[00:00:08] <robh__> not sure what your trying to do i read a small part of it throught u was trying to get a ramp in on pocket start but maybe not
[00:00:17] <robh__> trying to hold down in a pocket, not move to a Z clear hight?
[00:00:29] <Connor> PetefromTn: Okay. On the pocket... it moves the tool up to "safe" height.. which I can specify. I tend to only make it .125" above the work.. (this is for pockets)
[00:00:33] <PetefromTn> Just a simple pocket with successive depths of .050 in a 2" pocket .5 deep...
[00:00:58] -!- Nick001-Shop has quit [Remote host closed the connection]
[00:01:19] <robh__> well normaly it moves to the safe hight part which is what ever you define normal say 2mm above part stock... unless you ask for hold down or tell it clearence is last cut depth
[00:01:36] <PetefromTn> robh__: yeah the move to safe Z height is a waste of time cutting air and is in every single pocket or profile cut I do..
[00:02:01] <PetefromTn> robh__: Clearance is last cut depth sounds yummy...
[00:02:17] <robh__> but you need to watch for any islands etc...like any cam but u just move the start point if you can
[00:02:55] <robh__> or you turn on Volume Mill and realy move some metal :)
[00:02:57] <PetefromTn> Connor: yeah that is what I do too... but the wasted air is annoying.
[00:03:17] <Connor> http://pastebin.com/SDgtMjAB
[00:03:23] <Connor> 2" circle inside profile..
[00:03:26] <Connor> No wasted air.
[00:03:30] <PetefromTn> robh__: okay...
[00:04:00] <robh__> id say it does not take that much time to rapid to clear and back in.. unless have a realy slow machine
[00:04:10] <PetefromTn> Connor: Okay man now we are getting somewhere...
[00:04:31] <robh__> unless your cam is doing a lot of lifts and back in on a pocket for some odd reason on the same depth
[00:05:25] <PetefromTn> well yeah actually it DOES take a lot of time if it does it at EACH AND EVERY DEPTH!!
[00:05:34] <Connor> http://pastebin.com/weA1vvmp
[00:05:51] <Connor> 2" profile with Spiral lead in..
[00:06:14] <Connor> Which is what I prefer to use.
[00:06:16] <PetefromTn> damn that looks better...
[00:06:30] <PetefromTn> That is an inside profile..
[00:06:44] <Connor> Yea. Same can be done on out side..
[00:07:09] <PetefromTn> but it does not work on a pocketing op...
[00:07:12] -!- slifty has quit [Quit: Leaving...]
[00:07:19] <Connor> Let me check something.
[00:07:22] <Tom_itx> here's another one...
[00:07:37] <PetefromTn> This is interesting isn't it...
[00:07:53] <Tom_itx> http://tom-itx.dyndns.org:81/~webpage/cnc/test/pocket.ngc
[00:08:13] <Tom_itx> i programmed the tool center
[00:08:18] <Tom_itx> so it will be over 2"
[00:08:24] -!- gammax-Laptop1 [gammax-Laptop1!~Rob@75-171-222-108.hlrn.qwest.net] has joined #linuxcnc
[00:08:26] <Tom_itx> err did i?
[00:08:28] <Tom_itx> mmm
[00:08:48] -!- Aero-Tec__ has quit [Read error: Connection reset by peer]
[00:08:54] -!- tmcw_ has quit [Remote host closed the connection]
[00:09:01] <Tom_itx> no it should be ok
[00:09:19] <PetefromTn> Tom_itx: Looks like it comes out of the cut on yours too in a pocketing op.
[00:10:13] <Connor> PetefromTn: I don't think it's going to do it on a pocket.. I think it will always retract..
[00:10:21] -!- cradek has quit [Changing host]
[00:10:21] -!- cradek [cradek!~chris@emc/board-of-directors/cradek] has joined #linuxcnc
[00:10:21] -!- mode/#linuxcnc [+v cradek] by ChanServ
[00:10:43] <PetefromTn> I suppose I can see the reasoning behind it, if you look at the part I am working on, if the cut starts somwhere in the circle and ends in the longish parts and then moves to the start again it will rip off the corner of the straight portion...
