I am trying to install emc2 / ubuntu 8.04 live cd and would not let me partition, during interactive install, no erro msg. show s up
how much ram is in your system?
did you run the media test on the cd at the first menu?
maybe his hard disk controller isn't being detected
512 mb ddr
no dit not run media test
ok, that is enough
run the media test - it's very easy to get a bad cd burn
mih, good idea to test the cd, and, need more info on 'would not let me partition', what did you see?
ok , however Im am booted on the livecd
that's good but is not a substitute for the media check
can I mediacheck within ubuntu?
Optic: fdisk -l shows nothing, does this mean hd is not detected?
i would imagine
but it doesn't hurt to do the test
check dmesg output and see if it got your controller
is your hard disk weird at all?
no errors found for integrity check
this is min
this is mih
what kind of disk is it?
(IDE, SCSI, SATA ...)
ok, that should be detected, unless the controller is weird
what's the motherboard chipset?
msi neo2 platinum [ nvidia ]
mih have you ever installed linux on this system before?
I had ubuntu 8
sometimes you'll have two IDE disks with the same master/slave flag; windows will happily use it but linux complains
I will remove the slave hd
you can install EMC2 and the realtime kernel onto an already installed 8.04 system
you don't need the liveCD
[04:22:39] <SWPadnos> http://wiki.linuxcnc.org/cgi-bin/emcinfo.pl?Installing_EMC2#On_Ubuntu_8_04_using_precompiled_EMC2_packages
I don't know what I have now, it won't boot by itself
if you can't get our liveCD to work, please try a stock Ubuntu 8.04 CD and let us know if that works
can you give me the link again my chat window froze
[04:26:28] <SWPadnos> http://wiki.linuxcnc.org/cgi-bin/emcinfo.pl?Installing_EMC2#On_Ubuntu_8_04_using_precompiled_EMC2_packages
if you can't get our liveCD to work, please try a stock Ubuntu 8.04 CD and let us know if that works
was that freeze on the EMC machine or another?
md5 the iso and burn at 4x speed
stock live cd works
could you make a wiki page and stick the output of dmesg on it?
and maybe lspci
(upload the files and link to them if you could)
[04:29:23] <JymmmEMC> http://codepad.org
there have been a couple of reports like this, but I don't think we have a list of hardware that the problem crops up on
no, the wiki is a better place for this I think :)
but ide is ide, unless it's an onboard RAID or something
"EMC2 CD didn't work on this hardware, 8.04 CD did" ...
some of those have been problematic for Linux in general
[04:31:26] <JymmmEMC> http://www.metacafe.com/watch/2696469/hyundai_aggressive_marketing_against_big_3/
SWPadnos: did you see my Q about simple/cheap 2 or 3 I/O via ethernet?
yep, nothing came to mind, especially in the tax bracket I expect you're looking for ;)
I would try on an old compaq wity 256 ram would be enough for emc2?
I think you need at least 256, prefereably 512 for the install
you can run with 256
SWPadnos: Yep $20 or less =)
I know where you can get connectors for that price
SWPadnos: me too, your junk box
better pricing too FREE!
sure, I'll sell you some 10/100 connectors at $20 each
I got those
damn. and I was getting excited about the profit potential
Yeah, go ahead and take out a 3rd on your house for that
no no no, I'm the one who *gets* the revenue
SWPadnos: Sure, tell the bank that
is there description of boot live cd image from usb thumb? ( wiki describes cf via ide )
SWPadnos: RFC2324 and RFC 2325
tomp: It works good
just copy cd contents to thumb?
tomp, Les Newell made a CF turotial, and there's been success with USB sticks with a tutorial on PenDriveLinux.com (I think)
ok, pendrivelinux hello :)
Not anywhere close actually
also, there's an application in Jaunty (probably in 8.xx also, via backports) which will install an ISO onto a USB drive
ought be a start... Install Ubuntu 8.10 to a Flash Drive using the Live CD http://www.pendrivelinux.com/ubuntu-810-install-using-the-built-in-usb-installer/
dang, does ubuntu 8.04 have a 'System > Administration > Create a USB startup disk:' menu item? ( on w$ now )
no, I think it was added in 8.10
but it's possible that it's available in backports (you have to enable that explicitly in Synaptic)
ok, rebooting, thx
Heh, he could have just used the VM I created! lol
nope - oh well :)
oh hey, I downloaded the P2V migration tool from VMWare
we'll see how well it works
physical to virtual
have you used it at all?
I'm planning on it, but I heard that it might catch EVERYTHING
I was wondering how that was bad :)
I need the disk space before I can try it out
What I need is a damn NAS box
yep. I've got to get my other workstation somewhere useful
I'm also maxed out the hdd in the MBP, so I need to crack the sucker open again and installed a larger hdd
what's in it now?
ah, relatively small
iso's and VM's take up a LOT of room
same as this workstation though ;)
SWPadnos: Oh, I just found out about MFS, I want to check it out and might play around
what is it?
a redundant network distributed FS
fault tolerant too
don't tell me Moose Peterson made a photo file system or something
Though, I'm not sure I'm like the MASTER's needs
ok, similar to a persistent torrent, complete with master tracker
But FUSE can run over SSL
Ubuntu USB desktop image creator?
my Jaunty machine is off, so I can't check there
note that the version in backports likely has a bug which may cause it to make a non-bootable stick
you might have to put syslinus there yourself, and/or make the partition bootable
Oh hell, nm on the MFS... it's gpl
well it installed to 8.04 ok ( orig from live cd ) now, where to find a live cd, maybe just grab iso and mount it? no. rtfm!
GPL isn't all that bad, unless you want to change it and not distribute the code
eh? dangerous app? makes brick sticks?
no need to mount, you point the program at a bootable ISO :)
SWPadnos: I've never really cared for gpl
no, forgets to put syslinux on the stick, and forgets to mark the partition bootable
JymmmEMC, and yet you use GPL all over the place (like the freenode server software ...)
SWPadnos: ok, will try (maybe not this stick tho), i could even repair the boot flag & push syslinux onto it in a pinch
yeah. there's a thread I was reading about this just today
I think I was searching for how to update a USB stick install
which doesn't work all that well, I'll have you know
(at least not when I do it ;) )
yeah, tried that
but did you make a LIVEUSB or persistant?
problem is that the casper-rw "partition" fills up
live and persistent
well you need a big enough stick
there's a loopback disk image, which I made 512M
the stick is 2G
yeah, so? try 4gb
there's extra stuff that gets stored, and I stopped messing with it before figuring it out
I think it doesn't modify the original image, it adds all the extra stuff to the writable partition, overlaid on the boot image
I removed second hd and set the the remaining one to master, it was a priority conflict , and the partitioning program works now
[05:05:16] <SkinnYPuP> http://www.pendrivelinux.com/
yes, they talk about the loopback vs separate casper partition schmes http://www.pendrivelinux.com/ubuntu-810-persistent-flash-drive-install-from-live-cd/
oh gnite SWPadnos, thx
[05:07:35] <SkinnYPuP> http://www.pendrivelinux.com/tag/usb-ubuntu-804/
I recall when messin with an 810 live disk there was an install to usb in the admin menu
maybe there's something to be learned from its script if anyone is interested in looking
back to w$ for cad, thx
is it recomanded to update ubuntu 8.04 + EMC2?
SWPadnos_ is now known as SWPadnos
