan|2> hob might get expensive
[07:51:02] <zeeshan|2> cause of the different ratios
[07:51:14] <zeeshan|2> honestly, i should prolly say fuck it to helical gears
[07:51:18] <zeeshan|2> and just make straight cut gears
[07:51:26] <zeeshan|2> helical gears are stronger
[07:51:34] <zeeshan|2> but i can just make the face width of the straight cut gears wider
[07:51:38] <archivist> hob is generation you dont care what the ratio is
[07:51:38] <zeeshan|2> and just deal with the noise
[07:51:57] -!- balestrino [balestrino!~balestrin@host192-212-dynamic.245-95-r.retail.telecomitalia.it] has joined #linuxcnc
[07:52:40] <archivist> you can mill helical should be quieter than milled straight
[07:53:02] <zeeshan|2> http://www.practicalmachinist.com/vb/attachments/f38/26946d1286581656-help-gear-hobbing-helical-gear-pictures-062small.jpg
[07:53:02] <archivist> linuxcnc can hob too
[07:53:05] <zeeshan|2> you're saying something like that
[07:53:06] <zeeshan|2> right?
[07:53:10] <zeeshan|2> just hob at an angle
[07:53:48] <archivist> yes and gear the spindles together
[07:54:26] <archivist> one also has the lead to add into the rotation with distance cut
[07:54:44] <zeeshan|2> here's another thing
[07:54:45] <zeeshan|2> http://valuablemechanisms.files.wordpress.com/2010/05/bevel-gears.png
[07:54:49] <zeeshan|2> if iwanna make bevel gears
[07:54:53] <zeeshan|2> can it be done on a 4 axis?
[07:55:10] -!- rob_h [rob_h!~robh@176.248.180.75] has joined #linuxcnc
[07:55:34] <zeeshan|2> gear machining interests me :)
[07:55:38] <archivist> probably but the maths is....
[07:56:10] <archivist> I have not fully cracked straight generated bevels
[07:56:36] <zeeshan|2> the pinion looks hard to make
[07:56:46] <zeeshan|2> cause of the way the teeth curve
[07:56:53] <zeeshan|2> the ring gear seems fairly standard
[07:56:59] <zeeshan|2> something that you can do using a 3 axis
[07:57:15] <zeeshan|2> http://www.iwasa-tech.com/product/img/DSC_0515.jpg
[07:57:19] <zeeshan|2> looks like they use a bull nose cutter
[07:57:23] <zeeshan|2> ball nose cutter
[07:57:52] <Loetmichel> when i can make threads on a chinese 6040 you sure can make bevel gears on your machine.
[07:58:34] <archivist> zeeshan|2, that is probably only the gashing stage
[07:59:31] <archivist> the maths http://www.archivist.info/gear/designbevel.php
[07:59:49] <zeeshan|2> rofl
[08:00:04] <zeeshan|2> the gears i wanna make arent even straight
[08:00:06] <zeeshan|2> they're offset
[08:00:09] <archivist> I know
[08:00:25] <zeeshan|2> looks like a pain
[08:00:46] <zeeshan|2> but fun
[08:01:16] <archivist> they build the maths into the machine, and have some near enough parts
[08:01:24] -!- asdfasd [asdfasd!~654365635@2.123.123.2] has joined #linuxcnc
[08:02:09] <archivist> the spiral gears are made with special cutters, look at youtube
[08:02:58] <zeeshan|2> http://www.youtube.com/watch?v=8aUQM-VtElo
[08:03:05] <zeeshan|2> this guy seems to be using just a slitting saw
[08:03:05] <zeeshan|2> lol
[08:03:12] <zeeshan|2> sparks flying everywhere
[08:03:52] <zeeshan|2> purely mechanical system
[08:03:53] <zeeshan|2> fancy
[08:04:14] <Loetmichel> more like a flycutter than a slitting saw
[08:04:21] <archivist> flycutter
[08:04:32] <zeeshan|2> whoops
[08:04:32] <zeeshan|2> =D
[08:04:38] <Loetmichel> i would think: with the tooth for gound into it
[08:04:40] <Loetmichel> form
[08:05:03] <zeeshan|2> okay on this note
[08:05:03] <Loetmichel> ground
[08:05:04] <zeeshan|2> its bed time
[08:05:05] <zeeshan|2> 4am :{
[08:05:07] <zeeshan|2> gnite!
[08:05:08] <archivist> but the form should be changing along the gear
[08:05:22] <Loetmichel> maybe he compromized?
[08:05:48] <archivist> there are often compromises