[00:10:47] <robh__> sometimes you cant beat a bit of code edit
[00:11:29] <PetefromTn> Honestly if CamBam does this on a pocket but not a profile and has 3d toolpathing it is worth a second look that is for sure...
[00:11:46] <PetefromTn> robh__: Yeah but editing every pocket you draw would be a real pain in the ass..
[00:11:51] <Tom_itx> it shouldn't
[00:12:10] <PetefromTn> what should'nt
[00:12:38] <Tom_itx> oh it may go to z safe
[00:12:50] <PetefromTn> that's what I am talking about..
[00:13:01] <PetefromTn> its annoying waste of time.
[00:13:01] <Tom_itx> i can tell it what to do though i think
[00:13:11] <PetefromTn> show me...LOL
[00:13:12] <Tom_itx> i just posted a quick pocket
[00:13:28] <Tom_itx> you don't have smartcam
[00:13:41] Jymmm is now known as Jymmmmmmmmmm
[00:13:41] <PetefromTn> show me the posted code LOL
[00:13:55] <Tom_itx> it's in the link i posted
[00:14:02] <PetefromTn> How much is Smartcam?
[00:14:09] <Tom_itx> 8k +
[00:14:20] <PetefromTn> The link you posted the cutter comes out of the hole to safe Z
[00:14:21] -!- dimas__ has quit [*.net *.split]
[00:14:21] -!- netxshare has quit [*.net *.split]
[00:14:21] -!- kwallace1 has quit [*.net *.split]
[00:14:21] -!- ds3 has quit [*.net *.split]
[00:14:22] -!- Guest46365 has quit [*.net *.split]
[00:14:22] -!- ve7it has quit [*.net *.split]
[00:14:22] -!- carper64_lb_ has quit [*.net *.split]
[00:14:22] -!- andypugh has quit [*.net *.split]
[00:14:27] <PetefromTn> Nevermind LOL...
[00:14:33] Jymmmmmmmmmm is now known as Jym
[00:16:05] <Tom_itx> PetefromTn, did you get the pocket one?
[00:16:41] <PetefromTn> Got two both do the same thing..
[00:16:56] <Tom_itx> feed & speed are way off too
[00:17:00] <Tom_itx> didn't bother
[00:17:44] <Tom_itx> they do different things
[00:18:04] <Tom_itx> one cuts the pocket from the center out and the other cuts a spiral
[00:18:27] Jym is now known as Jymmm
[00:18:58] <PetefromTn> yeah but it still goes to safe z after each depth right?
[00:19:04] <robh__> PetefromTn, dont forget you dont wanna drag that cuutter over a surface ull end up with marks if finish level or chiping the flutes too
[00:19:15] -!- tooriame [tooriame!~Nunya@unaffiliated/tandoori] has joined #linuxcnc
[00:19:16] <PetefromTn> Honestly does not matter because I am not gonna buy an 8k program
[00:19:33] <robh__> http://pastebin.com/Z2867vNz
[00:19:44] <Tom_itx> if you want full blown 3d you might
[00:20:25] <PetefromTn> robh__: yeah that would be true if you did not intend to cut that level off on the next pass tho..
[00:20:54] <robh__> i did a quick one lifts are over to the next spiral in hight inside the pocket
[00:21:05] -!- gammax-Laptop1 has quit [Ping timeout: 256 seconds]
[00:21:24] <Tom_itx> even so, if you rapid to the start of the next pass you're gonna drag the cutter
[00:21:47] <Tom_itx> unless you raise it to the z clear
[00:22:04] <Tom_itx> i can make z clear be .0001 if i want
[00:22:20] <PetefromTn> So can I but it is annoying..
[00:22:28] <PetefromTn> Maybe I am just a whiner LOL
[00:22:31] <Tom_itx> you are
[00:22:32] <robh__> indeed like even things like volumemill dont like u setting high speed feed links to zero
[00:22:37] <Tom_itx> it's the way it should be done
[00:23:41] <PetefromTn> I guess what I was wanting was the cutter to do the circular pocket spiraling outward, then when it reaches the end of the layers cut maybe ramp down from there and do it again but perhaps that is not possible.
