[00:15:50] <Tom_itx> can i invert a halui output signal or do i need to run it thru a 'not' component?
[00:18:42] -!- The_Ball [The_Ball!~ballen@202.10.92.134] has joined #linuxcnc
[00:18:59] <JT-Shop> output to a physical output or logical?
[00:19:28] <Tom_itx> logical
[00:20:07] <Tom_itx> physical in the end but further down the logic train
[00:20:26] <JT-Shop> use not then
[00:29:27] <JT-Shop> guy on the forum wants to hold 0.001" with a backlash of 0.005" with software backlash compensation
[00:32:02] <Tom_itx> good luck
[00:33:51] <JT-Shop> trying to singulate PC boards