[00:24:08] <Tom_itx> you'd have to reverse the cutter path each level
[00:24:18] <PetefromTn> okay sounds good...
[00:24:53] <PetefromTn> Honestly just the fact that CamBam can do this on profile is a big deal since I use a lot of profiles in my stuff...
[00:25:20] <PetefromTn> Not cracking on sheetcam here as I honestly quite like it but that is a real time saver that much is clear.
[00:25:42] <PetefromTn> Even with a faster machine that rapids at 600+ IPM like my machine that is a PIA...
[00:26:05] <robh__> depends how fast accel is too
[00:26:26] <PetefromTn> Sure does...honestly that is actually even more important most of the time..
[00:27:19] <robh__> mind u, i have seen shops with 50m/min machines but only run them at 50% speed lol becasue it scares them
[00:27:19] <PetefromTn> it takes a moment or so to reach full speed no matter what your machine is so accel rates from hole to hole nearby are even more of a factor on speed..
[00:27:46] <PetefromTn> robh__: I know mine scares me but I am just getting started using it.
[00:28:01] <robh__> yea, i know that feeling
[00:28:24] <PetefromTn> yup accel is considerably more a factor on cycle time than speed.
[00:28:25] <robh__> what are your rapids, 12m? or more
[00:28:42] <robh__> or should i convert to inch mode now
[00:29:15] <PetefromTn> Just screwing around with it as I just got it working but I can see 650 or so IPM on X and Y and 500+ on Z but it is a pucker....
[00:29:29] <PetefromTn> especially in only 20 inches in all directions.
[00:29:43] <robh__> that is nice
[00:30:06] <robh__> sometimes its what the screws will take in speed, if supported both ends they will take it nice
[00:30:08] <PetefromTn> yeah man I doubt I will actually be using it too much..
[00:30:36] <PetefromTn> right now 300 feels about right and 200 on the Z I can stand..
[00:30:56] <PetefromTn> If I got some paying repeat jobs that were run a lot I am sure I would ramp it up...
[00:31:17] <PetefromTn> Nice to know it is there tho ;P
[00:31:42] <robh__> lo, then you will wish u had a faster atc
[00:31:59] <robh__> did you get it tool changing yet?
[00:32:04] -!- joe9 has quit [Read error: Connection reset by peer]
[00:32:28] <PetefromTn> hell no I still need to machine a Spindle motor encoder mount and get feedback working.
[00:32:52] <robh__> aah i see
[00:33:35] <PetefromTn> I do have the tool carousel ram wired up as well as the power drawbar and some sensors..
[00:33:57] <PetefromTn> Almost afraid to tackle the toolchanger really...
[00:33:58] <ssi_> JT-Shop: around? I have thcud questions
[00:34:18] <robh__> you mean try not part the tool changer off with the Z
[00:34:31] -!- tmcw has quit [Remote host closed the connection]
[00:34:34] <PetefromTn> Yes that is EXACTLY what I mean.
[00:35:11] <PetefromTn> Oh well enough BS'ing here. Gonna go do something.
[00:35:18] <PetefromTn> have a good night fellas.
[00:35:27] <robh__> cya
[00:35:31] -!- PetefromTn has quit [Remote host closed the connection]
[00:37:52] -!- the_wench [the_wench!~the_wench@host81-149-189-98.in-addr.btopenworld.com] has joined #linuxcnc
[00:38:16] -!- Felix29 [Felix29!Felix@c-71-193-105-131.hsd1.in.comcast.net] has joined #linuxcnc
[00:42:22] -!- sumpfralle [sumpfralle!~lars@87.234.216.224] has joined #linuxcnc
[00:52:43] <Connor> What does better for inside profile finish? Climb or Conventional ?
[00:54:07] -!- gammax-Laptop1 [gammax-Laptop1!~Rob@75-171-222-108.hlrn.qwest.net] has joined #linuxcnc
[00:54:20] <Tom_itx> i prefer climb but it depends on the machine rigidity
[00:54:49] <Connor> I know that one way gives a much smoother finish.. I just never can remember which way..
